DMX-LED-Dimmer MaxiRGBThe DMX-LED-Dimmer MaxiRGB is specially designed for driving RGB LED strips with 12V or 24V.The 3 separate LED outputs that are independently controllable via DMX can beused for RGB or separate single color LED stripes.Alternatively, internal color gradients can be called without external control.The operating voltage of the DMX-LED-Dimmer MaxiRGB is also the operating voltage of the LED-Stripes. Specifications Power supply:12-24V DC / 50mA The supply voltage must correspond to the voltage for the LED stripe! LED voltage:12-24V DC (no AC voltage !) DMX Input:DMX512 / 3 channels LED Output:3x (R/G/B) max. 10A each together max. 10A with common anode (+) common power supply PWM resolution:256 steps (8-Bit), linear PWM frequency:~240 Hz StandAlone function:9 internal StandAlone-programs Connectors:Solder points Dimensions:70mm x 30 mm Product DownloadsDMX-LED-Dimmer MaxiRGBBedienungsanleitung DMX-LED-Dimmer MaxiRGBUser Manual
DMX-LED-Dimmer XS3The DMX-LED-Dimmer XS3 is designed to control RGB orsingle-colour LED-Stripes with 12V or 24V.3 OutputsThe DMX-LED-Dimmer XS3 has three outputs to connect LEDs. All outputsare designed at the same, so single-colour or RGB LEDs can be connected.High Power OutputsThe outputs can drive a current up to 2A.So it is possible to connect a maximum load of 72W (12V) / 144W (24V).0% up to 100% dimmableThe connected LEDs are dimmed via PWM from 0% up to 100%.For voltages from 12V up to 24VThe DMX-LED-Dimmer XS3 runs with a power supply from 12V up to 24V.DMX-FAIL FunctionAn adjustable DMX-FAIL Function offers the option to get, in case oflost DMX signal, the current state (HOLD) or assuming a preset value.DMX-Master dimmerOptionally, another DMX channel can be activated as master dimmer (all outputs).RDM supportThe DMX-LED-Dimmer XS3 allows configuration by RDM via DMX.All parameters can be set with the RDM Configurator.Stand-Alone-FunctionThe DMX-LED-Dimmer XS3 has a user-programmable Stand-Alone-Function,to replay an internal program.LED-Status-DisplayThe DMX receiving is indicated via the LED status display. Specifications Power supply:12-24V DC 50mA without load LED voltage:12-24V DC (no AC voltage !) Protocol:DMX512 RDM DMX channels:3 / 4 / 5 channels depend on Personality DMX-FAIL:Hold / 0%-100% / Stand-Alone Output:3 PWM-Signals with 8 Bit resolution Common supply voltage Output current:max. 2A per output max. 6A in sum for all outputs Output power:3x 24W (12V) / 3x 48W (24V) PWM-Frequency:244 Hz StandAlone-Function:User-defined light program Connections:Solder pads Dimensions:12mm x 40mm Product DownloadsDMX-LED-Dimmer XS3Bedienungsanleitung DMX-LED-Dimmer XS3User Manual
DMX-LED-Dimmer MaxiRGB (SR)The DMX-LED-Dimmer MaxiRGB is specially designed for driving RGB LED strips with 12V or 24V.The 3 separate LED outputs that are independently controllable via DMX can beused for RGB or separate single color LED stripes.Alternatively, internal color gradients can be called without external control.The operating voltage of the DMX-LED-Dimmer MaxiRGB is also the operating voltage of the LED-Stripes.SR-Version: With screw connectors Specifications Power supply:12-24V DC / 50mA The supply voltage must correspond to the voltage for the LED stripe! LED voltage:12-24V DC (no AC voltage !) DMX Input:DMX512 / 3 channels LED Output:3x (R/G/B) max. 10A each together max. 10A with common anode (+) common power supply PWM resolution:256 steps (8-Bit), linear PWM frequency:~240 Hz StandAlone function:9 internal StandAlone-programs Connectors:Screw connectors Dimensions:70mm x 30 mm Product DownloadsDMX-LED-Dimmer MaxiRGB (SR)Bedienungsanleitung DMX-LED-Dimmer MaxiRGB (SR)User Manual
DMX-LED-Dimmer CC1The DMX-LED-Dimmer CC1 is designed for controlling LEDs, which are operated with constant current and works with up to 48V DC.Output with selectable constant current modulesDifferent constant current modules with different output currents are available for connection.The constant current modules are available as accessories and are not included in the scope of delivery.Power supply from 12V up to 48VThe DMX-LED Dimmer CC1 works with supply voltages from 12V to 48V.0% to 100%The connected LEDs can be dimmed via PWM of 0% up to 100%.DMX FAIL-FunctionAn adjustable DMX FAIL-Function offers the option to hold the current state (HOLD)or to adopt a predefined value if the DMX signal fails.RDM supportThe DMX-LED-Dimmer CC1 the configuration via RDM or DMX.Top hat rail mounting availableSuitable for the DMX-LED-Dimmer CC1 the DIN rail housing 350 is available as accessory. Specifications Power supply:9-48V DC 20mA@12V; 11mA/24V; 6mA@48V (without LED driver) Protocol:DMX512 / RDM DMX channels1 DMX channel DMX-FAIL:HOLD / 0-100% Output:1 current regulated output (8 bit controlled) (Output current depends on the LED driver module) PWM-Frequency:244 Hz Dimensions:29,2mm x 82mm Product DownloadsDMX-LED-Dimmer CC1Bedienungsanleitung DMX-LED-Dimmer CC1User Manual
DMX-LED-Dimmer CC4The DMX-LED-Dimmer CC4 is designed for controlling LEDs, which are operatedwith constant current and works with up to 48V DC.4 outputs with choose able constant current modulesDifferent constant current modules with different output currents are available for plug-on.The constant current modules are available as accessories and are not included in the scope of delivery.For voltages from 12V up to 24VThe DMX-LED-Dimmer CC4 works with supply voltages from 12V up to 24V DC.DMX FAIL-FunctionAn adjustable DMX FAIL function offers the option to hold the current state (HOLD)or to adopt a predefined value if the DMX signal fails.LED state displayThe DMX state is indicated via the LED status.DMX-MasterdimmerOptionally an additional DMX channel can be activated as master dimmer.0% up to 100% dimmableThe connected LEDs are dimmed from 0% up to 100% via PWM.RDM supportThe DMX-LED-Dimmer CC4 allows configuration by RDM via DMX.Top-hat rail housing availableThe top-hat rail housing 1050 is available as accessory for the DMX-LED-Dimmer X9HR.Together with the top-hat rail housing 1050, the interface is optimally suited for control cabinet installation. Specifications Power supply:9-48V DC / 20mA@12V; 11mA/24V; 6mA@48V (without LED driver) Output voltage:Depends on the constant current module used Output current:Depends on the constant current module used Protocol:DMX512 RDM DMX-Channels:4 / 5 channels DMX-FAIL:HOLD / ALL OFF / ALL ON Masterdimmer:can be enabled PWM-Frequency:244 Hz Connections:Screw terminals Dimensions:99mm x 82mm Product DownloadsDMX-LED-Dimmer CC4Bedienungsanleitung DMX-LED-Dimmer CC4User Manual
DMX-LED-Dimmer 4The DMX-LED-Dimmer 4 is a compact LED-Dimmer with 4 seperate LED-outputs.These can be used for RGB/ RGB+W or for single color stripes.The connectors for LED,power supply and DMX are made with removable screw terminals.Can be used from 12V to 48VThe DMX-LED Dimmer 4 can be used in a wide power supply range from 12V to 48V.High Power OutputsThe outputs can drive a current up to 10A.So it is possible to connect a maximum load of 120W (12V) / 240W (24V) / 240W (48V).Customizable LookUp tablesThe DMX-LED-Dimmer 4 has one LookUp-Table per output.The definition of the LookUp tables is done via the USB port using theprogram DMX-Configurator, which is available as a free download.Removable screw terminalsThe DMX-LED Dimmer 4 is designed with removable screw terminals.16 Million ColorsWith the RGB-LED-Stripe up to 16 million colours can be adjusted.By using an additional single color white stripe it is possible to makecolor neutral illuminations or pastel colours.Firmware-Update-FunctionIn order to take advantage of future features, the DMX-LED-Dimmer 4 has a firmware update function. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications Power supply:12-48V DC / 50mA without load (=LED voltage) LED voltage:12-48V DC (no AC voltage !) (=power supply voltage) DMX-IN:4 channels + optional Master-Dimmer-Channel DMX-Fail:Hold / Off / On Ausgang:4 PWM-Signal with 16 Bit resolution common supply voltage Output current:max. 10A each output with 12V or 24V max. 5A each output with 48V max. 10A in sum through all outputs Output :120W (12V) / 240W (24V) / 240W (48V) PWM-Frequency:244 Hz / 4kHz Master-Dimmer:None / Masterdimmer / System-Masterdimmer StandAlone-Function:9 internal StandAlone-Programs Dimensions:80mm x 50,5mm Product DownloadsDMX-LED-Dimmer 4Bedienungsanleitung DMX-LED-Dimmer 4User Manual DMX-LED-Dimmer 4USB Driver - Version 6.0.0.0 DMX-LED-Dimmer 4Firmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual
DMX-LED-Dimmer 16xRGBThe DMX-LED-Dimmer 16xRGB has 48 outputs which are summarized in 16 RGB groups.Each output is optimal for all RGB-LED-stripes but can be also used for unicoloured LED-stripes.The global master-dimmer (all outputs) or one master-dimmer per RGB-group can be activated.The global master-dimmer can be fixed to the DMX-address 1 as system-master-dimmer. Specifications Power supply:7-24V DC / 100mA (without connected load) Input:DMX512 / 48 up to 64 channels Output:48 PWM-outputs per up to 2A (together 14A) PWM-Frequency:120 Hz Dimensions:100 x 60 mm Product DownloadsDMX-LED-Dimmer 16xRGBBedienungsanleitung DMX-LED-Dimmer 16xRGBUser Manual
DMX-LED-Dimmer X9The DMX-LED-Dimmer X9 is especially designed for controlling RGB LED-Stripes.The dimmer has 9 PWM-Outputs (3xRGB) independently controllable via DMX.9 OutputsThe DMX-LED-Dimmer X9 has 9 outputs to which LEDs can be connected.All outputs are designed in the same way so single color, RGB or RGBW LEDs can be connected.High Power OutputsThe outputs can drive a current up to 10A.So it is possible to connect a maximum load of 120W (12V) / 240W (24V)0% bis 100% dimmableThe connected LEDs are dimmed by PWM from 0% to 100%.For voltages from 12V up to 24VThe DMX-LED-Dimmer X9 operates with supply voltages from 12V up to 24V. The LED voltage canbe different per output so that one DMX-LED-Dimmer X9 can control different LED systems.DMX-FAIL FunctionAn adjustable DMX FAIL function offers the option to get in case of lostDMX signal the current state (HOLD) or assuming a preset value.RDM supportThe DMX-LED-Dimmer X9 allows configuration by RDM via DMX.LED-State DisplayThe DMX state is indicated via the LED status.Stand-Alone FunctionAs an alternative to DMX control, internal color sequences can be called upvia the address switch without external DMX control.Top hat rail housing availableThe top-hat rail housing 1050 is available as accessory for the DMX-LED-Dimmer X9. Specifications Power supply:7-24V DC 80mA@12V / 100mA@24V (without connected LED load) LED voltage:7-24V DC (no AC voltage !) Protocol:DMX512 RDM DMX channels:9 channels with 8Bit-controlling DMX-FAIL:Hold / 0%-100% Output:9 PWM-signal with 8Bit-resolution Common supply voltage Output current:max. 10A each output In sum 90A with all GND connections Output power:9x 120W (12V) / 9x 240W (24V) PWM-Frequency:244 Hz Energy-Save output:Control output for switching off the load power supply units StandAlone function:9 internal StandAlone programs Connections:Screw terminals Dimensions:99mm x 82 mm Product DownloadsDMX-LED-Dimmer X9Bedienungsanleitung DMX-LED-Dimmer X9User Manual
ArtNet-LED-Dimmer CC4The ArtNet-LED-Dimmer CC4 is designed for controlling LEDs,which are operated with constant current and works with up to 48V DC.4 Outputs with selectable constant current modulesSeveral constant current modules with different output currents to insert are available.The constant current modules are available as accessory and not included in delivery.For power supply from 12V up to 48VThe ArtNet-LED-Dimmer CC4 works with a power supply of 12V up to 48V.DMX or Art-Net™The ArtNet-LED-Dimmer CC4 can be controlled via DMX or ArtNet (DMX over Ethernet).Which signal is used prior can be selected.DMX-FAIL FunctionA DMX-FAIL-Function, which can be activated optionally, leaves the status unchangedin case of a DMX-Signal failure, turns off the output OFF (0%) or ON (100%).Disengageable LED-DisplaysThe LED-Displays at the ArtNet-LED-Dimmer CC4 can be disengaged viaArtNet-Command (AcLedMute) or time controlled. This is very helpfulto avoid disturbing “lights points” e.g. on stage.10 User defined Color Changes / ProgramsThe ArtNet-LED-Dimmer CC4 offers 10 user defined color changes.These can be created via a web browser or via the Android App „DMX4ALL Remote“.Test Function for Service PurposesFor test and service purposes it is possible to switch on the single outputs viathe web interface. So each output can be checked without an external control.Easy ConfigurationAn user friendly configuration via web browser allows a fast and uncomplicated settingof all parameters. No special software is necessary, a standard web browser is enough.So, anytime the configuration is possible from PC, Smartphone or tablet.For an easy setting of the IP we provide the IP-Configurator as PC-Tool or Android-App for free.The network settings can be leaved unchanged and the IP can be configured without any problems.Firmware-Update-FunctionTo use future functions the ArtNet-LED-Dimmer CC4 offers a Firmware-Update-Function.The update can be started from a web browser, so no direct access to the device is necessary! Specifications Power supply:9-48V DC / 150mA@12V; 80mA/24V; 60mA@48V (Current consumption without LED-Driver) Ethernet:RJ45 (Art-Net™) DMX:3pin screw terminal DMX-Kanäle4 Channels (without master dimmer) 5 Channels (with master dimmer) DMX-FAIL:HOLD / ALL OFF / ALL ON Masterdimmer:activatable Output:4 current regulated output (8 bit controlled) (Output current depends on the LED driver module) PWM-Frequency:244 Hz USB connector:5V / 500mA for power supply external devices (e.g. WLAN-Bridge) Dimensions:99mm x 82mm Constant current modules:Constant current LED-Driver LDD-H(available as an accessory)Constant current LED-Driver NLDD-H Product DownloadsArtNet-LED-Dimmer CC4Bedienungsanleitung ArtNet-LED-Dimmer CC4User Manual ArtNet-LED-Dimmer CC4Firmware
ArtNet-LED-Dimmer 4 MK2The ArtNet-LED-Dimmer 4 MK2 is a compact LED-Dimmer controlling 4 separate LED outputs.These can be used for RGB+W or for single, single-colored LED-Stripes.The LEDs connection occurs via removable screw clamps.Via a RJ45-Connection occurs the connection to Ethernet (ArtNet net work).High Power OutputsThe outputs can drive a current of 10A.So, a load of maximum 120W (12V) or rather 240W (24V) results.10 user defined color changes/programsThe ArtNet-LED-Dimmer 4 MK2 offers more than 10 user defined color changes.These can be created via the web browser or the Android App „DMX4ALL Remote“.Disengageable LED-Display The LED-Displays at the ArtNet-LED-Dimmer 4 MK2 are disengageablevia ArtNet-Command (AcLedMute) or time-controlled.Most of all this is very helpful on stages to avoid disturbing “light-points”.Easy configuration A user friendly configuration via a web browser allows a fast and uncomplicated settingof all parameters. No special software is necessary, a standard web browser is enough.So, the configuration is possible every time from PC, Smartphone or tablet.For an easy setting of the IP we provide the IP-Configurator as PC-Tool or Android-App for free.The network settings can be leaved unchanged and the IP can be configured without any problems.Controlling via browser or App with Colorwheel / Slider The output control is available via an integrated web interface with a Colorwheel.Alternatively each other app which supports Art-Net can be used.Firmware-Update-Function To use future functions the ArtNet-LED-Dimmer 4 MK2 offers a Firmware-Update-Function.This can be started from a web browser, so that no direct access to the device is necessary!DMX4ALL Communication-Interface The ArtNet-LED-Dimmer 4 MK2 has a further TCP-Communication-Interface.This interface uses the DMX4ALL-Commands with TCP-Commands via TCP-Packages to Port 10001. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications Power supply:12-24V DC / 100mA (=LED voltage) LED voltage:12-24V DC (no AC voltage !) Connection:RJ45 Ethernet LED-connection:R/G/B + W screw terminals max. 10A with common anode (+) USB-connection:5V / 500mA for power supply external devices (e.g. WLAN-bridge) PWM-Frequency:250 Hz Dimensions:115mm x 54mm x 23mm DMX4ALL Commands Protocol:Art-Net 3 ™ DMX4ALL Commands Product DownloadsArtNet-LED Dimmer 4 MK2Bedienungsanleitung ArtNet-LED Dimmer 4 MK2User Manual ArtNet-LED Dimmer 4 MK2Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note
