ArtNet-LED-Dimmer 4 MK2+

 DMX-Splitter 4The DMX-Splitter 4 is a compact DMX-Divider with one DMX-Input signal which providesthese at four galvanically isolated outputs.4 galvanically isolated outputsThe DMX-Splitter 4 is a compact DMX-Divider with one DMX-Input signal which providesthese at four galvanically isolated outputs.Extremely light constructionExtremely light DC/DC converters are used for galvanic isolation.Power supply via one power supply unitThe power supply occurs via one power supply unit.The voltage range is between 8V up to 24V.Compact design for top hat rail mountingThe DMX-Splitter 4 is suitable for installation in top hat rail mountingswith a width of 7cm due to its small size.LED-DisplayTwo LEDs show clearly the current operation mode.Top hat rail mounting availableSuitable for the DMX Splitter 4 the DIN rail housing 700 is available as accessory. Specifications  Power supply:8-24V DC (350mA@12V; 200mA@24V)  Input:512 channels  Output:4x 512 channels galvanically isolated  Connections:screw terminals  Dimensions:64,2mm x 82mm Product DownloadsDMX-Splitter 4Bedienungsanleitung DMX-Splitter 4User Manual

 ArtNet-LED-Dimmer 6The ArtNet Dimmer 6 is a compact LED-Dimmer with 6 seperate LED-outputs.These can be used for RGB/ RGB+W / RGB + W WW or for single color stripes.High Power OutputsEach output can drive a current up to 10A.So it is possible to connect a maximum load on ecah output of 120W (12V) or 240W (24V).16 Million ColorsWith the RGB-LED-Stripe up to 16 million colours can be adjusted.By using an additional single color white stripe it is possible to makecolor neutral illuminations or pastel colours.NEW: User Configurable Color ProgrammsThe ArtNet-LED Dimmer 6 has also 10 user configurable color programms whichcan be defined via the webbrowsr or the Android App „DMX4ALL Remote“.User-friendly ConfigurationA user-friendly configuration via a web browser allows a fast and uncomplicated setting of all parameters.Power Supply for WiFi BridgeIn addition the ArtNet-Dimmer 6 has a USB connector providing a power supplywith 5V/500mA for external devices e.x. a WiFi-bridge.As WLAN-bridge we suggest: TP-Link TL-WR702N or TP-Link TL-WR802NControll with AppThe controll of this device is possible by using the free Android-App "DMX Remote".Firmware-Update-FunctionIn order to take advantage of future features, the ArtNet-LED-Dimmer 6 has a firmware update function.This can be launched from the browser so that no access to the device is necessary!DMX4ALL-Command interfaceThe ArtNet-LED-Dimmer 6 has another TCP communication interface.This interface uses the DMX4ALL-commands via TCP packets. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:12-24V DC / 100mA  LED voltage:12-24V DC (no AC voltage !)  Connection:RJ45 Ethernet  LED-connection:6 outputs max. 10A per output (in total 60A) common anode (+)  USB-connection:5V / 500mA for power supply external devices (e.g. WLAN-bridge)  PWM-Frequency:250Hz / 500Hz / 1000Hz / 2000 Hz  Dimensions:64,2 x 82 x 20 mm  Protocol:Art-Net 3 ™ DMX4ALL Commands Product DownloadsArtNet-LED Dimmer 6Bedienungsanleitung ArtNet-LED Dimmer 6User Manual ArtNet-LED Dimmer 6Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note DMX4ALL CommandsDMX4ALL Commands for Devolopment

 DMX-LED-Dimmer CC4The DMX-LED-Dimmer CC4 is designed for controlling LEDs, which are operatedwith constant current and works with up to 48V DC.4 outputs with choose able constant current modulesDifferent constant current modules with different output currents are available for plug-on.The constant current modules are available as accessories and are not included in the scope of delivery.For voltages from 12V up to 24VThe DMX-LED-Dimmer CC4 works with supply voltages from 12V up to 24V DC.DMX FAIL-FunctionAn adjustable DMX FAIL function offers the option to hold the current state (HOLD)or to adopt a predefined value if the DMX signal fails.LED state displayThe DMX state is indicated via the LED status.DMX-MasterdimmerOptionally an additional DMX channel can be activated as master dimmer.0% up to 100% dimmableThe connected LEDs are dimmed from 0% up to 100% via PWM.RDM supportThe DMX-LED-Dimmer CC4 allows configuration by RDM via DMX.Top-hat rail housing availableThe top-hat rail housing 1050 is available as accessory for the DMX-LED-Dimmer X9HR.Together with the top-hat rail housing 1050, the interface is optimally suited for control cabinet installation. Specifications  Power supply:9-48V DC / 20mA@12V; 11mA/24V; 6mA@48V (without LED driver)  Output voltage:Depends on the constant current module used  Output current:Depends on the constant current module used  Protocol:DMX512 RDM  DMX-Channels:4 / 5 channels  DMX-FAIL:HOLD / ALL OFF / ALL ON  Masterdimmer:can be enabled  PWM-Frequency:244 Hz  Connections:Screw terminals  Dimensions:99mm x 82mm Product DownloadsDMX-LED-Dimmer CC4Bedienungsanleitung DMX-LED-Dimmer CC4User Manual

