Product information "DMX-LED-Dimmer MaxiRGB"
 DMX-LED-Dimmer MaxiRGB |
The DMX-LED-Dimmer MaxiRGB is specially designed for driving RGB LED strips with 12V or 24V.
The 3 separate LED outputs that are independently controllable via DMX can be
used for RGB or separate single color LED stripes.
Alternatively, internal color gradients can be called without external control.
The operating voltage of the DMX-LED-Dimmer MaxiRGB is also the operating voltage of the LED-Stripes.
| Specifications |
| Power supply: | 12-24V DC / 50mA |
| The supply voltage must correspond to the voltage for the LED stripe! | |
| LED voltage: | 12-24V DC (no AC voltage !) |
| DMX Input: | DMX512 / 3 channels |
| LED Output: | 3x (R/G/B) max. 10A each |
| together max. 10A with common anode (+) | |
| common power supply | |
| PWM resolution: | 256 steps (8-Bit), linear |
| PWM frequency: | ~240 Hz |
| StandAlone function: | 9 internal StandAlone-programs |
| Connectors: | Solder points |
| Dimensions: | 70mm x 30 mm |
| Product Downloads |