DMX-LED-Dimmer X9HRThe DMX-LED-Dimmer X9HR is especially designed for controlling RGB LED-Stripes.The dimmer has 9 High-Resolution PWM-Outputs (3xRGB) independently controllable via DMX.9 OutputsThe DMX-LED-Dimmer X9HR has 9 outputs to which LEDs can be connected.All outputs are designed in the same way so single color, RGB or RGBW LEDs can be connected.High Power OutputsThe outputs can drive a current up to 10A.So it is possible to connect a maximum load of 120W (12V) / 240W (24V)0% bis 100% dimmableThe connected LEDs are dimmed by PWM from 0% to 100%.For voltages from 12V up to 24VThe DMX-LED-Dimmer X9HR operates with supply voltages from 12V up to 24V. The LED voltage canbe different per output so that one DMX-LED-Dimmer X9HR can control different LED systems.DMX-FAIL FunctionAn adjustable DMX FAIL function offers the option to get in case of lostDMX signal the current state (HOLD) or assuming a preset value.DMX-Master DimmerOptionally, another DMX channel can be activated as Master Dimmer (all outputs)or one master dimmer per RGB group. The global master dimmer is fixed atDMX address 1 and can be used as system master dimmer.Adjustable dimming curveThe dimming curves can be configured individually for each output.RDM supportThe DMX-LED-Dimmer X9HR allows configuration by RDM via DMX.SubDevice-ModeIn SubDevice mode, each output is assigned its own DMX address and DMX FAIL behavior via RDM.LED-State DisplayThe DMX state is indicated via the LED status.Firmware-Update-FunctionTo use future functions, the DMX-LED-Dimmer X9HR offers a firmware update function.Top hat rail housing availableThe top-hat rail housing 1050 is available as accessory for the DMX-LED-Dimmer X9HR. Specifications Power supply:7-24V DC 80mA@12V / 100mA@24V (without load) LED voltage:7-24V DC (no AC voltage !) Protocol:DMX512 RDM DMX channels:9 channels with 8Bit-Mode 18 channels with 16Bit-Mode + optional Master-Dimmer-Channels Masterdimmer:None / Global / RGB / System DMX-FAIL:Hold / 0%-100% 8bit ModePWM-Frequency 488 Hz with LookUp-Table 2 kHz or 4 kHz without LookUp-Table 16bit ModePWM-Frequency 488 Hz without LookUp-Table Output:9 PWM-signal common supply voltage anode (PLUS) Output current:max. 10A each output In sum 90A with all GND connections Output power:9x 120W (12V) / 9x 240W (24V) Energy-Save output:Control output for switching off the load power supply units StandAlone function:9 internal StandAlone programs Connections:Screw terminals Dimensions:99mm x 82 mm Produkt DownloadsDMX-LED-Dimmer X9HRBedienungsanleitung DMX-LED-Dimmer X9HRUser Manual DMX-LED-Dimmer X9HRUSB Driver (ab V2.2)Version 6.0.0.0 DMX-LED-Dimmer X9HRFirmware (ab V2.2) Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual
<table width="800" cellspacing="1" cellpadding="1"> <tr> <td><img src="https://www.media.dmx4all.store/images/kategorie-head.png" align="absmiddle"><span style="font-size: large;"><strong> DMX-LED-Dimmer BB4</strong></span></td> </tr></table><br>The DMX-LED-Dimmer BB4 is designed to control LEDs, which operate with<br>constant current and works with up to 24V of the LED voltage.<br><br><br><strong>Regulable output current</strong><br>The DMX LED Dimmer BB4 has 4 outputs where the LEDs are operated with a<br>current of 0 to 330mA-1500mA. The level of the output current can be adjusted via DMX.<br><br><strong>Voltages up to 24V</strong><br>The DMX-LED-Dimmer BB4 works with supply voltages up to 24V.<br><br><strong>DMX-FAIL Function</strong><br>An adjustable DMX FAIL function offers the option to hold the current state (HOLD)<br>or to take a preset value in case of a failed DMX signal.<br><br><strong>DMX-Master-Dimmer</strong><br>The DMX-LED-Dimmer BB4 has various Master Dimmers.<br><br><strong>Up to 1024 brightness steps</strong><br>Each output driver has a resolution of 1024 steps in which the output<br>current is controlled. The special driver design allows a constant current<br>which is not modulated by a PWM for the dimming process.<br><br><strong>Two adjustable operation modes</strong><br>Control with 2 DMX channels per output, the first DMX channel allows<br>coarse control and the second DMX channel allows fine control.<br><br><strong>Settable dim curve</strong><br>The dimming curves are freely configurable for each output.<br><br><strong>RDM support</strong><br>The DMX LED dimmer X9HR allows configuration via RDM over DMX.<br><br><strong>LED-State-Display</strong><br>The integrated multifunctional display shows the current status of the device.<br><br><strong>Suitable for top hat rail mounting</strong><br>The top-hat rail housing 1050 is available as optional accessory for the DMX-LED-Dimmer BB4.<br><br><br><img class="dmxmadein" src="https://www.media.dmx4all.store/images/made-in-germany.png" border="0"><br><br><br><!-- Specifications --><table width="800" cellspacing="1" cellpadding="1"> <tr> <td><img src="https://www.media.dmx4all.store/images/kategorie-head.png" border="0" align="absmiddle"><span style="font-size: large;"><strong> ArtNet Player 4</strong></span></td> </tr></table><table border="0" cellspacing="1" cellpadding="1"> <tr> <td width="300"> </td> <td width="500"> </td> </tr> <tr> <td>Power supply:</td> <td>8-24V DC (maximum 26V)</td> </tr> <tr> <td> </td> <td>50mA (without connected load)</td> </tr> <tr> <td> </td> <td> </td> </tr> <tr> <td>Drop voltage:</td> <td>max. 2V</td> </tr> <tr> <td> </td> <td> </td> </tr> <tr> <td>Output current:</td> <td>4x 0 – settable output current (330mA – 1500mA)</td> </tr> <tr> <td> </td> <td>Sustained short circuit / 1024 steps at each output</td> </tr> <tr> <td> </td> <td> </td> </tr> <tr> <td>Protokoll:</td> <td>DMX512</td> </tr> <tr> <td> </td> <td>RDM</td> </tr> <tr> <td> </td> <td> </td> </tr> <tr> <td>DMX channels:</td> <td>4 channels with 8Bit control and Lookup table</td> </tr> <tr> <td> </td> <td>8 channels with 10Bit control</td> </tr> <tr> <td> </td> <td> </td> </tr> <tr> <td>DMX-FAIL:</td> <td>Hold / 0%-100%</td> </tr> <tr> <td> </td> <td> </td> </tr> <tr> <td>Masterdimmer:</td> <td>Kein / Global / System</td> </tr> <tr> <td> </td> <td> </td> </tr> <tr> <td>PWM-Frequency:</td> <td>no PWM on output</td> </tr> <tr> <td> </td> <td> </td> </tr> <tr> <td>StandAlone-Function:</td> <td>9 internal StandAlone programs</td> </tr> <tr> <td> </td> <td>Switching on individual outputs</td> </tr> <tr> <td> </td> <td> </td> </tr> <tr> <td>Operation temperature:</td> <td>0°C up to +45°C</td> </tr> <tr> <td> </td> <td>Thermal overload protection per output</td> </tr> <tr> <td> </td> <td> </td> </tr> <tr> <td>Connection:</td> <td>Screw terminals</td> </tr> <tr> <td> </td> <td> </td> </tr> <tr> <td>Dimensions:</td> <td>99mm x 82mm x 47mm</td> </tr></table><br><!-- Produkt Downloads --><table width="800" cellspacing="1" cellpadding="1"> <tr> <td><img src="https://www.media.dmx4all.store/images/kategorie-head.png" align="absmiddle"><span style="font-size: large;"><strong> Product Downloads</strong></span></td> </tr></table><div id="dmx4all-buttons"> <a class="document-button" onfocus="this.blur()" href="https://www.dmx4all.de/download/manuals_german/dmx_led_dimmer_bb4_mk2_german.pdf" target="_blank">DMX-LED-Dimmer BB4<br> <span><span class="german-lang">Bedienungsanleitung</span></span></a> <br> <a class="document-button" onfocus="this.blur()" href="https://www.dmx4all.de/download/manuals_english/dmx_led_dimmer_bb4_mk2_english.pdf" target="_blank">DMX-LED-Dimmer BB4<br> <span><span class="english-lang">User Manual</span></span></a></div>
