5 Port Gigabit Ethernet Switch DGS-105

 ArtNet Multi PixxControlThe ArtNet Multi PixxControl is a very compact LED pixel controller for digital LED stripes. With a standard ArtNet (DMX over Ethernet)the combination to standard ethernet and WiFi components is possible.Selectable LED controllerThe used LED chip inside the connected digital LED Stripe is selected.Thus, the use of various digital LED Stripes is possible, for example:MagiarLED III flex, MagiarLED II flex, DycoLED, TM1804, TM1812, TM1814, WS2801, WS2811, LPD8803, LPD8806, UCS1903,UCS1912, UCS2912, APA-101, APA-102, APA-104, INK1002, INK1003, SK6812, SK9822, LPD1886 8Bit, LPD1886 12BitAdjustable color sequenceThe RGB color sequence is adjustable which allows universal usage.In addition, you can choose a single color option, in which each pixel has only one channel.Adjustable pixel groupArtNet Multi PixxControl supports pixel groups with an adjustable length.Each pixel group behaves as a single pixel on the 3 DMX channels is controlled.Thus, in extended installations save channels.Muteable LED indicatorThe LED indicators on the ArtNet Multi PixxControl are muteable by ArtNet command (AcLedMute) or time-controlled.This is helpful to disturbing "points of light" especially on stages.Easy ConfigurationA user-friendly configuration via a web browser allows a fast and uncomplicated setting of all parameters.No special software is required, a normal web browser is sufficient. Thus, the configuration at any timefrom your PC, smartphone or tablet device.For easy setting of the IP-address, we provide the IP Configurator as a PC tool or Android app available for free.This allows you to leave the network settings unchanged and can easily configure the IP.High quality and compact designThe ArtNet Multi PixxControl is designed with a 4-pin Neutrik metal XLR connector inside a compact aluminum body.Use together with WiFi componentsIn conjunction with a WiFi-bridge the ArtNet Multi PixxControl can be integrated into standard WiFi networks.As WiFi-bridge we suggest: Netgear WNCE2001.Firmware-Update-FunctionIn order to take advantage of future features, the ArtNet Multi PixxControl has a firmware update function.This can be launched from the browser so that no access to the device is necessary!This Interface will be supported from:Madrix - LED Lighting Control SolutionsDMX-Configurator 4PIXX (V2.x)Jinx!or any other software with ArtNet-outputWe suggest the software MADRIX® - LED Lighting Control Solutions for an easy and optimal controlling via ArtNet. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:5V with included power supply  Connection:RJ45 Ethernet Neutrik® XLR4 USB Mini-B only for the power supply  Protocol:Art-Net ™ (downward compatible)  LED types:MagiarLED III flex / MagiarLED II flexmax. 2720 Pixel TM1804 / TM1812 / TM1829max. 1360 Pixel WS2801max. 1360 Pixel LPD8803max. 1360 Pixel DycoLED / LPD6803 / LPD1101 / APA-101max. 1360 Pixel APA102 / SK9822max. 2720 Pixel LPD1886 - 8Bit oder 12Bitmax. 1360 Pixel WS2811 / WS2812(B) / APA-104 / SK6812max. 1360 Pixel INK1002 / INK1003max. 1360 Pixel UCS1903 / / UCS 1912 / UCS2912max. 1360 Pixel UCS9812max. 850 Pixel DMX512max. 170 Pixel DMX1024max. 340 Pixel  Gamma correction:in combination with LPD1886 - 12Bit, UCS9812  Color sequence:RGB adjustable / SingleColor red, green, blue, white RGBW with SK6812 / UCS2912  Pixel groups:adjustable, 1 - 10  Dimensions:75 x 26 x 35 mm  Delivery includes::ArtNet Multi PixxControl 5V power supply 1m RJ45 network cable 1:1 Product DownloadsArtNet Multi PixxControlBedienungsanleitung ArtNet Multi PixxControlUser Manual ArtNet Multi PixxControlFirmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual IP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note Application NotesArtNet Multi PixxControl mit Jinx ansteuernAppNote Controlling ArtNet Multi PixxControl with JinxAppNote

 ArtNet PixxControl PX1The ArtNet PixxControl PX1 is a compact ArtNet (DMX over Ethernet) interface,which converts ArtNet directly to a control signals for several digital LEDs.For the ArtNet network connection a standard RJ45 network connector is used.Output with selectable pixel data protocolThe ArtNet PixxControl PX1 has one configurable output. The pixel data protocol (control signal)for different LED pixel types and other parameters can be selected separately.Adjustable color sequenceThe RGB color sequence is adjustable, which allows flexible uses.It is also possible to control RGBW pixels. Furthermore, a SingleColor optioncan be selected, where each pixel needs only one channel.Adjustable pixel groupThe ArtNet PixxControl PX1 supports pixel groups with adjustable length.Each pixel group behaves like a single pixel controlled via 3 DMX channels (RGB)or 4 DMX channels (RGBW). That reduces channels in installations with many pixels.RGB-LED-DisplayThe RGB LED displays the current operation status of the ArtNet PixxControl PX1 clearly.Muteable LED-DisplayThe LED displays on the ArtNet PixxControl PX1 can be switched off via ArtNet command (AcLedMute),RDM (DISPLAY_LEVEL) or time-controlled. This is especially helpful on stages to avoid disturbing "light spots".RDMThe important parameters such as the pixel type, the pixel group size or the color sequencecan be set individually for both data outputs via RDM.Free RDM-SoftwareTo set parameters via RDM our free software RDM-Configurator is available as download on our website www.dmx4all.de .DMX4ALL Communication-InterfaceThe ArtNet PixxControl PX1 has another communication interface which uses the DMX4ALL commands via TCP or UDP.Easy ConfigurationA user-friendly configuration via a web browser allows a quick and uncomplicated setting of all parameters.No special software is needed a normal web browser is enough. This means that the configuration is possibleat any time from a PC, smartphone or tablet.To set the IP address easily, the IP Configurator is offered as free download as PC tool or Android app.This allows the network settings of the PC or Android device to remain unchanged in order to configurethe IP of the ArtNet PixxControl PX1.Combinable with WiFi componentsThe ArtNet PixxControl PX1 can be integrated into WLAN networks in combination with a WLAN bridge.Firmware update functionTo use future functions, the ArtNet PixxControl PX1 offers a firmware update function.The update can be started from a web browser, so no access to the device is necessary!Top hat rail housing availableThe top-hat rail housing 350 or 350flat is available as accessory for the ArtNet PixxControl PX1. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:8-24V DC (100mA@12V; 50mA@24V)  Connection:RJ45 Ethernet  5pin screw terminal  Protocol:Art-Net™ 4 (downward compatible) RDM  LED types:APA-101, APA-104, APA-102,max. 1360 pixel DycoLED PB3, DycoLED PB5,  GS8208,  INK1002, INK1003,  LC8808,  LPD1101, LPD8803, LPD6803, LPD8806,  LPD1886 8Bit, LPD1886 12Bit (8Bit controlled),  SK6812, SK6822, SK9822,  SM16703,  TM1804, TM1812, TM1814, TM1829, TM1934,  UCS1903, UCS1912, UCS2903, UCS2912,  WS2801, WS2811, WS2812, WS2812B,  WS2813, WS2815, WS2818, WS2821     LPD1886 12Bit (12Bit controlled),max. 680 pixel UCS9812 (8Bit controlled), UCS9812 (16Bit controlled)   Color Sequence:RGB selectable / RGBW SingleColor white, red, green, blue  Pixel groups:1 up to 127 pixel / all  Gamma correction:Selectable for LPD1886 12Bit (8Bit controlled), UCS9812 (8Bit controlled)  LED-Display:RGB Status-LED Ethernet-Status-LEDs yellow and green  Dimensions:29,2mm x 82mm Product DownloadsArtNet PixxControl PX1Bedienungsanleitung ArtNet PixxControl PX1User Manual ArtNet PixxControl PX1Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note RDM Configurator (ArtNet Produkte)Windows 32 & 64bit RDM ConfiguratorBedienungsanleitung RDM ConfiguratorUser Manual

 ArtNet PixxControl PX2The ArtNet PixxControl PX2 is a compact ArtNet (DMX over Ethernet) interface,which converts ArtNet directly to two independent control signals for several digital LEDs.For the ArtNet network connection a standard RJ45 network connector is used.Two independent outputs with selectable pixel data protocolThe ArtNet PixxControl PX2 has two outputs, independently configurable. The pixel data protocol (control signal)for different LED pixel types and other parameters can be selected separately for each output.Selectable color sequenceThe RGB color sequence is adjustable, which allows flexible uses. It is also possible to control RGBW pixels.Furthermore, a SingleColor option can be selected, where each pixel needs only one channel.Adjustable pixel groupThe ArtNet PixxControl PX2 supports pixel groups with adjustable length.Each pixel group behaves like a single pixel controlled via 3 DMX channels (RGB) or 4 DMX channels (RGBW).That reduces channels in installations with many pixels.Voltage monitoringBoth data outputs are equipped with a voltage input, which allows monitoring of the LED voltage supplyvia the network. The voltage values can be called via RDM or with the web interface.CTRL OutputThe CTRL output can be used to switch off the power supply for the LED installation as soon as theArtNet PixxControl PX2 does not receive any data after 5 minutes or the connected digital LEDs don’t light up.RGB-LED-DisplayThe RGB LED displays the current operation status of the ArtNet PixxControl PX2 clearly.Mute able LED-DisplayThe LED displays on the ArtNet PixxControl PX2 can be switched off via ArtNet command (AcLedMute),RDM (DISPLAY_LEVEL) or time-controlled. This is especially helpful on stages to avoid disturbing "light spots".Easy ConfigurationA user-friendly configuration via a web browser allows quick and uncomplicated setting of all parameters.No special software is needed a normal web browser is enough. This means that the configuration ispossible at any time from a PC, smartphone or tablet.To set the IP address easily, the IP Configurator is offered as free download as a PC tool or Android app.This allows the network settings of the PC or Android device to remain unchanged in order to configurethe IP of the ArtNet PixxControl PX2.RDMThe important parameters such as the pixel type, the pixel group size or the color sequence can be set individuallyfor both data outputs via RDM. Also the voltage values of the LED power supply can be called via RDM.Free RDM-SoftwareTo set parameters via RDM our free software RDM-Configurator is available as download on our website www.dmx4all.de .DMX4ALL Communication-InterfaceThe ArtNet PixxControl PX2 has another communication interface which uses the DMX4ALL commands via TCP or UDP.Combinable with WiFi componentsThe ArtNet PixxControl PX2 can be integrated into WLAN networks in combination with a WLAN bridge.Firmware update functionTo use future functions, the ArtNet PixxControl PX2 offers a firmware update function.The update can be started from a web browser, so no access to the device is necessary!Top-hat rail housing availableThe top-hat rail housing 700 is available as accessory for the ArtNet PixxControl PX2. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:8-24V DC (150mA@12V; 100mA@24V)  Connection:RJ45 Ethernet  12pin screw terminal  Ethernet:10 Mbit/s | 100 Mbit/s  Protocol:Art-Net™ 4 (downward compatible) RDM  LED types:APA-101, APA-104, APA-102,max. 1360 pixel per output DycoLED PB3, DycoLED PB5,  GS8208,  INK1002, INK1003,  LC8808,  LPD1101, LPD8803, LPD6803, LPD8806,  LPD1886 8Bit, LPD1886 12Bit (8Bit controlled),  SK6812, SK6822, SK9822,  SM16703,  TM1804, TM1812, TM1814, TM1829, TM1934,  UCS1903, UCS1912, UCS2903, UCS2912,  WS2801, WS2811, WS2812, WS2812B,  WS2813, WS2815, WS2818, WS2821     LPD1886 12Bit (12Bit controlled),max. 680 pixel per output UCS9812 (8Bit controlled), UCS9812 (16Bit controlled)     DMX512max. 512 DMX channels per output  Color Sequence:RGB selectable / RGBW SingleColor white, red, green, blue  Pixel groups:1 up to 127 pixel / all  Gamma correction:Selectable for LPD1886 12Bit (8Bit controlled), UCS9812 (8Bit controlled)  LED-Display:RGB Status-LED Ethernet-Status-LEDs yellow and green  Dimensions:64,2mm x 82mm Product DownloadsArtNet PixxControl PX2Bedienungsanleitung ArtNet PixxControl PX2User Manual ArtNet PixxControl PX2Firmware