 DMX-Analog 0-10V 8-KanalThe DMX 0-10V Interface is especially designed to switch not-DMX-suitable devices with an analog input.On the output 8 analog signals with 0-10V output voltage are available.Each output is controllable via a DMX-channel and divided in 256 steps.A output driver on each channel allows loads up to 10mA. Specifications  Power supply:12-24V DC  Current consumption:50mA@12V; 40mA@24V (without connected load)  Protocol:DMX512 RDM  DMX channels:8 channels  DMX-FAILHold / 0-100%  Output:8 outputs with driver each max. 10mA  Resolution:256 steps (8-Bit), linear  Connections:screw terminals  Dimensions:64mm x 82 mm Product DownloadsDMX-Analog 0-10V 8-KanalBedienungsanleitung DMX-Analog 0-10V 8 channelUser Manual

 WAGO 221-2411 DurchgangsverbinderWith the 221 series connection terminal, WAGO enables tool-free wiring for all types of conductors.Clear handling and space-saving design make every application child's play.Simple, quick and safe handling.The connection terminals can be opened particularly easily and quickly.Thanks to the specially designed operating lever, only minimal effort is required to open the 221.The connection is made completely without tools.In addition, the recessed grips on the side prevent slipping and ensure that the terminal is easy to hold while connecting the conductors.With the small connection terminal up to 4 mm², all types of conductors with different cross-sections can be clamped quickly and easily.The 1-way through connectors connect fine-stranded conductors from 0.14 to 4 mm² as well as single and multi-wire conductors from 0.2 to 4 mm².The large connection area allows you to connect different types of conductors and bridge large differences in cross-section. Specifications  Number of poles:1  Rated current:32A  Cross section flexible (max.):4 mm²  Cross section flexible (min.):0.14 mm²  Cross section rigid (max.):4 mm²  Cross section rigid (max.):0.2 mm²  Part number:221-2411  Manufactor:WAGO

 WAGO 221-412 Verbindungsklemme 2With the 221 series connection terminal, WAGO enables tool-free wiring for all types of conductors.Clear handling and space-saving design make every application child's play.Simple, quick and safe handling.The connection terminals can be opened particularly easily and quickly.Thanks to the specially designed operating lever, only minimal effort is required to open the 221.The connection is made completely without tools.In addition, the recessed grips on the side prevent slipping and ensure that the terminal is easy to hold while connecting the conductors.With the small connection terminal up to 4 mm², all types of conductors with different cross-sections can be clamped quickly and easily.The connectors connect fine-stranded conductors from 0.14 to 4 mm² as well as single and multi-wire conductors from 0.2 to 4 mm².The large connection area allows you to connect different types of conductors and bridge large differences in cross-section. Specifications  Type:Connection terminal  Assembly:2 conductors  Rated current:32A  Cross section flexible (max.):4 mm²  Cross section flexible (min.):0.14 mm²  Cross section rigid (max.):4 mm²  Cross section rigid (max.):0.2 mm²  Part number:221-412  Manufactor:WAGO

 WAGO 221-413 Verbindungsklemme 3With the 221 series connection terminal, WAGO enables tool-free wiring for all types of conductors.Clear handling and space-saving design make every application child's play.Simple, quick and safe handling.The connection terminals can be opened particularly easily and quickly.Thanks to the specially designed operating lever, only minimal effort is required to open the 221.The connection is made completely without tools.In addition, the recessed grips on the side prevent slipping and ensure that the terminal is easy to hold while connecting the conductors.With the small connection terminal up to 4 mm², all types of conductors with different cross-sections can be clamped quickly and easily.The connectors connect fine-stranded conductors from 0.14 to 4 mm² as well as single and multi-wire conductors from 0.2 to 4 mm².The large connection area allows you to connect different types of conductors and bridge large differences in cross-section. Specifications  Type:Connection terminal  Assembly:3 conductors  Rated current:32A  Cross section flexible (max.):4 mm²  Cross section flexible (min.):0.14 mm²  Cross section rigid (max.):4 mm²  Cross section rigid (max.):0.2 mm²  Part number:221-413  Manufactor:WAGO