ArtNet-LED-Dimmer 4 MK2+The ArtNet-LED-Dimmer 4 MK2 is a compact LED-Dimmer controlling 4 separate LED outputs.These can be used for RGB+W or for single, single-colored LED-Stripes.The LEDs connection occurs via removable screw clamps.Via a RJ45-Connection occurs the connection to Ethernet (ArtNet net work).High Power OutputsThe outputs can drive a current of 10A.So, a load of maximum 120W (12V) or rather 240W (24V) results.10 user defined color changes/programsThe ArtNet-LED-Dimmer 4 MK2 offers more than 10 user defined color changes.These can be created via the web browser or the Android App „DMX4ALL Remote“.Disengageable LED-Display The LED-Displays at the ArtNet-LED-Dimmer 4 MK2 are disengageablevia ArtNet-Command (AcLedMute) or time-controlled.Most of all this is very helpful on stages to avoid disturbing “light-points”.Easy configuration A user friendly configuration via a web browser allows a fast and uncomplicated settingof all parameters. No special software is necessary, a standard web browser is enough.So, the configuration is possible every time from PC, Smartphone or tablet.For an easy setting of the IP we provide the IP-Configurator as PC-Tool or Android-App for free.The network settings can be leaved unchanged and the IP can be configured without any problems.Controlling via browser or App with Colorwheel / Slider The output control is available via an integrated web interface with a Colorwheel.Alternatively each other app which supports Art-Net can be used.High quality and compact design The ArtNet-LED-Dimmer 4+ MK2 is manufactured with removable clamps.Furthermore, the ArtNet LED Dimmer 4+ MK2 is mounted in a compact aluminum housing.Firmware-Update-Function To use future functions the ArtNet-LED-Dimmer 4 MK2 offers a Firmware-Update-Function.This can be started from a web browser, so that no direct access to the device is necessary!DMX4ALL Communication-Interface The ArtNet-LED-Dimmer 4 MK2 has a further TCP-Communication-Interface.This interface uses the DMX4ALL-Commands with TCP-Commands via TCP-Packages to Port 10001. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications Power supply:12-24V DC / 100mA (=LED voltage) LED voltage:12-24V DC (no AC voltage !) Connection:RJ45 Ethernet LED-connection:R/G/B + W screw terminals max. 10A with common anode (+) USB-connection:5V / 500mA for power supply external devices (e.g. WLAN-bridge) PWM-Frequency:250 Hz Dimensions:115mm x 74mm x 23mm Protocol:Art-Net 3 ™ DMX4ALL Commands Product DownloadsArtNet-LED Dimmer 4 MK2+Bedienungsanleitung ArtNet-LED Dimmer 4 MK2+User Manual ArtNet-LED Dimmer 4 MK2+Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note
DMX-LED-Dimmer X9HR+The DMX-LED-Dimmer X9HR+ is especially designed for controlling RGB LED-Stripes.The dimmer has 9 High-Resolution PWM-Outputs (3xRGB) independently controllable via DMX.9 OutputsThe DMX-LED-Dimmer X9HR+ has 9 outputs to which LEDs can be connected.All outputs are designed in the same way so single color, RGB or RGBW LEDs can be connected.High Power OutputsThe outputs can drive a current up to 10A.So it is possible to connect a maximum load of 120W (12V) / 240W (24V).0% to 100% dimmableThe connected LEDs are dimmed by PWM from 0% to 100%.For voltages from 12V up to 24VThe DMX-LED-Dimmer X9HR+ operates with supply voltages from 12V up to 24V.The LED voltage can be different per output so that one DMX-LED-Dimmer X9HR can control different LED systems.DMX-FAIL FunctionAn adjustable DMX FAIL function offers the option to get in case of lost DMX signal thecurrent state (HOLD) or to adopt a predefined value if the DMX signal fails.DMX-Master DimmerOptionally, another DMX channel can be activated as Master Dimmer (all outputs) orone master dimmer per RGB group. The global master dimmer is fixed at DMX address 1 andcan be used as system master dimmer.Adjustable dimming curveThe dimming curves can be configured individually for each output.RDM supportThe DMX-LED-Dimmer X9HR+ allows configuration by RDM via DMX.SubDevice-ModeWithin the SubDevice Mode, each output is assigned its own DMX address and DMX FAIL behavior via RDM.Touch-ControlThe DMX-LED-Dimmer X9HR+ is designed with 3 touch fields for operation and a 7-segment display.RGB-Status displayVia a RGB status display the DMX reception is shown.Firmware-Update-FunctionTo use future functions, the DMX-LED-Dimmer X9HR+ offers a firmware update function. Specifications Power supply:7-24V DC 100mA@12V / 150mA@24V (without load) LED voltage:7-24V DC (no AC voltage !) Protocol:DMX512 RDM DMX channels:9 channels with 8Bit-controlling and LookUp-Table 18 channels with 16Bit-controlling + optional Master-Dimmer-Channels Output:9 PWM-signal common supply voltage anode (PLUS) 8bit ModePWM-Frequency 488 Hz with LookUp-Table 2 kHz or 4 kHz without LookUp-Table 16bit ModePWM-Frequency 488 Hz without LookUp-Table Masterdimmer:None / Global / RGB / System DMX-FAIL:Hold / 0%-100% Output current:max. 10A each output In sum 90A with all GND connections Output power:9x 120W (12V) / 9x 240W (24V) CTRL output:Control output for switching off the load power supply units (Energy-Save) StandAlone function:9 internal StandAlone programs Display:7 segment display RGB LED TOUCH-Control:3 touch buttons Connectors:Screw terminals Dimensions:105mm x 90mm x 60mm Produkt DownloadsDMX-LED-Dimmer X9 HR+Bedienungsanleitung DMX-LED-Dimmer X9 HR+User Manual DMX-LED-Dimmer X9 HR+USB DriverVersion 6.0.0.0 DMX-LED-Dimmer X9 HR+Firmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual
ArtNet-LED-Dimmer 6The ArtNet Dimmer 6 is a compact LED-Dimmer with 6 seperate LED-outputs.These can be used for RGB/ RGB+W / RGB + W WW or for single color stripes.High Power OutputsEach output can drive a current up to 10A.So it is possible to connect a maximum load on ecah output of 120W (12V) or 240W (24V).16 Million ColorsWith the RGB-LED-Stripe up to 16 million colours can be adjusted.By using an additional single color white stripe it is possible to makecolor neutral illuminations or pastel colours.NEW: User Configurable Color ProgrammsThe ArtNet-LED Dimmer 6 has also 10 user configurable color programms whichcan be defined via the webbrowsr or the Android App „DMX4ALL Remote“.User-friendly ConfigurationA user-friendly configuration via a web browser allows a fast and uncomplicated setting of all parameters.Power Supply for WiFi BridgeIn addition the ArtNet-Dimmer 6 has a USB connector providing a power supplywith 5V/500mA for external devices e.x. a WiFi-bridge.As WLAN-bridge we suggest: TP-Link TL-WR702N or TP-Link TL-WR802NControll with AppThe controll of this device is possible by using the free Android-App "DMX Remote".Firmware-Update-FunctionIn order to take advantage of future features, the ArtNet-LED-Dimmer 6 has a firmware update function.This can be launched from the browser so that no access to the device is necessary!DMX4ALL-Command interfaceThe ArtNet-LED-Dimmer 6 has another TCP communication interface.This interface uses the DMX4ALL-commands via TCP packets. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications Power supply:12-24V DC / 100mA LED voltage:12-24V DC (no AC voltage !) Connection:RJ45 Ethernet LED-connection:6 outputs max. 10A per output (in total 60A) common anode (+) USB-connection:5V / 500mA for power supply external devices (e.g. WLAN-bridge) PWM-Frequency:250Hz / 500Hz / 1000Hz / 2000 Hz Dimensions:64,2 x 82 x 20 mm Protocol:Art-Net 3 ™ DMX4ALL Commands Product DownloadsArtNet-LED Dimmer 6Bedienungsanleitung ArtNet-LED Dimmer 6User Manual ArtNet-LED Dimmer 6Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note DMX4ALL CommandsDMX4ALL Commands for Devolopment