 ArtNet PixxControl PX2+The ArtNet PixxControl PX2+ is a compact ArtNet (DMX over Ethernet) interface,which converts ArtNet directly to two independent control signals for several digital LEDs.For the ArtNet network connection a standard RJ45 network connector is used.Two independent outputs with selectable pixel data protocolThe ArtNet PixxControl PX2+ has two outputs, independently configurable. The pixel data protocol (control signal)for different LED pixel types and other parameters can be selected separately for each output.Selectable color sequenceThe RGB color sequence is adjustable, which allows flexible uses. It is also possible to control RGBW pixels.Furthermore, a SingleColor option can be selected, where each pixel needs only one channel.Adjustable pixel groupThe ArtNet PixxControl PX2+ supports pixel groups with adjustable length.Each pixel group behaves like a single pixel controlled via 3 DMX channels (RGB) or 4 DMX channels (RGBW).That reduces channels in installations with many pixels.Voltage monitoringBoth data outputs are equipped with a voltage input, which allows monitoring of the LED voltage supplyvia the network. The voltage values can be called via RDM or with the web interface.CTRL OutputThe CTRL output can be used to switch off the power supply for the LED installation as soon as theArtNet PixxControl PX2+ does not receive any data after 5 minutes or the connected digital LEDs don’t light up.5 RGB-LED-DisplayFive RGB LEDs display the current operating status of the ArtNet PixxControl PX2+ and the output ports clearly.Muteable LED-DisplayThe LED displays on the ArtNet PixxControl PX2+ can be switched off via ArtNet command (AcLedMute),RDM (DISPLAY_LEVEL) or time-controlled. This is especially helpful on stages to avoid disturbing "light spots".Easy ConfigurationA user-friendly configuration via a web browser allows quick and uncomplicated setting of all parameters.No special software is needed a normal web browser is enough. This means that the configuration ispossible at any time from a PC, smartphone or tablet.To set the IP address easily, the IP Configurator is offered as free download as a PC tool or Android app.This allows the network settings of the PC or Android device to remain unchanged in order toconfigure the IP of the ArtNet PixxControl PX2+.RDMThe important parameters such as the pixel type, the pixel group size or the color sequence can be set individuallyfor both data outputs via RDM. Also the voltage values of the LED power supply can be called via RDM.Combinable with WiFi componentsThe ArtNet PixxControl PX2+ can be integrated into WLAN networks in combination with a WLAN bridge.Firmware update functionTo use future functions, the ArtNet PixxControl PX2+ offers a firmware update function.The update can be started from a web browser, so no access to the device is necessary! Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:8-24V DC (150mA@12V; 100mA@24V)  Connection:RJ45 Ethernet  12pin screw terminal  Protocol:Art-Net™ 4 (downward compatible) RDM  LED types:APA-101, APA-104, APA-102,max. 1360 pixel per output DycoLED PB3, DycoLED PB5,  GS8208,  INK1002, INK1003,  LC8808,  LPD1101, LPD8803, LPD6803, LPD8806,  LPD1886 8Bit, LPD1886 12Bit (8Bit controlled),  SK6812, SK6822, SK9822,  SM16703,  TM1804, TM1812, TM1814, TM1829, TM1934,  UCS1903, UCS1912, UCS2903, UCS2912,  WS2801, WS2811, WS2812, WS2812B,  WS2813, WS2815, WS2818, WS2821     LPD1886 12Bit (12Bit controlled),max. 680 pixel per output UCS9812 (8Bit controlled), UCS9812 (16Bit controlled)     DMX512max. 512 DMX channels per output  Color Sequence:RGB selectable / RGBW SingleColor white, red, green, blue  Pixel groups:1 up to 127 pixel / all  Gamma correction:Selectable for LPD1886 12Bit (8Bit controlled), UCS9812 (8Bit controlled)  LED-Display:5 RGB Status-LED Ethernet-Status-LEDs yellow and green  Dimensions:70mm x 90mm x 60mm Product DownloadsArtNet PixxControl PX2+Bedienungsanleitung ArtNet PixxControl PX2+User Manual ArtNet PixxControl PX2+Firmware

 ArtNet Player X16The ArtNet Player X16, in the following only called ArtNet Player X,is the first Stand-Alone Controller from DMX4ALL, offered in different model versions.Depending on the needed application, the ArtNet Player X is available in different designs and functionalities.As usual, the ArtNet Player X is also quickly ready for use in DMX4ALL manner and remains intuitiveand user-friendly despite numerous and new functions in the handling.This is possible by the well-structured user interface of the device's own web interface, available for the settings.An overview of the current status is provided by the integrated RGB LED.Whether as a board version or as compact ready-made device with comfortable touch operation, the ArtNet Player Xcan be used to play lighting programs from SD card. Different file formats can be used, which can be created withthe DMX Configurator or used as TPM2 files from freely available software.With up to 16 universes, a maximum of 8192 channels can be output via the network with just one ArtNet Player X.Even in larger installations, handling across several devices remains easy and clear thanks to Master-Slave operation.The ArtNet Player X offers the possibility to execute programs comfortably time-controlled. Up to 16 configurable timerscan be defined individually. For each timer one or several days can be assigned as well as the start time.Furthermore, the playback duration as well as the hourly playback with adjustable time window can be set optionally.The current time is needed for the correct processing the timers. This setting is done either via the device's ownweb interface, the optionally available DCF77 Key with DCF77 sensor or according to the ArtNet specificationvia network-based ArtTimeSync packages. DCF77 allows an automatic adjustment to summer / winter time.The configurable digital inputs integrated in the ArtNet Player X allow operation by remote pushbuttons,making additional devices obsolete. Designed as a LongDistance inputs, even larger distances do not cause anyproblems when mounting the switching elements.The ArtNet Player X is convincing and combines a multitude of useful and innovative functions undera top-hat rail housing in its space-saving, compact design.Replay up to 16 DMX UniversesThe ArtNet Player X can output up to 16 DMX universes via Art-Net / sACN.Output via Art-Net or sACNThe DMX universes to be output can be output via Art-Net or sACN.Synchronization of sveral devicesIf more DMX universes are needed, several ArtNet Player X can be synchronized.Two galvanically separate DMX connectionsOn the ArtNet Player X there are 2 galvanically isolated DMX connections.These can be configured as DMX-OUT or DMX-IN.Remote-FunctionThe ArtNet Player X has a configurable remote function. Remote control ispossible via DMX, Art-Net, sACN, HTTP request or DMX4ALL Commands.8 LongDistance inputs8 configurable digital inputs are available for connecting buttons or switches.The inputs are designed as LongDistance Inputs, so the switching elements can also be installed in greater distance.Switchable LED DisplayThe LED displays on the ArtNet Player X can be switched off by ArtNet command or time-controlled,to avoid disturbing "light spots " especially on stage.RGB-FilterA quick and uncomplicated change of the defined color in the program is allowed by the RGB filter.The selected colors can be filtered as needed without editing the previously created program.Firmware-Update-FunctionThe firmware update function enables to use always the free, current device software.Different data files for lighting programsThe ArtNet Player X plays the lighting programs from the SD card.The DMX4ALL program files as well as TPM2 or TPM2NET can be used as data formats.Easy ConfigurationFast and uncomplicated configuration is possible at any time from a PC, smartphone or tablet,due to the user-friendly configuration via any web browser.DIN rail housing availableThe DIN rail housing 700 is available as accessory for the ArtNet Player X.Free SoftwareFor creating the programs our free software DMX-Configurator can be used, which is availablein the current FREE version as download on our website www.dmx4all.de. Specifications  Power supply:8-24V DC (150mA@12V; 100mA@24V)  Connections:RJ45 Ethernet Screw terminals  Ethernet:10 Mbit/s | 100 Mbit/s  Art-Net™ / sACN:16 universes up to 8192 channels  DMX2x galvanically isolated Switchable DMX OUTPUT / DMX INPUT DMX OUTPUT: DMX512 DMX INPUT: DMX512 / RDM  Device-Sync:Synchronisation of several devices  Remote-Options:DMX Art-Net™ sACN HTTP-Request DMX4ALL Commands  Digital Input:8 configurable Long Distance-Inputs  Timer:Up to 16 configurable timer for executing programs Hourly execution with adjustable time slot  SD Card:microSD up to 16GB  Playback format:DMX4ALL program files TPM2 files TPM2NET files  Status display:RGB-LED, network status LEDs all disengageable  Features:RGB-Filter Firmware-Update-Function Silent without a fan  Optional Equipment:DCF77 receiver  Dimension:62mm x 88mm x 29mm Product DownloadsArtNet Player X16Bedienungsanleitung ArtNet Player X16User Manual ArtNet Player X16Firmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual IP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note Application NotesArtNet Player X mit ArtNet-DMX MUX fernsteuernAppNote Remote control Player X with ArtNet-DMX MUXAppNote

 ArtNet Player X16+The ArtNet Player X16+, in the following only called ArtNet Player X,is the first Stand-Alone Controller from DMX4ALL, offered in different model versions.Depending on the needed application, the ArtNet Player X is available in different designs and functionalities.As usual, the ArtNet Player X is also quickly ready for use in DMX4ALL manner and remains intuitiveand user-friendly despite numerous and new functions in the handling.This is possible by the well-structured user interface of the device's own web interface, available for the settings.The essential actions can be set directly on the device, thanks to the clearly designed touch paneland an external access is not needed. An overview of the current status is provided by the integrated RGB LED.Whether as a board version or as compact ready-made device with comfortable touch operation, the ArtNet Player Xcan be used to play lighting programs from SD card. Different file formats can be used, which can be created withthe DMX Configurator or used as TPM2 files from freely available software.With up to 16 universes, a maximum of 8192 channels can be output via the network with just one ArtNet Player X.Even in larger installations, handling across several devices remains easy and clear thanks to Master-Slave operation.The ArtNet Player X offers the possibility to execute programs comfortably time-controlled. Up to 16 configurable timerscan be defined individually. For each timer one or several days can be assigned as well as the start time.Furthermore, the playback duration as well as the hourly playback with adjustable time window can be set optionally.The current time is needed for the correct processing the timers. This setting is done either via the device's ownweb interface, the optionally available DCF77 Key with DCF77 sensor or according to the ArtNet specificationvia network-based ArtTimeSync packages. DCF77 allows an automatic adjustment to summer / winter time.The configurable digital inputs integrated in the ArtNet Player X allow operation by remote pushbuttons,making additional devices obsolete. Designed as a LongDistance inputs, even larger distances do not cause anyproblems when mounting the switching elements.The ArtNet Player X is convincing and combines a multitude of useful and innovative functions undera top-hat rail housing in its space-saving, compact design.Replay up to 16 DMX UniversesThe ArtNet Player X can output up to 16 DMX universes via Art-Net / sACN.Output via Art-Net or sACNThe DMX universes to be output can be output via Art-Net or sACN.Synchronization of sveral devicesIf more DMX universes are needed, several ArtNet Player X can be synchronized.Two galvanically separate DMX connectionsOn the ArtNet Player X there are 2 galvanically isolated DMX connections.These can be configured as DMX-OUT or DMX-IN.Remote-FunctionThe ArtNet Player X has a configurable remote function. Remote control ispossible via DMX, Art-Net, sACN, HTTP request or DMX4ALL Commands.8 LongDistance inputs8 configurable digital inputs are available for connecting buttons or switches.The inputs are designed as LongDistance Inputs, so the switching elements can also be installed in greater distance.Touch HandlingThere are 7 touch fields for operation on the ArtNet Player X as well as an RGB display LED.Switchable LED DisplayThe LED displays on the ArtNet Player X can be switched off by ArtNet command or time-controlled,to avoid disturbing "light spots " especially on stage.RGB-FilterA quick and uncomplicated change of the defined color in the program is allowed by the RGB filter.The selected colors can be filtered as needed without editing the previously created program.Firmware-Update-FunctionThe firmware update function enables to use always the free, current device software.Different data files for lighting programsThe ArtNet Player X plays the lighting programs from the SD card.The DMX4ALL program files as well as TPM2 or TPM2NET can be used as data formats.Easy ConfigurationFast and uncomplicated configuration is possible at any time from a PC, smartphone or tablet,due to the user-friendly configuration via any web browser.Free SoftwareFor creating the programs our free software DMX-Configurator can be used, which is availablein the current FREE version as download on our website www.dmx4all.de. Specifications  Power supply:8-24V DC (150mA@12V; 100mA@24V)  Connections:RJ45 Ethernet Screw terminals  Ethernet:10 Mbit/s | 100 Mbit/s  Art-Net™ / sACN:16 universes up to 8192 channels  DMX2x galvanically isolated Switchable DMX OUTPUT / DMX INPUT DMX OUTPUT: DMX512 DMX INPUT: DMX512 / RDM  Device-Sync:Synchronisation of several devices  Remote-Options:DMX Art-Net™ sACN HTTP-Request DMX4ALL Commands  Digital Input:8 configurable Long Distance-Inputs  Timer:Up to 16 configurable timer for executing programs Hourly execution with adjustable time slot  TOUCH-Control:7 sensor buttons directly on the device for quick operation and RGB status display  SD Card:microSD up to 16GB  Playback format:DMX4ALL program files TPM2 files TPM2NET files  Status display:RGB-LED, network status LEDs all disengageable  Features:RGB-Filter Firmware-Update-Function Silent without a fan  Optional Equipment:DCF77 receiver  Dimension:70mm x 90mm x 60mm Product DownloadsArtNet Player XBedienungsanleitung ArtNet Player XUser Manual ArtNet Player XFirmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual IP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note Application NotesArtNet Player X mit ArtNet-DMX MUX fernsteuernAppNote Remote control Player X with ArtNet-DMX MUXAppNote

 ArtNet Player X8The ArtNet Player X8, in the following only called ArtNet Player X,is the first Stand-Alone Controller from DMX4ALL, offered in different model versions.Depending on the needed application, the ArtNet Player X is available in different designs and functionalities.As usual, the ArtNet Player X is also quickly ready for use in DMX4ALL manner and remains intuitiveand user-friendly despite numerous and new functions in the handling.This is possible by the well-structured user interface of the device's own web interface, available for the settings.An overview of the current status is provided by the integrated RGB LED.Whether as a board version or as compact ready-made device with comfortable touch operation, the ArtNet Player Xcan be used to play lighting programs from SD card. Different file formats can be used, which can be created withthe DMX Configurator or used as TPM2 files from freely available software.With up to 8 universes, a maximum of 4096 channels can be output via the network with just one ArtNet Player X.Even in larger installations, handling across several devices remains easy and clear thanks to Master-Slave operation.The ArtNet Player X offers the possibility to execute programs comfortably time-controlled. Up to 16 configurable timerscan be defined individually. For each timer one or several days can be assigned as well as the start time.Furthermore, the playback duration as well as the hourly playback with adjustable time window can be set optionally.The current time is needed for the correct processing the timers. This setting is done either via the device's ownweb interface, the optionally available DCF77 Key with DCF77 sensor or according to the ArtNet specificationvia network-based ArtTimeSync packages. DCF77 allows an automatic adjustment to summer / winter time.The configurable digital inputs integrated in the ArtNet Player X allow operation by remote pushbuttons,making additional devices obsolete. Designed as a LongDistance inputs, even larger distances do not cause anyproblems when mounting the switching elements.The ArtNet Player X is convincing and combines a multitude of useful and innovative functions undera top-hat rail housing in its space-saving, compact design.Replay up to 8 DMX UniversesThe ArtNet Player X can output up to 8 DMX universes via Art-Net / sACN.Output via Art-Net or sACNThe DMX universes to be output can be output via Art-Net or sACN.Synchronization of sveral devicesIf more DMX universes are needed, several ArtNet Player X can be synchronized.Two galvanically separate DMX connectionsOn the ArtNet Player X there are 2 galvanically isolated DMX connections.These can be configured as DMX-OUT or DMX-IN.Remote-FunctionThe ArtNet Player X has a configurable remote function. Remote control ispossible via DMX, Art-Net, sACN, HTTP request or DMX4ALL Commands.8 LongDistance inputs8 configurable digital inputs are available for connecting buttons or switches.The inputs are designed as LongDistance Inputs, so the switching elements can also be installed in greater distance.Switchable LED DisplayThe LED displays on the ArtNet Player X can be switched off by ArtNet command or time-controlled,to avoid disturbing "light spots " especially on stage.RGB-FilterA quick and uncomplicated change of the defined color in the program is allowed by the RGB filter.The selected colors can be filtered as needed without editing the previously created program.Firmware-Update-FunctionThe firmware update function enables to use always the free, current device software.Different data files for lighting programsThe ArtNet Player X plays the lighting programs from the SD card.The DMX4ALL program files as well as TPM2 or TPM2NET can be used as data formats.Easy ConfigurationFast and uncomplicated configuration is possible at any time from a PC, smartphone or tablet,due to the user-friendly configuration via any web browser.DIN rail housing availableThe DIN rail housing 700 is available as accessory for the ArtNet Player X.Free SoftwareFor creating the programs our free software DMX-Configurator can be used, which is availablein the current FREE version as download on our website www.dmx4all.de. Specifications  Power supply:8-24V DC (150mA@12V; 100mA@24V)  Connections:RJ45 Ethernet Screw terminals  Ethernet:10 Mbit/s | 100 Mbit/s  Art-Net™ / sACN:8 universes up to 4096 channels  DMX2x galvanically isolated Switchable DMX OUTPUT / DMX INPUT DMX OUTPUT: DMX512 DMX INPUT: DMX512 / RDM  Device-Sync:Synchronisation of several devices  Remote-Options:DMX Art-Net™ sACN HTTP-Request DMX4ALL Commands  Digital Input:8 configurable Long Distance-Inputs  Timer:Up to 16 configurable timer for executing programs Hourly execution with adjustable time slot  SD Card:microSD up to 16GB  Playback format:DMX4ALL program files TPM2 files TPM2NET files  Status display:RGB-LED, network status LEDs all disengageable  Features:RGB-Filter Firmware-Update-Function Silent without a fan  Optional Equipment:DCF77 receiver  Dimension:62mm x 88mm x 29mm Product DownloadsArtNet Player X8Bedienungsanleitung ArtNet Player X8User Manual ArtNet Player X8Firmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual IP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note Application NotesArtNet Player X mit ArtNet-DMX MUX fernsteuernAppNote Remote control Player X with ArtNet-DMX MUXAppNote

 ArtNet-DMX Mux16The ArtNet-DMX Mux16 has 16 digital inputs which are given to a ArtNet and DMX output..Each input can act to one or more output channels and the mode is selectable.A user-friendly configuration by using the webinterface allows a fast and uncomplicated setting of all parameters.The firmware of the ArtNet-DMX Mux16 can be update easy over the network. Specifications  Power supply:7-24V DC / 0,5A  Ethernet:1x RJ45  DMX-OUT:1x 512 channels  Inputs:16x Long Distance Digital Input  Mode:Switch Button On Button Off Button On/Off Dimmer Up/Down Dimmer Up Dimmer Down Button On + Dimmer Up Button Off + Dimmer Down Button On/Off + Dimmer Up/Down  Dimensions:99 x 82 x 20mm Product DownloadsArtNet-DMX Mux16Bedienungsanleitung ArtNet-DMX Mux16User Manual ArtNet-DMX Mux16Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note

 ArtNet-DMX Mux24The ArtNet-DMX Mux24 has 16 digital inputs and 8 additional inputs which are adaptableanalog or digital. The output occurs via ArtNet and DMX. For each input the function (Mode) as well as the channels to control are adjustable. A user-friendly configuration via a web browser allows a fast an uncomplicatedsetting for all parameters. The firmware of the ArtNet-DMX Mux24 can be update easy over the network. Specifications  Power supply:7-24V DC / 0,5A  Ethernet:1x RJ45  DMX-OUT:1x 512 channels  Inputs:16x Long Distance Digital Input 8x Analog Eingang or Long Distance Digital Eingang  Mode:Switch Button On Button Off Button On/Off Dimmer Up/Down Dimmer Up Dimmer Down Button On + Dimmer Up Button Off + Dimmer Down Button On/Off + Dimmer Up/Down Analog 0-10V Analog 0-5V Analog 1-10V  Timer:4 configureable timer  Dimensions:99 x 82 x 20mm Product DownloadsArtNet-DMX Mux24Bedienungsanleitung ArtNet-DMX Mux24User Manual ArtNet-DMX Mux24Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note