 WAGO 221-415 Verbindungsklemme 5With the 221 series connection terminal, WAGO enables tool-free wiring for all types of conductors.Clear handling and space-saving design make every application child's play.Simple, quick and safe handling.The connection terminals can be opened particularly easily and quickly.Thanks to the specially designed operating lever, only minimal effort is required to open the 221.The connection is made completely without tools.In addition, the recessed grips on the side prevent slipping and ensure that the terminal is easy to hold while connecting the conductors.With the small connection terminal up to 4 mm², all types of conductors with different cross-sections can be clamped quickly and easily.The connectors connect fine-stranded conductors from 0.14 to 4 mm² as well as single and multi-wire conductors from 0.2 to 4 mm².The large connection area allows you to connect different types of conductors and bridge large differences in cross-section. Specifications  Type:Connection terminal  Assembly:5 conductors  Rated current:32A  Cross section flexible (max.):4 mm²  Cross section flexible (min.):0.14 mm²  Cross section rigid (max.):4 mm²  Cross section rigid (max.):0.2 mm²  Part number:221-415  Manufactor:WAGO

 WAGO 221-500 BefestigungsadapterWith the 221 series, WAGO enables tool-free wiring for all types of conductors.Clear handling and space-saving design make every application child's play.Simple, quick and safe handling.The mounting carrier is suitable for 2-, 3- and 5-conductor 221 Series Splicing Connectors (4 mm²). Specifications  Type:Mounting carrier  Suitable:for 2-, 3- and 5-conductor 221 Series Splicing Connectors  Mounting type:DIN-35 rail Screw mount  Color:Orange  Part number:221-500  Manufactor:WAGO

 MEANWELL HLG-120H-12A (12V/10A/120W)- Universal input- Aluminium enclosure_ Overload protection, current limiting, auto recovery_ Protections: short circuit/over load/over voltage- Built-in active PFC function- Suitable for LED lighting and moving sign applications- EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13- IP65- Adjustable output voltage with internal potentiometer- Adjustable output current with internal potentiometer- Manufactor: MEANWELL- Order code: HLG-120H-12A Specifications  Output voltage:12V (einstellbar: 10,8...13,5V)  Output current, max:10A (adjustable 5...10A)  Input voltage:90...264V AC (47...63Hz) 127...370V DC  Input Inrush Current, max.:60A  Operating Temperature:-40...+70°C  Weight:1120g Produkt DownloadsHLG-120HDatasheet

 MEANWELL HLG-120H-24A (24V/5A/120W)- Universal input- Aluminium enclosure_ Overload protection, current limiting, auto recovery_ Protections: short circuit/over load/over voltage- Built-in active PFC function- Suitable for LED lighting and moving sign applications- EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13- IP65- Adjustable output voltage with internal potentiometer- Adjustable output current with internal potentiometer- Manufactor: MEANWELL- Order code: HLG-120H-24A Specifications  Output voltage:24V (einstellbar: 22...27V)  Output current, max:5A (adjustable 2,5...5A)  Input voltage:90...264V AC (47...63Hz) 127...370V DC  Input Inrush Current, max.:60A  Operating Temperature:-40...+70°C  Weight:1120g Produkt DownloadsHLG-120HDatasheet

 MEANWELL HLG-240H-12A (12V/16A/192W)- Universal input- Aluminium enclosure_ Overload protection, current limiting, auto recovery_ Protections: short circuit/over load/over voltage- Built-in active PFC function- Suitable for LED lighting and moving sign applications- EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13- IP65- Adjustable output voltage with internal potentiometer- Adjustable output current with internal potentiometer- Manufactor: MEANWELL- Order code: HLG-240H-12A Specifications  Output voltage:12V (adjustable: 11,2...12,8V)  Output current, max:16A (adjustable 8...16A)  Input voltage:90...305V AC (47...63Hz) 127...431V DC  Input Inrush Current, max.:75A  Over Current Protection:95...108%  Operating Temperature:-40...+70°C  Weight:1300g Produkt DownloadsHLG-240HDatasheet

 MEANWELL HLG-240H-24A (24V/10A/240W)- Universal input- Aluminium enclosure_ Overload protection, current limiting, auto recovery_ Protections: short circuit/over load/over voltage- Built-in active PFC function- Suitable for LED lighting and moving sign applications- EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13- IP65- Adjustable output voltage with internal potentiometer- Adjustable output current with internal potentiometer- Manufactor: MEANWELL- Order code: HLG-240H-24A Specifications  Output voltage:24V (adjustable: 22,4...25,6V)  Output current, max:10A (adjustable 5...10A)  Input voltage:90...305V AC (47...63Hz) 127...431V DC  Input Inrush Current, max.:75A  Over Current Protection:95...108%  Operating Temperature:-40...+70°C  Weight:1300g Produkt DownloadsHLG-240HDatasheet

 MEANWELL HLG-320H-12A (12V/22A/264W)- Universal input- Aluminium enclosure_ Overload protection, current limiting, auto recovery_ Protections: short circuit/over load/over voltage- Built-in active PFC function- Suitable for LED lighting and moving sign applications- EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13- IP65- Adjustable output voltage with internal potentiometer- Adjustable output current with internal potentiometer- Manufactor: MEANWELL- Order code: HLG-320H-12A Specifications  Output voltage:12V (adjustable: 10,8...13,5V)  Output current, max:22A (adjustable 11...22A)  Input voltage:90...305V AC (47...63Hz) 127...431V DC  Input Inrush Current, max.:70A  Over Current Protection:95...108%  Operating Temperature:-40...+70°C  Weight:1880g Produkt DownloadsHLG-320HDatasheet

 MEANWELL HLG-320H-24A (24V/13,3A/319W)- Universal input- Aluminium enclosure_ Overload protection, current limiting, auto recovery_ Protections: short circuit/over load/over voltage- Built-in active PFC function- Suitable for LED lighting and moving sign applications- EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13- IP65- Adjustable output voltage with internal potentiometer- Adjustable output current with internal potentiometer- Manufactor: MEANWELL- Order code: HLG-320H-24A Specifications  Output voltage:24V (adjustable: 21...26V)  Output current, max:13,3A (adjustable 6,67...13,34A)  Input voltage:90...305V AC (47...63Hz) 127...431V DC  Input Inrush Current, max.:70A  Over Current Protection:95...108%  Operating Temperature:-40...+70°C  Weight:1880g Produkt DownloadsHLG-320HDatasheet

 MEANWELL HLG-600H-12A (12V/40A/480W)- Universal input- Aluminium enclosure_ Overload protection, current limiting, auto recovery_ Protections: short circuit/over load/over voltage- Built-in active PFC function- Suitable for LED lighting and moving sign applications- EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13- IP65- Adjustable output voltage with internal potentiometer- Adjustable output current with internal potentiometer- Manufactor: MEANWELL- Order code: HLG-600H-12A Specifications  Output voltage:12V (adjustable: 10,2...12,6V)  Output current, max:40A (adjustable 20...40A)  Input voltage:90...305V AC (47...63Hz) 127...431V DC  Input Inrush Current, max.:70A  Over Current Protection:95...108%  Operating Temperature:-40...+70°C  Weight:3900g Produkt DownloadsHLG-600HDatasheet

 MEANWELL HLG-600H-24A (24V/25A/600W)- Universal input- Aluminium enclosure_ Overload protection, current limiting, auto recovery_ Protections: short circuit/over load/over voltage- Built-in active PFC function- Suitable for LED lighting and moving sign applications- EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13- IP65- Adjustable output voltage with internal potentiometer- Adjustable output current with internal potentiometer- Manufactor: MEANWELL- Order code: HLG-600H-24A Specifications  Output voltage:24V (adjustable: 20,4...25,2V)  Output current, max:25A (adjustable 12,5...25A)  Input voltage:90...305V AC (47...63Hz) 127...431V DC  Input Inrush Current, max.:70A  Over Current Protection:95...108%  Operating Temperature:-40...+70°C  Weight:3900g Produkt DownloadsHLG-600HDatasheet

 MEANWELL HLG-80H-12A (12V/5A/60W)- Universal input- Aluminium enclosure_ Overload protection, current limiting, auto recovery_ Protections: short circuit/over load/over voltage- Built-in active PFC function- Suitable for LED lighting and moving sign applications- EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13- IP65- Adjustable output voltage with internal potentiometer- Adjustable output current with internal potentiometer- Manufactor: MEANWELL- Order code: HLG-80H-12A Specifications  Output voltage:12V (adjustable: 10,8...13,5V)  Output current, max:5A (adjustable 3...5A)  Input voltage:90...305V AC (47...63Hz) 127...431V DC  Input Inrush Current, max.:70A  Operating Temperature:-40...+70°C  Weight:840g Produkt DownloadsMEANWELL HLG-80HDatasheet