DMX-LED-Dimmer X9HRXThe DMX LED Dimmer X9HRX is a 9-channel LED driver with 16-bit grayscale adaptive pulse density modulation (APDM)and a high output frequency of up to 8kHz at the same time.Thanks to the special APDM technology in combination with the optimized 48V LED drivers,the DMX LED dimmer X9HRX is perfectly suited for controlling RGB, RGBW or even single-color W stripes.9 OutputsThe DMX-LED-Dimmer X9HRX has 9 outputs to which LEDs can be connected.All outputs are designed in the same way so single color, RGB or RGBW LEDs can be connected.High Power OutputsThe outputs can drive a current up to 10A. So it is possible to connect a maximum loadof 120W (12V) / 240W (24V) / 240W (48V).High efficiencyThe 48V LED drivers are designed to allow the DMX LED Dimmer X9HRXto operate without active cooling (no fan).0% up to 100% dimmableThe connected LEDs are dimmed by APDM from 0% to 100%.For voltages from 12V up to 48VThe DMX-LED-Dimmer X9HRX operates with supply voltages from 12V up to 48V.The LED voltage can be different per output so that one DMX-LED-Dimmer X9HRX can control different LED systems.DMX-FAIL FunctionAn adjustable DMX FAIL function offers the option to get in case of loss DMX signalthe current state (HOLD) or predefined a preset value.DMX-Master DimmerOptionally, another DMX channel can be activated as Master Dimmer (all outputs)or one master dimmer per RGB/RGBW group.Adjustable Output FrequencyThe output frequency at the LED outputs can be adjusted between 500Hz and 8000Hz via RDM.Adjustable Dimming CurveThe dimming curves can be configured individually for each output.RDM SupportThe DMX-LED-Dimmer X9HRX allows configuration by RDM via DMX.Free RDM-SoftwareTo set the parameters via RDM, our free RDM Configurator software is availableto download from our website www.dmx4all.de.SubDevice-ModeIn SubDevice mode, each output is assigned its own DMX address and DMX FAIL behavior via RDM.RGB-Status-DisplayThe device status is shown via the RGB status display.Firmware-Update-FunctionIn order to be able to use future functions, the DMX-LED-Dimmer X9HRX offersa firmware update function both via USB and RDM.Top hat rail housing availableThe top-hat rail housing 1050 is available as accessory for the DMX-LED-Dimmer X9HRXand therefore ideally suited for switch cabinet installation. Specifications Power supply:12-48V DC 80mA@12V / 100mA@24V (without load) LED voltage:12-48V DC (no AC voltage !) Protocol:DMX512 RDM DMX channels:9 channels with 8Bit-controlling and Curve-Definition 18 channels with 16Bit-Mode + optional Master-Dimmer-Channels DMX-FAIL:Hold / 0%-100% Output:9 PWM-signal with 16Bit-resolution and APDM (Adaptive Pulse Density Modulation) common supply voltage Output current:max. 10A each output In sum 90A with all GND connections Output power:9x 120W (12V) / 9x 240W (24V) / 9x 240W (48V) Masterdimmer:None / Global / RGB / RGBW PWM frequency:500Hz / 1kHz / 2kHz / 4kHz / 8kHz CTRL Output:Control output for switching off the load power supply units (Energy-Save) StandAlone function:9 internal Stand-Alone programs Display:RGB LED Connections:Screw terminals Dimensions:99mm x 82mm Produkt DownloadsDMX-LED-Dimmer X9HRXBedienungsanleitung DMX-LED-Dimmer X9HRXUser Manual DMX-LED-Dimmer X9HRXUSB DriverVersion 6.0.0.0 DMX-LED-Dimmer X9HRXFirmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual
DMX-LED-Dimmer X9HRX+The DMX LED Dimmer X9HRX+ is a 9-channel LED driver with 16-bit grayscale adaptive pulse density modulation (APDM)and a high output frequency of up to 8kHz at the same time.Thanks to the special APDM technology in combination with the optimized 48V LED drivers,the DMX LED dimmer X9HRX+ is perfectly suited for controlling RGB, RGBW or even single-color W stripes.9 OutputsThe DMX-LED-Dimmer X9HRX+ has 9 outputs to which LEDs can be connected.All outputs are designed in the same way so single color, RGB or RGBW LEDs can be connected.High Power OutputsThe outputs can drive a current up to 10A. So it is possible to connect a maximum loadof 120W (12V) / 240W (24V) / 240W (48V).High efficiencyThe 48V LED drivers are designed to allow the DMX LED Dimmer X9HRX+to operate without active cooling (no fan).0% up to 100% dimmableThe connected LEDs are dimmed by APDM from 0% to 100%.For voltages from 12V up to 48VThe DMX-LED-Dimmer X9HRX+ operates with supply voltages from 12V up to 48V.The LED voltage can be different per output so that one DMX-LED-Dimmer X9HRX+ can control different LED systems.DMX-FAIL FunctionAn adjustable DMX FAIL function offers the option to get in case of loss DMX signalthe current state (HOLD) or predefined a preset value.DMX-Master DimmerOptionally, another DMX channel can be activated as Master Dimmer (all outputs)or one master dimmer per RGB/RGBW group.Adjustable Output FrequencyThe output frequency at the LED outputs can be adjusted between 500Hz and 8000Hz via RDM.Adjustable Dimming CurveThe dimming curves can be configured individually for each output.RDM SupportThe DMX-LED-Dimmer X9HRX+ allows configuration by RDM via DMX.Free RDM-SoftwareTo set the parameters via RDM, our free RDM Configurator software is availableto download from our website www.dmx4all.de.SubDevice-ModeIn SubDevice mode, each output is assigned its own DMX address and DMX FAIL behavior via RDM.Touch-ControlThe DMX-LED-Dimmer X9HRX+ is designed with 3 touch fields for operation and a 7-segment display.RGB-Status-DisplayThe device status is shown via the RGB status display.Firmware-Update-FunctionIn order to be able to use future functions, the DMX-LED-Dimmer X9HRX+ offersa firmware update function both via USB and RDM. Specifications Power supply:12-48V DC 80mA@12V / 100mA@24V (without load) LED voltage:12-48V DC (no AC voltage !) Protocol:DMX512 RDM DMX channels:9 channels with 8Bit-controlling and Curve-Definition 18 channels with 16Bit-Mode + optional Master-Dimmer-Channels DMX-FAIL:Hold / 0%-100% Output:9 PWM-signal with 16Bit-resolution and APDM (Adaptive Pulse Density Modulation) common supply voltage Output current:max. 10A each output In sum 90A with all GND connections Output power:9x 120W (12V) / 9x 240W (24V) / 9x 240W (48V) Masterdimmer:None / Global / RGB / RGBW PWM frequency:500Hz / 1kHz / 2kHz / 4kHz / 8kHz CTRL Output:Control output for switching off the load power supply units (Energy-Save) StandAlone function:9 internal Stand-Alone programs Display:7 segment display RGB LED Connections:Screw terminals Dimensions:105mm x 90mm x 60mm Produkt DownloadsDMX-LED-Dimmer X9HRX+Bedienungsanleitung DMX-LED-Dimmer X9HRX+User Manual DMX-LED-Dimmer X9HRX+USB DriverVersion 6.0.0.0 DMX-LED-Dimmer X9HRX+Firmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual
ArtNet Multi PixxControlThe ArtNet Multi PixxControl is a very compact LED pixel controller for digital LED stripes. With a standard ArtNet (DMX over Ethernet)the combination to standard ethernet and WiFi components is possible.Selectable LED controllerThe used LED chip inside the connected digital LED Stripe is selected.Thus, the use of various digital LED Stripes is possible, for example:MagiarLED III flex, MagiarLED II flex, DycoLED, TM1804, TM1812, TM1814, WS2801, WS2811, LPD8803, LPD8806, UCS1903,UCS1912, UCS2912, APA-101, APA-102, APA-104, INK1002, INK1003, SK6812, SK9822, LPD1886 8Bit, LPD1886 12BitAdjustable color sequenceThe RGB color sequence is adjustable which allows universal usage.In addition, you can choose a single color option, in which each pixel has only one channel.Adjustable pixel groupArtNet Multi PixxControl supports pixel groups with an adjustable length.Each pixel group behaves as a single pixel on the 3 DMX channels is controlled.Thus, in extended installations save channels.Muteable LED indicatorThe LED indicators on the ArtNet Multi PixxControl are muteable by ArtNet command (AcLedMute) or time-controlled.This is helpful to disturbing "points of light" especially on stages.Easy ConfigurationA user-friendly configuration via a web browser allows a fast and uncomplicated setting of all parameters.No special software is required, a normal web browser is sufficient. Thus, the configuration at any timefrom your PC, smartphone or tablet device.For easy setting of the IP-address, we provide the IP Configurator as a PC tool or Android app available for free.This allows you to leave the network settings unchanged and can easily configure the IP.High quality and compact designThe ArtNet Multi PixxControl is designed with a 4-pin Neutrik metal XLR connector inside a compact aluminum body.Use together with WiFi componentsIn conjunction with a WiFi-bridge the ArtNet Multi PixxControl can be integrated into standard WiFi networks.As WiFi-bridge we suggest: Netgear WNCE2001.Firmware-Update-FunctionIn order to take advantage of future features, the ArtNet Multi PixxControl has a firmware update function.This can be launched from the browser so that no access to the device is necessary!This Interface will be supported from:Madrix - LED Lighting Control SolutionsDMX-Configurator 4PIXX (V2.x)Jinx!or any other software with ArtNet-outputWe suggest the software MADRIX® - LED Lighting Control Solutions for an easy and optimal controlling via ArtNet. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications Power supply:5V with included power supply Connection:RJ45 Ethernet Neutrik® XLR4 USB Mini-B only for the power supply Protocol:Art-Net ™ (downward compatible) LED types:MagiarLED III flex / MagiarLED II flexmax. 2720 Pixel TM1804 / TM1812 / TM1829max. 1360 Pixel WS2801max. 1360 Pixel LPD8803max. 1360 Pixel DycoLED / LPD6803 / LPD1101 / APA-101max. 1360 Pixel APA102 / SK9822max. 2720 Pixel LPD1886 - 8Bit oder 12Bitmax. 1360 Pixel WS2811 / WS2812(B) / APA-104 / SK6812max. 1360 Pixel INK1002 / INK1003max. 1360 Pixel UCS1903 / / UCS 1912 / UCS2912max. 1360 Pixel UCS9812max. 850 Pixel DMX512max. 170 Pixel DMX1024max. 340 Pixel Gamma correction:in combination with LPD1886 - 12Bit, UCS9812 Color sequence:RGB adjustable / SingleColor red, green, blue, white RGBW with SK6812 / UCS2912 Pixel groups:adjustable, 1 - 10 Dimensions:75 x 26 x 35 mm Delivery includes::ArtNet Multi PixxControl 5V power supply 1m RJ45 network cable 1:1 Product DownloadsArtNet Multi PixxControlBedienungsanleitung ArtNet Multi PixxControlUser Manual ArtNet Multi PixxControlFirmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual IP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note Application NotesArtNet Multi PixxControl mit Jinx ansteuernAppNote Controlling ArtNet Multi PixxControl with JinxAppNote
ArtNet PixxControl PX1The ArtNet PixxControl PX1 is a compact ArtNet (DMX over Ethernet) interface,which converts ArtNet directly to a control signals for several digital LEDs.For the ArtNet network connection a standard RJ45 network connector is used.Output with selectable pixel data protocolThe ArtNet PixxControl PX1 has one configurable output. The pixel data protocol (control signal)for different LED pixel types and other parameters can be selected separately.Adjustable color sequenceThe RGB color sequence is adjustable, which allows flexible uses.It is also possible to control RGBW pixels. Furthermore, a SingleColor optioncan be selected, where each pixel needs only one channel.Adjustable pixel groupThe ArtNet PixxControl PX1 supports pixel groups with adjustable length.Each pixel group behaves like a single pixel controlled via 3 DMX channels (RGB)or 4 DMX channels (RGBW). That reduces channels in installations with many pixels.RGB-LED-DisplayThe RGB LED displays the current operation status of the ArtNet PixxControl PX1 clearly.Muteable LED-DisplayThe LED displays on the ArtNet PixxControl PX1 can be switched off via ArtNet command (AcLedMute),RDM (DISPLAY_LEVEL) or time-controlled. This is especially helpful on stages to avoid disturbing "light spots".RDMThe important parameters such as the pixel type, the pixel group size or the color sequencecan be set individually for both data outputs via RDM.Free RDM-SoftwareTo set parameters via RDM our free software RDM-Configurator is available as download on our website www.dmx4all.de .DMX4ALL Communication-InterfaceThe ArtNet PixxControl PX1 has another communication interface which uses the DMX4ALL commands via TCP or UDP.Easy ConfigurationA user-friendly configuration via a web browser allows a quick and uncomplicated setting of all parameters.No special software is needed a normal web browser is enough. This means that the configuration is possibleat any time from a PC, smartphone or tablet.To set the IP address easily, the IP Configurator is offered as free download as PC tool or Android app.This allows the network settings of the PC or Android device to remain unchanged in order to configurethe IP of the ArtNet PixxControl PX1.Combinable with WiFi componentsThe ArtNet PixxControl PX1 can be integrated into WLAN networks in combination with a WLAN bridge.Firmware update functionTo use future functions, the ArtNet PixxControl PX1 offers a firmware update function.The update can be started from a web browser, so no access to the device is necessary!Top hat rail housing availableThe top-hat rail housing 350 or 350flat is available as accessory for the ArtNet PixxControl PX1. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications Power supply:8-24V DC (100mA@12V; 50mA@24V) Connection:RJ45 Ethernet 5pin screw terminal Protocol:Art-Net™ 4 (downward compatible) RDM LED types:APA-101, APA-104, APA-102,max. 1360 pixel DycoLED PB3, DycoLED PB5, GS8208, INK1002, INK1003, LC8808, LPD1101, LPD8803, LPD6803, LPD8806, LPD1886 8Bit, LPD1886 12Bit (8Bit controlled), SK6812, SK6822, SK9822, SM16703, TM1804, TM1812, TM1814, TM1829, TM1934, UCS1903, UCS1912, UCS2903, UCS2912, WS2801, WS2811, WS2812, WS2812B, WS2813, WS2815, WS2818, WS2821 LPD1886 12Bit (12Bit controlled),max. 680 pixel UCS9812 (8Bit controlled), UCS9812 (16Bit controlled) Color Sequence:RGB selectable / RGBW SingleColor white, red, green, blue Pixel groups:1 up to 127 pixel / all Gamma correction:Selectable for LPD1886 12Bit (8Bit controlled), UCS9812 (8Bit controlled) LED-Display:RGB Status-LED Ethernet-Status-LEDs yellow and green Dimensions:29,2mm x 82mm Product DownloadsArtNet PixxControl PX1Bedienungsanleitung ArtNet PixxControl PX1User Manual ArtNet PixxControl PX1Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note RDM Configurator (ArtNet Produkte)Windows 32 & 64bit RDM ConfiguratorBedienungsanleitung RDM ConfiguratorUser Manual