 ArtNet-LED-Dimmer 4 MK2The ArtNet-LED-Dimmer 4 MK2 is a compact LED-Dimmer controlling 4 separate LED outputs.These can be used for RGB+W or for single, single-colored LED-Stripes.The LEDs connection occurs via removable screw clamps.Via a RJ45-Connection occurs the connection to Ethernet (ArtNet net work).High Power OutputsThe outputs can drive a current of 10A.So, a load of maximum 120W (12V) or rather 240W (24V) results.10 user defined color changes/programsThe ArtNet-LED-Dimmer 4 MK2 offers more than 10 user defined color changes.These can be created via the web browser or the Android App „DMX4ALL Remote“.Disengageable LED-Display The LED-Displays at the ArtNet-LED-Dimmer 4 MK2 are disengageablevia ArtNet-Command (AcLedMute) or time-controlled.Most of all this is very helpful on stages to avoid disturbing “light-points”.Easy configuration A user friendly configuration via a web browser allows a fast and uncomplicated settingof all parameters. No special software is necessary, a standard web browser is enough.So, the configuration is possible every time from PC, Smartphone or tablet.For an easy setting of the IP we provide the IP-Configurator as PC-Tool or Android-App for free.The network settings can be leaved unchanged and the IP can be configured without any problems.Controlling via browser or App with Colorwheel / Slider The output control is available via an integrated web interface with a Colorwheel.Alternatively each other app which supports Art-Net can be used.Firmware-Update-Function To use future functions the ArtNet-LED-Dimmer 4 MK2 offers a Firmware-Update-Function.This can be started from a web browser, so that no direct access to the device is necessary!DMX4ALL Communication-Interface The ArtNet-LED-Dimmer 4 MK2 has a further TCP-Communication-Interface.This interface uses the DMX4ALL-Commands with TCP-Commands via TCP-Packages to Port 10001. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:12-24V DC / 100mA (=LED voltage)  LED voltage:12-24V DC (no AC voltage !)  Connection:RJ45 Ethernet  LED-connection:R/G/B + W screw terminals max. 10A with common anode (+)  USB-connection:5V / 500mA for power supply external devices (e.g. WLAN-bridge)  PWM-Frequency:250 Hz  Dimensions:115mm x 54mm x 23mm DMX4ALL Commands  Protocol:Art-Net 3 ™ DMX4ALL Commands Product DownloadsArtNet-LED Dimmer 4 MK2Bedienungsanleitung ArtNet-LED Dimmer 4 MK2User Manual ArtNet-LED Dimmer 4 MK2Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note

 ArtNet-LED-Dimmer 4 MK2+The ArtNet-LED-Dimmer 4 MK2 is a compact LED-Dimmer controlling 4 separate LED outputs.These can be used for RGB+W or for single, single-colored LED-Stripes.The LEDs connection occurs via removable screw clamps.Via a RJ45-Connection occurs the connection to Ethernet (ArtNet net work).High Power OutputsThe outputs can drive a current of 10A.So, a load of maximum 120W (12V) or rather 240W (24V) results.10 user defined color changes/programsThe ArtNet-LED-Dimmer 4 MK2 offers more than 10 user defined color changes.These can be created via the web browser or the Android App „DMX4ALL Remote“.Disengageable LED-Display The LED-Displays at the ArtNet-LED-Dimmer 4 MK2 are disengageablevia ArtNet-Command (AcLedMute) or time-controlled.Most of all this is very helpful on stages to avoid disturbing “light-points”.Easy configuration A user friendly configuration via a web browser allows a fast and uncomplicated settingof all parameters. No special software is necessary, a standard web browser is enough.So, the configuration is possible every time from PC, Smartphone or tablet.For an easy setting of the IP we provide the IP-Configurator as PC-Tool or Android-App for free.The network settings can be leaved unchanged and the IP can be configured without any problems.Controlling via browser or App with Colorwheel / Slider The output control is available via an integrated web interface with a Colorwheel.Alternatively each other app which supports Art-Net can be used.High quality and compact design The ArtNet-LED-Dimmer 4+ MK2 is manufactured with removable clamps.Furthermore, the ArtNet LED Dimmer 4+ MK2 is mounted in a compact aluminum housing.Firmware-Update-Function To use future functions the ArtNet-LED-Dimmer 4 MK2 offers a Firmware-Update-Function.This can be started from a web browser, so that no direct access to the device is necessary!DMX4ALL Communication-Interface The ArtNet-LED-Dimmer 4 MK2 has a further TCP-Communication-Interface.This interface uses the DMX4ALL-Commands with TCP-Commands via TCP-Packages to Port 10001. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:12-24V DC / 100mA (=LED voltage)  LED voltage:12-24V DC (no AC voltage !)  Connection:RJ45 Ethernet  LED-connection:R/G/B + W screw terminals max. 10A with common anode (+)  USB-connection:5V / 500mA for power supply external devices (e.g. WLAN-bridge)  PWM-Frequency:250 Hz  Dimensions:115mm x 74mm x 23mm  Protocol:Art-Net 3 ™ DMX4ALL Commands Product DownloadsArtNet-LED Dimmer 4 MK2+Bedienungsanleitung ArtNet-LED Dimmer 4 MK2+User Manual ArtNet-LED Dimmer 4 MK2+Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note

 ArtNet-LED-Dimmer 6The ArtNet Dimmer 6 is a compact LED-Dimmer with 6 seperate LED-outputs.These can be used for RGB/ RGB+W / RGB + W WW or for single color stripes.High Power OutputsEach output can drive a current up to 10A.So it is possible to connect a maximum load on ecah output of 120W (12V) or 240W (24V).16 Million ColorsWith the RGB-LED-Stripe up to 16 million colours can be adjusted.By using an additional single color white stripe it is possible to makecolor neutral illuminations or pastel colours.NEW: User Configurable Color ProgrammsThe ArtNet-LED Dimmer 6 has also 10 user configurable color programms whichcan be defined via the webbrowsr or the Android App „DMX4ALL Remote“.User-friendly ConfigurationA user-friendly configuration via a web browser allows a fast and uncomplicated setting of all parameters.Power Supply for WiFi BridgeIn addition the ArtNet-Dimmer 6 has a USB connector providing a power supplywith 5V/500mA for external devices e.x. a WiFi-bridge.As WLAN-bridge we suggest: TP-Link TL-WR702N or TP-Link TL-WR802NControll with AppThe controll of this device is possible by using the free Android-App "DMX Remote".Firmware-Update-FunctionIn order to take advantage of future features, the ArtNet-LED-Dimmer 6 has a firmware update function.This can be launched from the browser so that no access to the device is necessary!DMX4ALL-Command interfaceThe ArtNet-LED-Dimmer 6 has another TCP communication interface.This interface uses the DMX4ALL-commands via TCP packets. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:12-24V DC / 100mA  LED voltage:12-24V DC (no AC voltage !)  Connection:RJ45 Ethernet  LED-connection:6 outputs max. 10A per output (in total 60A) common anode (+)  USB-connection:5V / 500mA for power supply external devices (e.g. WLAN-bridge)  PWM-Frequency:250Hz / 500Hz / 1000Hz / 2000 Hz  Dimensions:64,2 x 82 x 20 mm  Protocol:Art-Net 3 ™ DMX4ALL Commands Product DownloadsArtNet-LED Dimmer 6Bedienungsanleitung ArtNet-LED Dimmer 6User Manual ArtNet-LED Dimmer 6Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note DMX4ALL CommandsDMX4ALL Commands for Devolopment

 ArtNet-LED-Dimmer CC4The ArtNet-LED-Dimmer CC4 is designed for controlling LEDs,which are operated with constant current and works with up to 48V DC.4 Outputs with selectable constant current modulesSeveral constant current modules with different output currents to insert are available.The constant current modules are available as accessory and not included in delivery.For power supply from 12V up to 48VThe ArtNet-LED-Dimmer CC4 works with a power supply of 12V up to 48V.DMX or Art-Net™The ArtNet-LED-Dimmer CC4 can be controlled via DMX or ArtNet (DMX over Ethernet).Which signal is used prior can be selected.DMX-FAIL FunctionA DMX-FAIL-Function, which can be activated optionally, leaves the status unchangedin case of a DMX-Signal failure, turns off the output OFF (0%) or ON (100%).Disengageable LED-DisplaysThe LED-Displays at the ArtNet-LED-Dimmer CC4 can be disengaged viaArtNet-Command (AcLedMute) or time controlled. This is very helpfulto avoid disturbing “lights points” e.g. on stage.10 User defined Color Changes / ProgramsThe ArtNet-LED-Dimmer CC4 offers 10 user defined color changes.These can be created via a web browser or via the Android App „DMX4ALL Remote“.Test Function for Service PurposesFor test and service purposes it is possible to switch on the single outputs viathe web interface. So each output can be checked without an external control.Easy ConfigurationAn user friendly configuration via web browser allows a fast and uncomplicated settingof all parameters. No special software is necessary, a standard web browser is enough.So, anytime the configuration is possible from PC, Smartphone or tablet.For an easy setting of the IP we provide the IP-Configurator as PC-Tool or Android-App for free.The network settings can be leaved unchanged and the IP can be configured without any problems.Firmware-Update-FunctionTo use future functions the ArtNet-LED-Dimmer CC4 offers a Firmware-Update-Function.The update can be started from a web browser, so no direct access to the device is necessary! Specifications  Power supply:9-48V DC / 150mA@12V; 80mA/24V; 60mA@48V (Current consumption without LED-Driver)  Ethernet:RJ45 (Art-Net™)  DMX:3pin screw terminal  DMX-Kanäle4 Channels (without master dimmer) 5 Channels (with master dimmer)  DMX-FAIL:HOLD / ALL OFF / ALL ON  Masterdimmer:activatable  Output:4 current regulated output (8 bit controlled) (Output current depends on the LED driver module)  PWM-Frequency:244 Hz  USB connector:5V / 500mA for power supply external devices (e.g. WLAN-Bridge)  Dimensions:99mm x 82mm  Constant current modules:Constant current LED-Driver LDD-H(available as an accessory)Constant current LED-Driver NLDD-H Product DownloadsArtNet-LED-Dimmer CC4Bedienungsanleitung ArtNet-LED-Dimmer CC4User Manual ArtNet-LED-Dimmer CC4Firmware

 ArtNet-Relais/Analog 4The ArtNet Relais/Analog Interface 4 is designed for switching loads of several kinds.4 relay and 4 analog outputsFour potential free contacts with up to 8A switching power are available.Additional four analog outputs with 0-10V or 1-10V can be used to control systems with analog inputs.DMX or Art-NetThe ArtNet Relais/Analog Interface 4 can controlled by a DMX signal or by an Art-Net (DMX over Ethernet) signal.DMX-HOLD functionA DMX-HOLD function can be activated. Then, the state of the relay and analog outputs is hold after losing the DMX signal. User-friendly ConfigurationA user-friendly configuration via a web browser allows a fast and uncomplicated setting of all parameters.Power Supply for WiFi BridgeIn addition the ArtNet Relais/Analog Interface 4 has a USB connector providing a power supplywith 5V/500mA for external devices e.x. a WiFi-bridge.As WLAN-bridge we suggest: TP-Link TL-WR702N or TP-Link TL-WR802NControll with AppThe controll of this device is possible by using the free Android-App "DMX Remote".Firmware-Update-FunctionIn order to take advantage of future features, the ArtNet Relais/Analog Interface 4 has a firmware update function.This can be launched from the browser so that no access to the device is necessary!DMX4ALL-Command interfaceThe ArtNet Relais/Analog Interface 4 has another TCP communication interface.This interface uses the DMX4ALL-commands via TCP packets. Specifications  Power supply:12-24V DC / 250mA  Ethernet:RJ45  Input:4 up to 12 DMX-channels  Output:4 switching contacts each max. 8A / 250V~ (165A/20ms Switch-on peak current) 4x analog output 0-10V / 1-10V  DMX-FAIL:Hold / Off  Connectors:screw terminals  USB-connection:5V / 500mA for power supply external devices (e.g. WLAN-bridge)  Dimensions:99 x 82mm  Protocol:Art-Net ™ DMX4ALL Commands Product DownloadsArtNet-Relais/Analog Interface 4Bedienungsanleitung ArtNet-Relais/Analog Interface 4User Manual ArtNet-Relais/Analog Interface 4Firmware
