MEANWELL RSP-150-5 (5V/30A/150W)

€51.23*

Content: 1 Stck.

Prices incl. VAT plus shipping costs

7 at stock.

Das Versandversprechen gilt nur für Artikel, die im Online Shop als DMX4ALL GmbH - DMX und RDM-Technik Made in Germany

angezeigt werden und Zahlungseingang per PayPal vorrausgesetzt.
Versand nur werktags von Montag bis Donerstag (bis 13:00 Uhr) (nicht am Samstag, Sonntag und Feiertag).

Delivery time: 1-3 days

Piece

Product number: 50-0305

Manufacturer: Meanwell

Manufacturer product number: RSP-150-5

Weight: 0.8 kg

Delivery time: 1-3 days

Our benefits

Direct from the manufacturer
dispatch within 24 hours
Made in Germany
technical support

Our payment methods:

Product information "MEANWELL RSP-150-5 (5V/30A/150W)"

MEANWELL RSP-150-5 (5V/30A/150W)

- Enclosed case, screw terminals
- Universal input
- Overload protection, current limiting, auto recovery
- Protections: short circuit/over load/over voltage
- Built-in active PFC function
- Low profile
- Built-in remote On/Off control
- Manufactor: MEANWELL
- Manufactor order code: RSP-150-5

Note:
These power supplies are considered as a component that has to be installed in a final equipment.

Specifications


Output voltage:	5V

Output current, max:	30A (0...30A)

Input voltage:	85...264V AC (47...63Hz)
	120...370V DC

Input Inrush Current, max.:	40A

Over Current Protection:	105...135%

Operating Temperature:	-10...+70°C

Weight:	600g

Produkt Downloads

RSP-150
Datasheet

Manufacturer "Meanwell"

MEAN WELL ENTERPRISE Co.Ltd.
No. 28, Wu-Chuan 3 rd Road
Wugu Dist., New Taipei City 24891
Taiwan
+886 2 2299 6100

Importeur (Verantwortliche Person in der EU)
Schukat electronic Vertriebs GmbH
Hans-Georg-Schukat-Str. 2
40789 Monheim am Rhein
Germany
WEEE DE23942637
+49 2173 9505
info@schukat.com
www.schukat.de