ArtNet PixxControl PX2The ArtNet PixxControl PX2 is a compact ArtNet (DMX over Ethernet) interface,which converts ArtNet directly to two independent control signals for several digital LEDs.For the ArtNet network connection a standard RJ45 network connector is used.Two independent outputs with selectable pixel data protocolThe ArtNet PixxControl PX2 has two outputs, independently configurable. The pixel data protocol (control signal)for different LED pixel types and other parameters can be selected separately for each output.Selectable color sequenceThe RGB color sequence is adjustable, which allows flexible uses. It is also possible to control RGBW pixels.Furthermore, a SingleColor option can be selected, where each pixel needs only one channel.Adjustable pixel groupThe ArtNet PixxControl PX2 supports pixel groups with adjustable length.Each pixel group behaves like a single pixel controlled via 3 DMX channels (RGB) or 4 DMX channels (RGBW).That reduces channels in installations with many pixels.Voltage monitoringBoth data outputs are equipped with a voltage input, which allows monitoring of the LED voltage supplyvia the network. The voltage values can be called via RDM or with the web interface.CTRL OutputThe CTRL output can be used to switch off the power supply for the LED installation as soon as theArtNet PixxControl PX2 does not receive any data after 5 minutes or the connected digital LEDs don’t light up.RGB-LED-DisplayThe RGB LED displays the current operation status of the ArtNet PixxControl PX2 clearly.Mute able LED-DisplayThe LED displays on the ArtNet PixxControl PX2 can be switched off via ArtNet command (AcLedMute),RDM (DISPLAY_LEVEL) or time-controlled. This is especially helpful on stages to avoid disturbing "light spots".Easy ConfigurationA user-friendly configuration via a web browser allows quick and uncomplicated setting of all parameters.No special software is needed a normal web browser is enough. This means that the configuration ispossible at any time from a PC, smartphone or tablet.To set the IP address easily, the IP Configurator is offered as free download as a PC tool or Android app.This allows the network settings of the PC or Android device to remain unchanged in order to configurethe IP of the ArtNet PixxControl PX2.RDMThe important parameters such as the pixel type, the pixel group size or the color sequence can be set individuallyfor both data outputs via RDM. Also the voltage values of the LED power supply can be called via RDM.Free RDM-SoftwareTo set parameters via RDM our free software RDM-Configurator is available as download on our website www.dmx4all.de .DMX4ALL Communication-InterfaceThe ArtNet PixxControl PX2 has another communication interface which uses the DMX4ALL commands via TCP or UDP.Combinable with WiFi componentsThe ArtNet PixxControl PX2 can be integrated into WLAN networks in combination with a WLAN bridge.Firmware update functionTo use future functions, the ArtNet PixxControl PX2 offers a firmware update function.The update can be started from a web browser, so no access to the device is necessary!Top-hat rail housing availableThe top-hat rail housing 700 is available as accessory for the ArtNet PixxControl PX2. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications Power supply:8-24V DC (150mA@12V; 100mA@24V) Connection:RJ45 Ethernet 12pin screw terminal Ethernet:10 Mbit/s | 100 Mbit/s Protocol:Art-Net™ 4 (downward compatible) RDM LED types:APA-101, APA-104, APA-102,max. 1360 pixel per output DycoLED PB3, DycoLED PB5, GS8208, INK1002, INK1003, LC8808, LPD1101, LPD8803, LPD6803, LPD8806, LPD1886 8Bit, LPD1886 12Bit (8Bit controlled), SK6812, SK6822, SK9822, SM16703, TM1804, TM1812, TM1814, TM1829, TM1934, UCS1903, UCS1912, UCS2903, UCS2912, WS2801, WS2811, WS2812, WS2812B, WS2813, WS2815, WS2818, WS2821 LPD1886 12Bit (12Bit controlled),max. 680 pixel per output UCS9812 (8Bit controlled), UCS9812 (16Bit controlled) DMX512max. 512 DMX channels per output Color Sequence:RGB selectable / RGBW SingleColor white, red, green, blue Pixel groups:1 up to 127 pixel / all Gamma correction:Selectable for LPD1886 12Bit (8Bit controlled), UCS9812 (8Bit controlled) LED-Display:RGB Status-LED Ethernet-Status-LEDs yellow and green Dimensions:64,2mm x 82mm Product DownloadsArtNet PixxControl PX2Bedienungsanleitung ArtNet PixxControl PX2User Manual ArtNet PixxControl PX2Firmware
ArtNet-DMX Mux16The ArtNet-DMX Mux16 has 16 digital inputs which are given to a ArtNet and DMX output..Each input can act to one or more output channels and the mode is selectable.A user-friendly configuration by using the webinterface allows a fast and uncomplicated setting of all parameters.The firmware of the ArtNet-DMX Mux16 can be update easy over the network. Specifications Power supply:7-24V DC / 0,5A Ethernet:1x RJ45 DMX-OUT:1x 512 channels Inputs:16x Long Distance Digital Input Mode:Switch Button On Button Off Button On/Off Dimmer Up/Down Dimmer Up Dimmer Down Button On + Dimmer Up Button Off + Dimmer Down Button On/Off + Dimmer Up/Down Dimensions:99 x 82 x 20mm Product DownloadsArtNet-DMX Mux16Bedienungsanleitung ArtNet-DMX Mux16User Manual ArtNet-DMX Mux16Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note
ArtNet-DMX Mux24The ArtNet-DMX Mux24 has 16 digital inputs and 8 additional inputs which are adaptableanalog or digital. The output occurs via ArtNet and DMX. For each input the function (Mode) as well as the channels to control are adjustable. A user-friendly configuration via a web browser allows a fast an uncomplicatedsetting for all parameters. The firmware of the ArtNet-DMX Mux24 can be update easy over the network. Specifications Power supply:7-24V DC / 0,5A Ethernet:1x RJ45 DMX-OUT:1x 512 channels Inputs:16x Long Distance Digital Input 8x Analog Eingang or Long Distance Digital Eingang Mode:Switch Button On Button Off Button On/Off Dimmer Up/Down Dimmer Up Dimmer Down Button On + Dimmer Up Button Off + Dimmer Down Button On/Off + Dimmer Up/Down Analog 0-10V Analog 0-5V Analog 1-10V Timer:4 configureable timer Dimensions:99 x 82 x 20mm Product DownloadsArtNet-DMX Mux24Bedienungsanleitung ArtNet-DMX Mux24User Manual ArtNet-DMX Mux24Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note
ArtNet-LED-Dimmer 4 MK2+The ArtNet-LED-Dimmer 4 MK2 is a compact LED-Dimmer controlling 4 separate LED outputs.These can be used for RGB+W or for single, single-colored LED-Stripes.The LEDs connection occurs via removable screw clamps.Via a RJ45-Connection occurs the connection to Ethernet (ArtNet net work).High Power OutputsThe outputs can drive a current of 10A.So, a load of maximum 120W (12V) or rather 240W (24V) results.10 user defined color changes/programsThe ArtNet-LED-Dimmer 4 MK2 offers more than 10 user defined color changes.These can be created via the web browser or the Android App „DMX4ALL Remote“.Disengageable LED-Display The LED-Displays at the ArtNet-LED-Dimmer 4 MK2 are disengageablevia ArtNet-Command (AcLedMute) or time-controlled.Most of all this is very helpful on stages to avoid disturbing “light-points”.Easy configuration A user friendly configuration via a web browser allows a fast and uncomplicated settingof all parameters. No special software is necessary, a standard web browser is enough.So, the configuration is possible every time from PC, Smartphone or tablet.For an easy setting of the IP we provide the IP-Configurator as PC-Tool or Android-App for free.The network settings can be leaved unchanged and the IP can be configured without any problems.Controlling via browser or App with Colorwheel / Slider The output control is available via an integrated web interface with a Colorwheel.Alternatively each other app which supports Art-Net can be used.High quality and compact design The ArtNet-LED-Dimmer 4+ MK2 is manufactured with removable clamps.Furthermore, the ArtNet LED Dimmer 4+ MK2 is mounted in a compact aluminum housing.Firmware-Update-Function To use future functions the ArtNet-LED-Dimmer 4 MK2 offers a Firmware-Update-Function.This can be started from a web browser, so that no direct access to the device is necessary!DMX4ALL Communication-Interface The ArtNet-LED-Dimmer 4 MK2 has a further TCP-Communication-Interface.This interface uses the DMX4ALL-Commands with TCP-Commands via TCP-Packages to Port 10001. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications Power supply:12-24V DC / 100mA (=LED voltage) LED voltage:12-24V DC (no AC voltage !) Connection:RJ45 Ethernet LED-connection:R/G/B + W screw terminals max. 10A with common anode (+) USB-connection:5V / 500mA for power supply external devices (e.g. WLAN-bridge) PWM-Frequency:250 Hz Dimensions:115mm x 74mm x 23mm Protocol:Art-Net 3 ™ DMX4ALL Commands Product DownloadsArtNet-LED Dimmer 4 MK2+Bedienungsanleitung ArtNet-LED Dimmer 4 MK2+User Manual ArtNet-LED Dimmer 4 MK2+Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note
ArtNet-Relais/Analog 4The ArtNet Relais/Analog Interface 4 is designed for switching loads of several kinds.4 relay and 4 analog outputsFour potential free contacts with up to 8A switching power are available.Additional four analog outputs with 0-10V or 1-10V can be used to control systems with analog inputs.DMX or Art-NetThe ArtNet Relais/Analog Interface 4 can controlled by a DMX signal or by an Art-Net (DMX over Ethernet) signal.DMX-HOLD functionA DMX-HOLD function can be activated. Then, the state of the relay and analog outputs is hold after losing the DMX signal. User-friendly ConfigurationA user-friendly configuration via a web browser allows a fast and uncomplicated setting of all parameters.Power Supply for WiFi BridgeIn addition the ArtNet Relais/Analog Interface 4 has a USB connector providing a power supplywith 5V/500mA for external devices e.x. a WiFi-bridge.As WLAN-bridge we suggest: TP-Link TL-WR702N or TP-Link TL-WR802NControll with AppThe controll of this device is possible by using the free Android-App "DMX Remote".Firmware-Update-FunctionIn order to take advantage of future features, the ArtNet Relais/Analog Interface 4 has a firmware update function.This can be launched from the browser so that no access to the device is necessary!DMX4ALL-Command interfaceThe ArtNet Relais/Analog Interface 4 has another TCP communication interface.This interface uses the DMX4ALL-commands via TCP packets. Specifications Power supply:12-24V DC / 250mA Ethernet:RJ45 Input:4 up to 12 DMX-channels Output:4 switching contacts each max. 8A / 250V~ (165A/20ms Switch-on peak current) 4x analog output 0-10V / 1-10V DMX-FAIL:Hold / Off Connectors:screw terminals USB-connection:5V / 500mA for power supply external devices (e.g. WLAN-bridge) Dimensions:99 x 82mm Protocol:Art-Net ™ DMX4ALL Commands Product DownloadsArtNet-Relais/Analog Interface 4Bedienungsanleitung ArtNet-Relais/Analog Interface 4User Manual ArtNet-Relais/Analog Interface 4Firmware
Digital LED-Stripe RGB APA102 24BLThe digital LED-Stripe has 72 single controllable RGB-LED's (pixel) by a length of 3m (24 Pixel/m).There are running lights up to rainbow effects possible. Easy to install and perfect as striking decoration lighting! - easy separable between each LED - assembled with 72 intelligent RGB-SMD-LEDs- self-adhesive backside- LED-Stripe carrier in black- divided connection for power supply and data line - controlling e.g. with our ArtNet Multi PixxControl / MultiPixx DMX-Controller / NanoPixx DMX-Controller / NanoSD Player Specifications Spannungsversorgung:5V DC Power:max. 7,2 W/m LED Typ:SMD5050 RGB Number of Pixel:72 pices (24 Pixel/m) Brightness values:256 per colour LED view angle:120° LED-Controller:APA102 Length / Wide:3m / 12mm Carrier material:black / self-adhesive backside Connectors:Input: JST-SM3 female / DC-Connector Output: JST-SM3 male
Digital LED-Stripe RGB SK6812 30BLThe digital LED-Stripe has 150 single controllable RGB-LED's (pixel) by a length of 5m (30 Pixel/m).There are running lights up to rainbow effects possible. Easy to install and perfect as striking decoration lighting! - easy separable between each LED - assembled with 150 intelligent RGB-SMD-LEDs- self-adhesive backside- LED-Stripe carrier in black- divided connection for power supply and data line - controlling e.g. with our ArtNet Multi PixxControl / MultiPixx DMX-Controller / NanoPixx DMX-Controller / NanoSD Player- compatible with WS2811/WS2812/APA-104 Specifications Spannungsversorgung:5V DC Power:max. 9 W/m LED Typ:SMD5050 RGB Number of Pixel:150 pices (30 Pixel/m) Brightness values:256 per colour LED view angle:120° LED-Controller:SK6812 (with WS2811/WS2812/APA-104 compatible) Length / Wide:5m / 10mm Carrier material:black / self-adhesive backside Connectors:Input: JST-SM3 male / DC-Connector Output: JST-SM3 female
DMX PixxControl DRThe DMX PixxControl DR is especially designed for controlling digital LED-Stripes orPixel-Stripes via DMX.By controlling via DMX 170 Pixel (RGB) / 128 Pixel (RGBW) / 512 Pixel (single color) canbe controlled individually.Selectable LED-ChipThe used LED-Chip within the connected digital LED-Stripe is selectable.So, the usage with several digital LED-Stripes is possible.Adjustable color reproductionThe RGB-Color sequence is adjustable, allowing an universal application.SingleColor-OptionA SingleColor-Option is selectable in which each pixel occupies only one channel.So up to 512 pixel in one color can be controlled via one DMX-Universe.Adjustable pixel groupThe DMX PixxControl DR supports pixel groups with adjustable lengths.Each pixel group behaves like a single pixel which is controlled via3 DMX-Channels (for RGB). That economizes channels in longer installations.Easy ConfigurationAn easy configuration via RDM, USB via DMX-Configurator or DMX allowsthe setting of all parameters.Pixel-SequencerThe Pixel-Sequencer generates several effects.The settings can be made with only a few DMX channelsto fit the effects individually.RDM SupportThe DMX PixxControl DR allows configuration via RDM over DMX.TPM2-ProtocolThe DMX PixxControl DR also supports the TPM2 protocolvia the USB-Interface via Virtual Com Port (VCP).Firmware-Update-FunctionTo use future functions the DMX PixxControl DR offers a Firmware-Update-Function.Top-hat rail housing availableThe top-hat rail housing 350 or 350flat is available as accessory for the DMX PixxControl DR. Specifications Power supply:5 - 12V DC / 300mA@5V; 150mA@12V or via USB-Connection Input:DMX512 RDM Output:Digital control signal for up to 170 RGB-Pixel, single controlable 128 RGBW-Pixel, single controlable Supported LED types:APA101, APA102, APA104 DycoLED PB3, DycoLED PC5 GS8208 INK1002, INK1003 LPD6803, LPD6806, LPD8803 LPD1886 8Bit, LPD1886 12Bit SK6812, SK6822, SK9822 TM1804, TM1812, TM1814, TM1829 UCS1903, UCS1912, UCS2912, UCS9812 WS2801, WS2811, WS2812(B), WS2813 WS2815, WS2818 Color sequence:RGB (adjustable) SingleColor white SingleColor red SingleColor green SingleColor blue RGBW with UCS2912, SK6812, TM1814 Pixel groups:adjustable Max. Pixel count:RGB: 170 Pixel/Pixelgroups; RGBW: 128 Pixel/Pixelgroups SingleColor: 512 Pixel/Pixelgroups Dimensions:29,2mm x 82mm Product DownloadsDMX PixxControl DRBedienungsanleitung DMX PixxControl DRUser Manual DMX PixxControl DRUSB Driver 32 & 64bit - Version 6.0.0.0 DMX PixxControl DRFirmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual
