ArtNet Player X16+The ArtNet Player X16+, in the following only called ArtNet Player X,is the first Stand-Alone Controller from DMX4ALL, offered in different model versions.Depending on the needed application, the ArtNet Player X is available in different designs and functionalities.As usual, the ArtNet Player X is also quickly ready for use in DMX4ALL manner and remains intuitiveand user-friendly despite numerous and new functions in the handling.This is possible by the well-structured user interface of the device's own web interface, available for the settings.The essential actions can be set directly on the device, thanks to the clearly designed touch paneland an external access is not needed. An overview of the current status is provided by the integrated RGB LED.Whether as a board version or as compact ready-made device with comfortable touch operation, the ArtNet Player Xcan be used to play lighting programs from SD card. Different file formats can be used, which can be created withthe DMX Configurator or used as TPM2 files from freely available software.With up to 16 universes, a maximum of 8192 channels can be output via the network with just one ArtNet Player X.Even in larger installations, handling across several devices remains easy and clear thanks to Master-Slave operation.The ArtNet Player X offers the possibility to execute programs comfortably time-controlled. Up to 16 configurable timerscan be defined individually. For each timer one or several days can be assigned as well as the start time.Furthermore, the playback duration as well as the hourly playback with adjustable time window can be set optionally.The current time is needed for the correct processing the timers. This setting is done either via the device's ownweb interface, the optionally available DCF77 Key with DCF77 sensor or according to the ArtNet specificationvia network-based ArtTimeSync packages. DCF77 allows an automatic adjustment to summer / winter time.The configurable digital inputs integrated in the ArtNet Player X allow operation by remote pushbuttons,making additional devices obsolete. Designed as a LongDistance inputs, even larger distances do not cause anyproblems when mounting the switching elements.The ArtNet Player X is convincing and combines a multitude of useful and innovative functions undera top-hat rail housing in its space-saving, compact design.Replay up to 16 DMX UniversesThe ArtNet Player X can output up to 16 DMX universes via Art-Net / sACN.Output via Art-Net or sACNThe DMX universes to be output can be output via Art-Net or sACN.Two galvanically separate DMX connectionsOn the ArtNet Player X there are 2 galvanically isolated DMX connections.These can be configured as DMX-OUT or DMX-IN.Remote-FunctionThe ArtNet Player X has a configurable remote function. Remote control ispossible via DMX, Art-Net, sACN, HTTP request or DMX4ALL Commands.USER-Webinterface The ArtNet Player X16 and ArtNet Player X16+ have the option of storinga freely configurable website on the SD card.Up to 4 independent zones The independent zones provide the possibility to play different lighting programs simultaneously.8 LongDistance inputs8 configurable digital inputs are available for connecting buttons or switches.The inputs are designed as LongDistance Inputs, so the switching elements can also be installed in greater distance.Touch HandlingThere are 7 touch fields for operation on the ArtNet Player X as well as an RGB display LED.Switchable LED DisplayThe LED displays on the ArtNet Player X can be switched off by ArtNet command or time-controlled,to avoid disturbing "light spots " especially on stage.RGB/RGBW-FilterA quick and uncomplicated change of the defined color in the program is allowed by the RGB/RGBW filter.The selected colors can be filtered as needed without editing the previously created program.Firmware-Update-FunctionThe firmware update function enables to use always the free, current device software.Different data files for lighting programsThe ArtNet Player X plays the lighting programs from the SD card.The DMX4ALL program files as well as TPM2 or TPM2NET can be used as data formats.Easy ConfigurationFast and uncomplicated configuration is possible at any time from a PC, smartphone or tablet,due to the user-friendly configuration via any web browser.Configuration via SD card The ArtNet Player X can now also be configured using a configuration fileon the SD card instead of via the web interface.Synchronize multiple devicesIf more DMX universes are needed, several ArtNet Player X can be synchronized.Free SoftwareFor creating the programs our free software DMX-Configurator can be used, which is availablein the current FREE version as download on our website www.dmx4all.de. Specifications  Power supply:8-24V DC (150mA@12V; 100mA@24V)  Connections:RJ45 Ethernet Screw terminals  Ethernet:10 Mbit/s | 100 Mbit/s  Art-Net™ / sACN:16 universes up to 8192 channels  DMX2x galvanically isolated Switchable  DMX OUTPUT / DMX INPUT DMX OUTPUT: DMX512 DMX INPUT: DMX512 / RDM  Device-Sync:Synchronisation of several devices  Remote-Options:DMX Art-Net™ sACN HTTP-Request DMX4ALL Commands  Digital Input:8 configurable Long Distance-Inputs  Timer:Up to 16 configurable timer for executing programs Hourly execution with adjustable time slot  TOUCH-Control:7 sensor buttons directly on the device for quick operation and RGB status display  SD Card:microSD up to 16GB  Playback format:DMX4ALL program files TPM2 files TPM2NET files  Status display:RGB-LED, network status LEDs all disengageable  Features:RGB-Filter Firmware-Update-Function Silent without a fan  Optional Equipment:DCF77 receiver  Dimension:70mm x 90mm x 60mm Product DownloadsArtNet Player X    Bedienungsanleitung         ArtNet Player X    User Manual         ArtNet Player X    Firmware Software & ToolsDMX-Configurator V2    Windows 32 & 64bit         DMX-Configurator V2    Bedienungsanleitung         DMX-Configurator V2    User Manual         IP Configurator (ArtNet Produkte)    Windows 32 & 64bit         IP Configurator    Anwendungshinweis         IP Configurator    Application Note Application Notes  ArtNet Player X mit ArtNet-DMX MUX fernsteuern  AppNote     Remote control Player X with ArtNet-DMX MUX  AppNote

 DMX-Splitter 4 RDM+The DMX-Splitter 4 RDM+ is a compact DMX and RDM distributor that makes a DMX input signalavailable again at four galvanically isolated outputs.4 galvanically isolated outputsThe DMX-Splitter 4 RDM+ is a compact DMX and RDM distributor that makes a DMX input signalavailable again at four galvanically isolated outputs.DMX and RDMIn contrast to pure DMX splitters, the RDM information is passed in bothdirections in addition to the DMX signal.RDM filterWhen the RDM filter is switched on, all RDM information are filtered out and no longer passedon to the outputs. This can prevent malfunction / flickering of non-RDM-capable devices.Settings possible via RDMThe DMX-Splitter 4 RDM is recognized as an independent RDM device and settings can be made via RDM.Extremely light constructionExtremely light DC/DC converters are used for galvanic isolation.Power supply via one power supply unitThe power supply occurs via one power supply unit. The voltage range is between 8V up to 24V.3 RGB-LEDsThree RGB LEDs clearly indicate the current operating status.Touch-ControlThe DMX-Splitter 4 RDM+ has an integrated touch control field to turn on/off the RDM filter. Switchable LED-DisplayThe LED-Display at the DMX-Splitter 4 RDM+ can be switched off via RDM command or time-controlled,so that no disturbing light sources are present during operation. Specifications  Power supply:8-24V DC  Power consumption:200mA@12V / 130mA@24V (no load)  Protocol:DMX512 RDM  Input:1x DMX512 / RDM  Output:4x DMX512 / RDM galvanically isolated  RDM filter:Can be switched on / off  TOUCH-Control:1 sensor button directly on the device and 3 RGB status LEDs  Connections:screw terminals  Dimensions:70mm x 90mm x 60mm Product DownloadsDMX-Splitter 4 RDM+Bedienungsanleitung DMX-Splitter 4 RDM+User Manual

 DMX-LED-Dimmer X9HR+The DMX-LED-Dimmer X9HR+ is especially designed for controlling RGB LED-Stripes.The dimmer has 9 High-Resolution PWM-Outputs (3xRGB) independently controllable via DMX.9 OutputsThe DMX-LED-Dimmer X9HR+ has 9 outputs to which LEDs can be connected.All outputs are designed in the same way so single color, RGB or RGBW LEDs can be connected.High Power OutputsThe outputs can drive a current up to 10A.So it is possible to connect a maximum load of 120W (12V) / 240W (24V).0% to 100% dimmableThe connected LEDs are dimmed by PWM from 0% to 100%.For voltages from 12V up to 24VThe DMX-LED-Dimmer X9HR+ operates with supply voltages from 12V up to 24V.The LED voltage can be different per output so that one DMX-LED-Dimmer X9HR can control different LED systems.DMX-FAIL FunctionAn adjustable DMX FAIL function offers the option to get in case of lost DMX signal thecurrent state (HOLD) or to adopt a predefined value if the DMX signal fails.DMX-Master DimmerOptionally, another DMX channel can be activated as Master Dimmer (all outputs) orone master dimmer per RGB group. The global master dimmer is fixed at DMX address 1 andcan be used as system master dimmer.Adjustable dimming curveThe dimming curves can be configured individually for each output.RDM supportThe DMX-LED-Dimmer X9HR+ allows configuration by RDM via DMX.SubDevice-ModeWithin the SubDevice Mode, each output is assigned its own DMX address and DMX FAIL behavior via RDM.Touch-ControlThe DMX-LED-Dimmer X9HR+ is designed with 3 touch fields for operation and a 7-segment display.RGB-Status displayVia a RGB status display the DMX reception is shown.Firmware-Update-FunctionTo use future functions, the DMX-LED-Dimmer X9HR+ offers a firmware update function. Specifications  Power supply:7-24V DC 100mA@12V / 150mA@24V (without load)  LED voltage:7-24V DC (no AC voltage !)  Protocol:DMX512 RDM  DMX channels:9 channels with 8Bit-controlling and LookUp-Table 18 channels with 16Bit-controlling + optional Master-Dimmer-Channels  Output:9 PWM-signal common supply voltage anode (PLUS)  8bit ModePWM-Frequency 488 Hz with LookUp-Table 2 kHz or 4 kHz without LookUp-Table  16bit ModePWM-Frequency 488 Hz without LookUp-Table  Masterdimmer:None / Global / RGB / System  DMX-FAIL:Hold / 0%-100%  Output current:max. 10A each output In sum 90A with all GND connections  Output power:9x 120W (12V) / 9x 240W (24V)  CTRL output:Control output for switching off the load power supply units (Energy-Save)  StandAlone function:9 internal StandAlone programs  Display:7 segment display RGB LED  TOUCH-Control:3 touch buttons  Connectors:Screw terminals  Dimensions:105mm x 90mm x 60mm Produkt DownloadsDMX-LED-Dimmer X9 HR+Bedienungsanleitung DMX-LED-Dimmer X9 HR+User Manual DMX-LED-Dimmer X9 HR+USB DriverVersion 6.0.0.0 DMX-LED-Dimmer X9 HR+Firmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual

 DMX-RELAIS 8 INRUSH+The DMX-RELAIS 8 INRUSH+ is designed for several control tasks.8 potential free switching outputsThe DMX-RELAIS 8 INRUSH has 8 potential free switching outputs (Closer / NO) up to 8A switching capacity.Switching contact for direct and alternating voltageThe relay interface is suitable to direct current (DC) or alternating current (AC).DMX FAIL-FunctionAn adjustable DMX FAIL function offers the option to hold the current state (HOLD) orto adopt a predefined value if the DMX signal fails.RDM supportThe DMX-RELAIS 8 INRUSH+ allows the configuration via RDM or DMX.Free RDM softwareFor setting the parameters via RDM, our free RDM Configurator softwareis available for download on our website www.dmx4all.de.Lockable device settingsThe RDM parameters Lock Pin and Lock State allow or prohibit changingsaved RDM parameters to prevent unauthorized changes.SubDevice-ModeIn SubDevice mode, each output is assigned its own DMX address,operating mode and DMX FAIL behavior via RDM.Touch-ControlThe DMX-RELAIS 8 INRUSH+ is designed with 3 touch fields for operation and a 7-segment display.RGB-Status displayVia a RGB status display the DMX reception is shown.Mute able LED-DisplayThe LED-Display at the DMX-RELAIS 8 INRUSH+ can be switched off via RDM command or time-controlled,so that no disturbing light sources are present during operation.Several operation modesThe DMX-RELAIS 8 INRUSH+ offers various operation modes. Specifications  Power supply:12-24V DC (300mA @ 12V / 200mA @ 24V)  Protocol:DMX512 RDM  DMX-Channels:up to 8 DMX-channels  DMX-FAIL:Hold / 0-100%  Operation modes:Hysteresis 127/128 Hysteresis 0/1 Hysteresis 100/150 Exclusive Monostable 1Second  Output:8 potential-free switching output (closer / NO) each max. 8A 165A@20ms Switch-on peak current  Display:7 segment display RGB LED  TOUCH-Control:3 touch buttons  Connectors:screw terminals  Dimensions:105mm x 90mm x 60mm Product DownloadsDMX-RELAIS 8 INRUSH+Bedienungsanleitung DMX-RELAIS 8 INRUSH+User Manual

 ArtNet PixxControl PX2+The ArtNet PixxControl PX2+ is a compact ArtNet (DMX over Ethernet) interface,which converts ArtNet directly to two independent control signals for several digital LEDs.For the ArtNet network connection a standard RJ45 network connector is used.Two independent outputs with selectable pixel data protocolThe ArtNet PixxControl PX2+ has two outputs, independently configurable. The pixel data protocol (control signal)for different LED pixel types and other parameters can be selected separately for each output.Selectable color sequenceThe RGB color sequence is adjustable, which allows flexible uses. It is also possible to control RGBW pixels.Furthermore, a SingleColor option can be selected, where each pixel needs only one channel.Adjustable pixel groupThe ArtNet PixxControl PX2+ supports pixel groups with adjustable length.Each pixel group behaves like a single pixel controlled via 3 DMX channels (RGB) or 4 DMX channels (RGBW).That reduces channels in installations with many pixels.Voltage monitoringBoth data outputs are equipped with a voltage input, which allows monitoring of the LED voltage supplyvia the network. The voltage values can be called via RDM or with the web interface.CTRL OutputThe CTRL output can be used to switch off the power supply for the LED installation as soon as theArtNet PixxControl PX2+ does not receive any data after 5 minutes or the connected digital LEDs don’t light up.5 RGB-LED-DisplayFive RGB LEDs display the current operating status of the ArtNet PixxControl PX2+ and the output ports clearly.Muteable LED-DisplayThe LED displays on the ArtNet PixxControl PX2+ can be switched off via ArtNet command (AcLedMute),RDM (DISPLAY_LEVEL) or time-controlled. This is especially helpful on stages to avoid disturbing "light spots".Easy ConfigurationA user-friendly configuration via a web browser allows quick and uncomplicated setting of all parameters.No special software is needed a normal web browser is enough. This means that the configuration ispossible at any time from a PC, smartphone or tablet.To set the IP address easily, the IP Configurator is offered as free download as a PC tool or Android app.This allows the network settings of the PC or Android device to remain unchanged in order toconfigure the IP of the ArtNet PixxControl PX2+.RDMThe important parameters such as the pixel type, the pixel group size or the color sequence can be set individuallyfor both data outputs via RDM. Also the voltage values of the LED power supply can be called via RDM.Combinable with WiFi componentsThe ArtNet PixxControl PX2+ can be integrated into WLAN networks in combination with a WLAN bridge.Firmware update functionTo use future functions, the ArtNet PixxControl PX2+ offers a firmware update function.The update can be started from a web browser, so no access to the device is necessary! Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:8-24V DC (150mA@12V; 100mA@24V)  Connection:RJ45 Ethernet  12pin screw terminal  Protocol:Art-Net™ 4 (downward compatible) RDM  LED types:APA-101, APA-104, APA-102,max. 1360 pixel per output DycoLED PB3, DycoLED PB5,  GS8208,  INK1002, INK1003,  LC8808,  LPD1101, LPD8803, LPD6803, LPD8806,  LPD1886 8Bit, LPD1886 12Bit (8Bit controlled),  SK6812, SK6822, SK9822,  SM16703,  TM1804, TM1812, TM1814, TM1829, TM1934,  UCS1903, UCS1912, UCS2903, UCS2912,  WS2801, WS2811, WS2812, WS2812B,  WS2813, WS2815, WS2818, WS2821     LPD1886 12Bit (12Bit controlled),max. 680 pixel per output UCS9812 (8Bit controlled), UCS9812 (16Bit controlled)     DMX512max. 512 DMX channels per output  Color Sequence:RGB selectable / RGBW SingleColor white, red, green, blue  Pixel groups:1 up to 127 pixel / all  Gamma correction:Selectable for LPD1886 12Bit (8Bit controlled), UCS9812 (8Bit controlled)  LED-Display:5 RGB Status-LED Ethernet-Status-LEDs yellow and green  Dimensions:70mm x 90mm x 60mm Product DownloadsArtNet PixxControl PX2+Bedienungsanleitung ArtNet PixxControl PX2+User Manual ArtNet PixxControl PX2+Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note RDM Configurator (ArtNet Produkte)Windows 32 & 64bit RDM ConfiguratorBedienungsanleitung RDM ConfiguratorUser Manual

 DMX-Splitter 6+The DMX-Splitter 6+ is a compact DMX-Divider with one DMX-Input signal which providesthese at six galvanically isolated outputs.6 galvanically isolated outputsThe DMX-Splitter 6+ is a compact DMX-Divider with one DMX-Input signal which providesthese at four galvanically isolated outputs.Extremely light constructionExtremely light DC/DC converters are used for galvanic isolation.Power supply via one power supply unitThe power supply occurs via one power supply unit.The voltage range is between 8V up to 24V.Compact design for top hat rail mountingDue to its small size, the DMX Splitter 6+ is suitable for installationon DIN rails with a width of 10.5 cm.LED-DisplayA multicolor LED clearly indicates the current operating status. Specifications  Power supply:8-24V DC (350mA@12V; 200mA@24V)  Input:512 channels  Output:6x 512 channels galvanically isolated  Status Display:Multi-color LED  Connections:screw terminals  Dimensions:105mm x 90mm x 60mm Product DownloadsDMX-Splitter 6+Bedienungsanleitung DMX-Splitter 6+User Manual

 PixxSplitter DR8+The PixxSplitter DR8+ is a manifold for a digital LED signal to up to 8 connected digital LED-Strips.Up to 999 RGB or RGBW pixels can be connected to each output.The input signal, coming from a pixel controller, contains control information for all connected pixels.This allows to control up to 8 different digital LED-Strip elements with just one control unit. The wiring is radial.In the Default-Setting, the number of pixels on each output is set to 100 RGB pixels.In total a pixel controller drives 800 RGB pixels, whereby the first 100 pixels (pixels 1-100) are connected to output 1,the second 100 pixels (pixels 101-200) to output 2, etc. Specifications  Power supply:8-24V / 100mA 5V / 100mA via Mini-USB connector  Input:Control signal for digital LED stripes  Output:8x control signal for digital LED stripes  Compatible LED-Types:SK6812 GS8208 WS2811, WS2812(B) INK1002, INK1003  Color sequence:RGB / RGBW (selectable)  Number of pixel/output:1 - 999 pixel  Display:4 digit 7 segment display 1x RGB-LED  Controls:3 buttons (UP / DOWN / MENU)  Dimensions:105mm x 90mm x 60mm Produkt DownloadsPixxSplitter DR8+Bedienungsanleitung PixxSplitter DR8+User Manual PixxSplitter DR8+USB Driver PixxSplitter DR8+Firmware

 DMX-RELAIS 8 INRUSHThe DMX-RELAIS 8 INRUSH is designed for several control tasks.8 potential free switching outputsThe DMX-RELAIS 8 INRUSH has 8 potential free switching outputs (closer / NO) up to 8A switching capacity.Switching contact for direct and alternating voltageThe relay interface is suitable to direct voltage (DC) or alternating voltage (AC).DMX FAIL-FunctionAn adjustable DMX FAIL function offers the option to hold the current state (HOLD)or to adopt a predefined value if the DMX signal fails.RDM supportThe DMX-RELAIS 8 INRUSH allows the configuration via RDM or DMX.Free RDM softwareFor setting the parameters via RDM, our free RDM Configurator softwareis available for download on our website www.dmx4all.de.Lockable device settingsThe RDM parameters Lock Pin and Lock State allow or prohibit changingsaved RDM parameters to prevent unauthorized changes.SubDevice-ModeIn SubDevice mode, each output is assigned its own DMX address,operating mode and DMX FAIL behavior via RDM.LED-State DisplayThe DMX state is indicated via the LED status.Several operation modesThe DMX-RELAIS 8 INRUSH offers several operating modes which can be set via RDM:- Hysteresis 127/128- Hysteresis 0/1- Hysteresis 100/150- Exclusive- Monostable 1SecondTop hat rail mounting availableSuitable for the DMX-RELAIS 8 INRUSH the DIN rail housing 1050 is available as accessory.Together with the top-hat rail housing 1050, the interface is optimally suited for control cabinet installation. Specifications  Power supply:12-24V DC (280mA @ 12V / 180mA @ 24V)  Protocol:DMX512 RDM  DMX-Channels:8 DMX-channels  DMX-FAIL:Hold / 0-100%  Operation modes:Hysteresis 127/128 Hysteresis 0/1 Hysteresis 100/150 Exclusive Monostable 1Second  Output:8 potential-free switching output (closer / NO) each max. 8A 165A@20ms Switch-on peak current  Connectors:screw terminals  Dimensions:99mm x 82mm Product DownloadsDMX-RELAIS 8 INRUSHBedienungsanleitung DMX-RELAIS 8 INRUSHUser Manual

 DMX-Splitter 4The DMX-Splitter 4 is a compact DMX-Divider with one DMX-Input signal which providesthese at four galvanically isolated outputs.4 galvanically isolated outputsThe DMX-Splitter 4 is a compact DMX-Divider with one DMX-Input signal which providesthese at four galvanically isolated outputs.Extremely light constructionExtremely light DC/DC converters are used for galvanic isolation.Power supply via one power supply unitThe power supply occurs via one power supply unit.The voltage range is between 8V up to 24V.Compact design for top hat rail mountingThe DMX-Splitter 4 is suitable for installation in top hat rail mountingswith a width of 7cm due to its small size.LED-DisplayTwo LEDs show clearly the current operation mode.Top hat rail mounting availableSuitable for the DMX Splitter 4 the DIN rail housing 700 is available as accessory. Specifications  Power supply:8-24V DC (350mA@12V; 200mA@24V)  Input:512 channels  Output:4x 512 channels galvanically isolated  Connections:screw terminals  Dimensions:64,2mm x 82mm Product DownloadsDMX-Splitter 4Bedienungsanleitung DMX-Splitter 4User Manual

 ArtNet-DMX Mux24The ArtNet-DMX Mux24 has 16 digital inputs and 8 additional inputs which are adaptableanalog or digital. The output occurs via ArtNet and DMX. For each input the function (Mode) as well as the channels to control are adjustable. A user-friendly configuration via a web browser allows a fast an uncomplicatedsetting for all parameters. The firmware of the ArtNet-DMX Mux24 can be update easy over the network. Specifications  Power supply:7-24V DC / 0,5A  Ethernet:1x RJ45  DMX-OUT:1x 512 channels  Inputs:16x Long Distance Digital Input 8x Analog Eingang or Long Distance Digital Eingang  Mode:Switch Button On Button Off Button On/Off Dimmer Up/Down Dimmer Up Dimmer Down Button On + Dimmer Up Button Off + Dimmer Down Button On/Off + Dimmer Up/Down Analog 0-10V Analog 0-5V Analog 1-10V  Timer:4 configureable timer  Dimensions:99 x 82 x 20mm Product DownloadsArtNet-DMX Mux24Bedienungsanleitung ArtNet-DMX Mux24User Manual ArtNet-DMX Mux24Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note

 ArtNet-DMX Mux16The ArtNet-DMX Mux16 has 16 digital inputs which are given to a ArtNet and DMX output..Each input can act to one or more output channels and the mode is selectable.A user-friendly configuration by using the webinterface allows a fast and uncomplicated setting of all parameters.The firmware of the ArtNet-DMX Mux16 can be update easy over the network. Specifications  Power supply:7-24V DC / 0,5A  Ethernet:1x RJ45  DMX-OUT:1x 512 channels  Inputs:16x Long Distance Digital Input  Mode:Switch Button On Button Off Button On/Off Dimmer Up/Down Dimmer Up Dimmer Down Button On + Dimmer Up Button Off + Dimmer Down Button On/Off + Dimmer Up/Down  Dimensions:99 x 82 x 20mm Product DownloadsArtNet-DMX Mux16Bedienungsanleitung ArtNet-DMX Mux16User Manual ArtNet-DMX Mux16Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note

 DMX-Adressmodul mit LED-DisplayThe DMX-Address module with LED-Display is a helpful additionalmodule which is grinded in the DMX-Line.The DMX-Channels can be shift up as well as down within the DMX-Universes (shiften).The usage occurs via two buttons. The operation mode as well asthe value (DMX-Address) can be adjusted. Specifications  Power supply:5V DC / 50mA  DMX-Input:512 channels  DMX-Output:up to 512 channels  DMX-Output LOAD:Driver for 32 devices (LOAD-UNITs)  Signal delay:~ 0,1µs (Adress-Mode / Shift-Down) ~ 25ms (ChannelAdd-Mode / Shift-Up)  Dimensions:60mm x 30mm Product DownloadsDMX-Adressmodul mit LED-DisplayBedienungsanleitung DMX-Adressmodul mit LED-DisplayUser Manual

 DMX STAGE-PROFI 1.1 RDM (XLR3)The DMX STAGE-PROFI 1.1 RDM is a compact bidirectional Ethernet Gateway (DMX via Ethernet), whichcan be used for Art-Net™ / TPM2 / USB to DMX / sACN to DMX / RDM or DMX to Art-Net™.Via a standard RJ45 net work connection the connection to ethernet net work occurs.Switchable DMX directionThe DMX direction can be switched according to usage.Settable DMX frame rateIn the DMX-OUTPUT mode the DMX frame rate is adjustable, so this interface is compatible to "slow" DMX devices.RDM via Art-Net™Supports RDM via Art-Net™ and thus enables connected RDM devices to be configured via Art-Net™ using corresponding software.Muteable LED displayThe LED-Display at the DMX STAGE-PROFI 1.1 RDM is disengageable via Art-Net™-Command (AcLedMute)or time controlled. This is very helpful to avoid disturbing “light points” on stage.DHCPThe DMX STAGE-PROFI 1.1 RDM has a DHCP function for automatic addressing in the network.Internal stand-alone programs The internal programs make the DMX STAGE-PROFI 1.1 RDM a stand-alone device. The programs can be calledup via the web interface, when the device is switched on, or when Art-Net™ data is missing.Easy ConfigurationA user-friendly configuration via a web browser allows a fast and uncomplicated setting of all parameters.No special software is required, a normal web browser is sufficient. Thus, the configuration at any timefrom your PC, smartphone or tablet device.DMX-Monitor The DMX monitor is available via the web interface. This means that the current DMX valuescan be displayed and checked simultaneously without any additional software.DMX-Fader The DMX fader is available via the web interface. This allows the DMX values to be output to be set without additional software.Easy Network ConfigurationFor easy setting of the IP-address, we provide the IP Configurator as a PC tool or Android app available for free.This allows you to leave the network settings unchanged and can easily configure the IP.High quality and Compact DesignThe DMX STAGE-PROFI 1.1 RDM is designed with a 3-pin Neutrik-XLR-Connection metal design and cased in an aluminium housing.Art-Net™ Merge-FunctionTwo Art-Net™ sources are output by LTP (Latest) or HTP (Highest) combined to the DMX output.Combinable with WiFi componentsIn combination with a WLAN bridge the DMX STAGE-PROFI 1.1 RDM can also be integrated into WLAN net works.Firmware update functionTo use future functions the DMX STAGE-PROFI 1.1 RDM offers a Firmware-Update-Function.This can be started with any web browser, so no direct access to the device is necessary!DMX4ALL Communication-InterfaceThe DMX STAGE-PROFI 1.1 RDM has an additional communication interface using the DMX4ALL-Commands via TCP or UDP packages. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:5V DC via attached external power supply  Connection:RJ45 Ethernet USB Mini-B Neutrik® XLR3  Ethernet:10 Mbit/s | 100 Mbit/s  DMX:Selectable: - 512 channels OUT - 512 channels IN  DMX-Framerate:Adjustable (5 - 44 fps)  RDM:RDM via Art-Net™ (switchable on/off)  ArtDmx Fail:HOLD last data(DMX-OUT)CLEAR all to 0% SET all to 100% NO OUTPUT DEFAULT VALUES SET all to 100% NO OUTPUT DEFAULT VALUES INTERNAL PROGRAMDMX Fail:HOLD last data(DMX-IN)CLEAR all to 0% SET all to 100% NO OUTPUT DEFAULT VALUES  Protocol:Art-Net™ (downwards compatiblel) Ethernet-VCP (Virtual COM Port) USB-VCP (Virtual COM Port) TPM2 sACN (Unicast) DMX4ALL-Commands via TCP, UDP, VCP  Internal program:User-configurable stand-alone program  Status LED:Green: Ethernet Connection Yellow: Datatransfer  Dimensions:75mm x 26mm x 35 mm Produkt DownloadsDMX STAGE-PROFI 1.1 RDM (XLR3)Bedienungsanleitung DMX STAGE-PROFI 1.1 RDM (XLR3)User Manual DMX STAGE-PROFI 1.1 RDM (XLR3)Ethernet VCP Driver 32 & 64bit - Version 1.10 DMX STAGE-PROFI 1.1 RDM (XLR3)USB VCP Driver 32 & 64bit - Version 42.0.1.0 DMX STAGE-PROFI 1.1 RDM (XLR3)Firmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual IP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note DMX4ALL CommandsDMX4ALL Commands for Third-Party Developers RDM Configurator (ArtNet Produkte)Windows 32 & 64bit RDM ConfiguratorBedienungsanleitung RDM ConfiguratorUser Manual

 HUB75E Dot-Matrix ControlThe HUB75E Dot-Matrix Control is a controller for controlling several Dot-Matrix-Displays.Up to 5440 RGB-PixelUp to 5440 RGB pixels can be controlled by the HUB75E Dot-Matrix Control.Adjustable Dot-Matrix ParameterThe parameters for the dot matrix are adjustable. So, different dot-matrixdisplays can be controlled via the HUB75E Dot-Matrix Control.Art-Net™ or TPM2.netThe data transfer occurs per Art-Net™ or TPM2.net.Muteable Status-LEDsThe LED-Display on the HUB75E Dot-Matrix Control is disengageable via ArtNet-Command (AcLedMute)or via time control. This is very helpful on stages to avoid disturbing “light points”.Easy Configuration A user friendly configuration via a web browser allows a fast and uncomplicated settingof all parameters. No special software is necessary, a standard web browser is enough.So, the configuration is possible any time by PC, Smartphone or tablet.For an easy setting of the IP we provide the IP-Configurator as PC-Tool or Android-App for free.The network settings can be leaved unchanged and the IP can be configured without any problems. Combinable with WiFi-ComponentsIn connection with a WLAN-Bridge the HUB75E Dot-Matrix Control can be integrated in a WLAN-Network.Firmware-Update-FunctionTo use future functions the HUB75E Dot-Matrix Control provides a Firmware-Update-Function.This can be started from a web browser, so no direct access to the device is necessary!This Interface will be supported from:Madrix - LED Lighting Control SolutionsDMX-ConfiguratorJinx!or any other software with ArtNet-output Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:5V DC (200mA@5V)  Connection:Ethernet: RJ45 Power: pin screw clamp HUB75E: 16pin connector  Data Fail:Hold Blackout Saved Picture  Dot-Matrix Parameter:Panel number (1-10) Panel width (32, 64, 96, 128) Panel height (8, 16, 32, 64) Panel Scan Rate (1/4, 1/8, 1/16, 1/32) Panel RGB Groups (1, 2) Color depth (3-24 Bit)  Protocol:Art-Net™ 4 (max 32 universes) TPM2.net (max 16384 channels)  Color sequence:RGB  User Picture:User configurable output which is outputted after power on or after data fail  Status LED:Green: Ethernet-Connection available Yellow: Data are transferred  Dimensions:80mm x 50,5mm (without screw clamps)  Delivery includes:1x HUB75E Dot-Matrix Control 1x Screw connection clamps 2 pin 1x Quick guide german / english Product DownloadsHUB75E Dot-Matrix ControlBedienungsanleitung HUB75E Dot-Matrix ControlUser Manual HUB75E Dot-Matrix ControlFirmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual IP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note

 ArtNet Player X8The ArtNet Player X8, in the following only called ArtNet Player X,is the first Stand-Alone Controller from DMX4ALL, offered in different model versions.Depending on the needed application, the ArtNet Player X is available in different designs and functionalities.As usual, the ArtNet Player X is also quickly ready for use in DMX4ALL manner and remains intuitiveand user-friendly despite numerous and new functions in the handling.This is possible by the well-structured user interface of the device's own web interface, available for the settings.An overview of the current status is provided by the integrated RGB LED.Whether as a board version or as compact ready-made device with comfortable touch operation, the ArtNet Player Xcan be used to play lighting programs from SD card. Different file formats can be used, which can be created withthe DMX Configurator or used as TPM2 files from freely available software.With up to 8 universes, a maximum of 4096 channels can be output via the network with just one ArtNet Player X.Even in larger installations, handling across several devices remains easy and clear thanks to Master-Slave operation.The ArtNet Player X offers the possibility to execute programs comfortably time-controlled. Up to 16 configurable timerscan be defined individually. For each timer one or several days can be assigned as well as the start time.Furthermore, the playback duration as well as the hourly playback with adjustable time window can be set optionally.The current time is needed for the correct processing the timers. This setting is done either via the device's ownweb interface, the optionally available DCF77 Key with DCF77 sensor or according to the ArtNet specificationvia network-based ArtTimeSync packages. DCF77 allows an automatic adjustment to summer / winter time.The configurable digital inputs integrated in the ArtNet Player X allow operation by remote pushbuttons,making additional devices obsolete. Designed as a LongDistance inputs, even larger distances do not cause anyproblems when mounting the switching elements.The ArtNet Player X is convincing and combines a multitude of useful and innovative functions undera top-hat rail housing in its space-saving, compact design.Replay up to 8 DMX UniversesThe ArtNet Player X can output up to 8 DMX universes via Art-Net / sACN.Output via Art-Net or sACNThe DMX universes to be output can be output via Art-Net or sACN.Two galvanically separate DMX connectionsOn the ArtNet Player X there are 2 galvanically isolated DMX connections.These can be configured as DMX-OUT or DMX-IN.Remote-FunctionThe ArtNet Player X has a configurable remote function. Remote control ispossible via DMX, Art-Net, sACN, HTTP request or DMX4ALL Commands.8 LongDistance inputs8 configurable digital inputs are available for connecting buttons or switches.The inputs are designed as LongDistance Inputs, so the switching elements can also be installed in greater distance.Switchable LED DisplayThe LED displays on the ArtNet Player X can be switched off by ArtNet command or time-controlled,to avoid disturbing "light spots " especially on stage.RGB/RGBW-FilterA quick and uncomplicated change of the defined color in the program is allowed by the RGB/RGBW filter.The selected colors can be filtered as needed without editing the previously created program.Different data files for lighting programsThe ArtNet Player X plays the lighting programs from the SD card.The DMX4ALL program files as well as TPM2 or TPM2NET can be used as data formats.Easy ConfigurationFast and uncomplicated configuration is possible at any time from a PC, smartphone or tablet,due to the user-friendly configuration via any web browser.Configuration via SD card The ArtNet Player X can now also be configured using a configuration fileon the SD card instead of via the web interface.Synchronization of several devicesIf more DMX universes are needed, several ArtNet Player X can be synchronized.Firmware-Update-FunctionThe firmware update function enables to use always the free, current device software.DIN rail housing availableThe DIN rail housing 700 is available as accessory for the ArtNet Player X.Free SoftwareFor creating the programs our free software DMX-Configurator can be used, which is availablein the current FREE version as download on our website www.dmx4all.de. Specifications  Power supply:8-24V DC (150mA@12V; 100mA@24V)  Connections:RJ45 Ethernet Screw terminals  Ethernet:10 Mbit/s | 100 Mbit/s  Art-Net™ / sACN:8 universes up to 4096 channels  DMX2x galvanically isolated Switchable DMX OUTPUT / DMX INPUT DMX OUTPUT: DMX512 DMX INPUT: DMX512 / RDM  Device-Sync:Synchronisation of several devices  Remote-Options:DMX Art-Net™ sACN HTTP-Request DMX4ALL Commands  Digital Input:8 configurable Long Distance-Inputs  Timer:Up to 16 configurable timer for executing programs Hourly execution with adjustable time slot  SD Card:microSD up to 16GB  Playback format:DMX4ALL program files TPM2 files TPM2NET files  Status display:RGB-LED, network status LEDs all disengageable  Features:RGB-Filter Firmware-Update-Function Silent without a fan  Optional Equipment:DCF77 receiver  Dimension:62mm x 88mm x 29mm Product DownloadsArtNet Player X8Bedienungsanleitung ArtNet Player X8User Manual ArtNet Player X8Firmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual IP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note Application NotesArtNet Player X mit ArtNet-DMX MUX fernsteuernAppNote Remote control Player X with ArtNet-DMX MUXAppNote

 ArtNet Player X16+The ArtNet Player X16+, in the following only called ArtNet Player X,is the first Stand-Alone Controller from DMX4ALL, offered in different model versions.Depending on the needed application, the ArtNet Player X is available in different designs and functionalities.As usual, the ArtNet Player X is also quickly ready for use in DMX4ALL manner and remains intuitiveand user-friendly despite numerous and new functions in the handling.This is possible by the well-structured user interface of the device's own web interface, available for the settings.The essential actions can be set directly on the device, thanks to the clearly designed touch paneland an external access is not needed. An overview of the current status is provided by the integrated RGB LED.Whether as a board version or as compact ready-made device with comfortable touch operation, the ArtNet Player Xcan be used to play lighting programs from SD card. Different file formats can be used, which can be created withthe DMX Configurator or used as TPM2 files from freely available software.With up to 16 universes, a maximum of 8192 channels can be output via the network with just one ArtNet Player X.Even in larger installations, handling across several devices remains easy and clear thanks to Master-Slave operation.The ArtNet Player X offers the possibility to execute programs comfortably time-controlled. Up to 16 configurable timerscan be defined individually. For each timer one or several days can be assigned as well as the start time.Furthermore, the playback duration as well as the hourly playback with adjustable time window can be set optionally.The current time is needed for the correct processing the timers. This setting is done either via the device's ownweb interface, the optionally available DCF77 Key with DCF77 sensor or according to the ArtNet specificationvia network-based ArtTimeSync packages. DCF77 allows an automatic adjustment to summer / winter time.The configurable digital inputs integrated in the ArtNet Player X allow operation by remote pushbuttons,making additional devices obsolete. Designed as a LongDistance inputs, even larger distances do not cause anyproblems when mounting the switching elements.The ArtNet Player X is convincing and combines a multitude of useful and innovative functions undera top-hat rail housing in its space-saving, compact design.Replay up to 16 DMX UniversesThe ArtNet Player X can output up to 16 DMX universes via Art-Net / sACN.Output via Art-Net or sACNThe DMX universes to be output can be output via Art-Net or sACN.Two galvanically separate DMX connectionsOn the ArtNet Player X there are 2 galvanically isolated DMX connections.These can be configured as DMX-OUT or DMX-IN.Remote-FunctionThe ArtNet Player X has a configurable remote function. Remote control ispossible via DMX, Art-Net, sACN, HTTP request or DMX4ALL Commands.USER-Webinterface The ArtNet Player X16 and ArtNet Player X16+ have the option of storinga freely configurable website on the SD card.Up to 4 independent zones The independent zones provide the possibility to play different lighting programs simultaneously.8 LongDistance inputs8 configurable digital inputs are available for connecting buttons or switches.The inputs are designed as LongDistance Inputs, so the switching elements can also be installed in greater distance.Touch HandlingThere are 7 touch fields for operation on the ArtNet Player X as well as an RGB display LED.Switchable LED DisplayThe LED displays on the ArtNet Player X can be switched off by ArtNet command or time-controlled,to avoid disturbing "light spots " especially on stage.RGB/RGBW-FilterA quick and uncomplicated change of the defined color in the program is allowed by the RGB/RGBW filter.The selected colors can be filtered as needed without editing the previously created program.Firmware-Update-FunctionThe firmware update function enables to use always the free, current device software.Different data files for lighting programsThe ArtNet Player X plays the lighting programs from the SD card.The DMX4ALL program files as well as TPM2 or TPM2NET can be used as data formats.Easy ConfigurationFast and uncomplicated configuration is possible at any time from a PC, smartphone or tablet,due to the user-friendly configuration via any web browser.Configuration via SD card The ArtNet Player X can now also be configured using a configuration fileon the SD card instead of via the web interface.Synchronize multiple devicesIf more DMX universes are needed, several ArtNet Player X can be synchronized.Free SoftwareFor creating the programs our free software DMX-Configurator can be used, which is availablein the current FREE version as download on our website www.dmx4all.de. Specifications  Power supply:8-24V DC (150mA@12V; 100mA@24V)  Connections:RJ45 Ethernet Screw terminals  Ethernet:10 Mbit/s | 100 Mbit/s  Art-Net™ / sACN:16 universes up to 8192 channels  DMX2x galvanically isolated Switchable  DMX OUTPUT / DMX INPUT DMX OUTPUT: DMX512 DMX INPUT: DMX512 / RDM  Device-Sync:Synchronisation of several devices  Remote-Options:DMX Art-Net™ sACN HTTP-Request DMX4ALL Commands  Digital Input:8 configurable Long Distance-Inputs  Timer:Up to 16 configurable timer for executing programs Hourly execution with adjustable time slot  TOUCH-Control:7 sensor buttons directly on the device for quick operation and RGB status display  SD Card:microSD up to 16GB  Playback format:DMX4ALL program files TPM2 files TPM2NET files  Status display:RGB-LED, network status LEDs all disengageable  Features:RGB-Filter Firmware-Update-Function Silent without a fan  Optional Equipment:DCF77 receiver  Dimension:70mm x 90mm x 60mm Product DownloadsArtNet Player X    Bedienungsanleitung         ArtNet Player X    User Manual         ArtNet Player X    Firmware Software & ToolsDMX-Configurator V2    Windows 32 & 64bit         DMX-Configurator V2    Bedienungsanleitung         DMX-Configurator V2    User Manual         IP Configurator (ArtNet Produkte)    Windows 32 & 64bit         IP Configurator    Anwendungshinweis         IP Configurator    Application Note Application Notes  ArtNet Player X mit ArtNet-DMX MUX fernsteuern  AppNote     Remote control Player X with ArtNet-DMX MUX  AppNote

 DMX-Splitter 4 RDMThe DMX-Splitter 4 RDM is a compact DMX and RDM distributor that makes a DMX input signalavailable again at four galvanically isolated outputs.4 galvanically isolated outputsThe DMX-Splitter 4 RDM is a compact DMX and RDM distributor that makes a DMX input signalavailable again at four galvanically isolated outputs.DMX and RDMIn contrast to pure DMX splitters, the RDM information is passed in bothdirections in addition to the DMX signal.RDM filterWhen the RDM filter is switched on, all RDM information are filtered out and no longer passedon to the outputs. This can prevent malfunction / flickering of non-RDM-capable devices.Settings possible via RDMThe DMX-Splitter 4 RDM is recognized as an independent RDM device and settings can be made via RDM.Extremely light constructionExtremely light DC/DC converters are used for galvanic isolation.Power supply via one power supply unitThe power supply occurs via one power supply unit. The voltage range is between 8V up to 24V.RGB-LED-DisplayThree RGB LEDs clearly indicate the current operating status.Top hat rail mounting availableSuitable for the DMX-Splitter 4 RDM the DIN rail housing 700 is available as accessory. Specifications  Power supply:8-24V DC  Power consumption:200mA@12V / 130mA@24V (no load)  Protocol:DMX512 RDM  Output:4x DMX512 / RDM galvanically isolated  RDM filter:Can be switched on / off  Connections:screw terminals  Dimensions:64,2mm x 82mm Product DownloadsDMX-Splitter 4 RDMBedienungsanleitung DMX-Splitter 4 RDMUser Manual
