PixxSplitter DR8

 Hutschienengehäuse 1050Module housing for M36-DIN-standard rail. Specifications  Top Material:LexanColour:grey (RAL 7035)Max. Temperature:100°CInstallation wide:105.0 mm (6 module)Label dimensions:41.0 x 100.0 mmFlammability:in confomity with UL94-VO  Base Material:norylColour:black (RAL 7021)Max. Temperaturr:100°CTerminal:max. 36Montage:DIN-standard rail (EN50022)Flammability:in conformity with UL94-VO Product DownloadsModule enclosure 1050Maßzeichnung

 Steckernetzteil 5V/1,5A Mini-USB- Plug-in switching power supply with europlug- Universal input- Protections: short circuit/over load- Insulation Class II- Low no load power consumption- Meets DOE VI- Manufactor: HN-ELECTRONIC- Manufactor order code: HNP06-MINIUSBL6 Specifications  Output voltage:5V  Output current, max:1,5A (0...1,5A)  Input Voltage:90...264V AC (47...63Hz)  Input Inrush Current, Max.:30A  No Load Power Consumption, Max.:0,075W  Operating Temperature:-10...+40°C  Cable Length:1,5m  Output Plug:Mini-USB Produkt DownloadsHNP06-MINIUSBL6Datasheet

 ArtNet PixxControl PX1The ArtNet PixxControl PX1 is a compact ArtNet (DMX over Ethernet) interface,which converts ArtNet directly to a control signals for several digital LEDs.For the ArtNet network connection a standard RJ45 network connector is used.Output with selectable pixel data protocolThe ArtNet PixxControl PX1 has one configurable output. The pixel data protocol (control signal)for different LED pixel types and other parameters can be selected separately.Adjustable color sequenceThe RGB color sequence is adjustable, which allows flexible uses.It is also possible to control RGBW pixels. Furthermore, a SingleColor optioncan be selected, where each pixel needs only one channel.Adjustable pixel groupThe ArtNet PixxControl PX1 supports pixel groups with adjustable length.Each pixel group behaves like a single pixel controlled via 3 DMX channels (RGB)or 4 DMX channels (RGBW). That reduces channels in installations with many pixels.RGB-LED-DisplayThe RGB LED displays the current operation status of the ArtNet PixxControl PX1 clearly.Muteable LED-DisplayThe LED displays on the ArtNet PixxControl PX1 can be switched off via ArtNet command (AcLedMute),RDM (DISPLAY_LEVEL) or time-controlled. This is especially helpful on stages to avoid disturbing "light spots".RDMThe important parameters such as the pixel type, the pixel group size or the color sequencecan be set individually for both data outputs via RDM.Free RDM-SoftwareTo set parameters via RDM our free software RDM-Configurator is available as download on our website www.dmx4all.de .DMX4ALL Communication-InterfaceThe ArtNet PixxControl PX1 has another communication interface which uses the DMX4ALL commands via TCP or UDP.Easy ConfigurationA user-friendly configuration via a web browser allows a quick and uncomplicated setting of all parameters.No special software is needed a normal web browser is enough. This means that the configuration is possibleat any time from a PC, smartphone or tablet.To set the IP address easily, the IP Configurator is offered as free download as PC tool or Android app.This allows the network settings of the PC or Android device to remain unchanged in order to configurethe IP of the ArtNet PixxControl PX1.Combinable with WiFi componentsThe ArtNet PixxControl PX1 can be integrated into WLAN networks in combination with a WLAN bridge.Firmware update functionTo use future functions, the ArtNet PixxControl PX1 offers a firmware update function.The update can be started from a web browser, so no access to the device is necessary!Top hat rail housing availableThe top-hat rail housing 350 or 350flat is available as accessory for the ArtNet PixxControl PX1. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:8-24V DC (100mA@12V; 50mA@24V)  Connection:RJ45 Ethernet  5pin screw terminal  Protocol:Art-Net™ 4 (downward compatible) RDM  LED types:APA-101, APA-104, APA-102,max. 1360 pixel DycoLED PB3, DycoLED PB5,  GS8208,  INK1002, INK1003,  LC8808,  LPD1101, LPD8803, LPD6803, LPD8806,  LPD1886 8Bit, LPD1886 12Bit (8Bit controlled),  SK6812, SK6822, SK9822,  SM16703,  TM1804, TM1812, TM1814, TM1829, TM1934,  UCS1903, UCS1912, UCS2903, UCS2912,  WS2801, WS2811, WS2812, WS2812B,  WS2813, WS2815, WS2818, WS2821     LPD1886 12Bit (12Bit controlled),max. 680 pixel UCS9812 (8Bit controlled), UCS9812 (16Bit controlled)   Color Sequence:RGB selectable / RGBW SingleColor white, red, green, blue  Pixel groups:1 up to 127 pixel / all  Gamma correction:Selectable for LPD1886 12Bit (8Bit controlled), UCS9812 (8Bit controlled)  LED-Display:RGB Status-LED Ethernet-Status-LEDs yellow and green  Dimensions:29,2mm x 82mm Product DownloadsArtNet PixxControl PX1Bedienungsanleitung ArtNet PixxControl PX1User Manual ArtNet PixxControl PX1Firmware Software & ToolsDMX4ALL Software PackDMX / RDM / IP ConfiguratorWindows 32 & 64bit DMX4ALL CommandsDMX4ALL Commands for Third-Party Developers

 ArtNet PixxControl PX2The ArtNet PixxControl PX2 is a compact ArtNet (DMX over Ethernet) interface,which converts ArtNet directly to two independent control signals for several digital LEDs.For the ArtNet network connection a standard RJ45 network connector is used.Two independent outputs with selectable pixel data protocolThe ArtNet PixxControl PX2 has two outputs, independently configurable. The pixel data protocol (control signal)for different LED pixel types and other parameters can be selected separately for each output.Selectable color sequenceThe RGB color sequence is adjustable, which allows flexible uses. It is also possible to control RGBW pixels.Furthermore, a SingleColor option can be selected, where each pixel needs only one channel.Adjustable pixel groupThe ArtNet PixxControl PX2 supports pixel groups with adjustable length.Each pixel group behaves like a single pixel controlled via 3 DMX channels (RGB) or 4 DMX channels (RGBW).That reduces channels in installations with many pixels.Voltage monitoringBoth data outputs are equipped with a voltage input, which allows monitoring of the LED voltage supplyvia the network. The voltage values can be called via RDM or with the web interface.CTRL OutputThe CTRL output can be used to switch off the power supply for the LED installation as soon as theArtNet PixxControl PX2 does not receive any data after 5 minutes or the connected digital LEDs don’t light up.RGB-LED-DisplayThe RGB LED displays the current operation status of the ArtNet PixxControl PX2 clearly.Mute able LED-DisplayThe LED displays on the ArtNet PixxControl PX2 can be switched off via ArtNet command (AcLedMute),RDM (DISPLAY_LEVEL) or time-controlled. This is especially helpful on stages to avoid disturbing "light spots".Easy ConfigurationA user-friendly configuration via a web browser allows quick and uncomplicated setting of all parameters.No special software is needed a normal web browser is enough. This means that the configuration ispossible at any time from a PC, smartphone or tablet.To set the IP address easily, the IP Configurator is offered as free download as a PC tool or Android app.This allows the network settings of the PC or Android device to remain unchanged in order to configurethe IP of the ArtNet PixxControl PX2.RDMThe important parameters such as the pixel type, the pixel group size or the color sequence can be set individuallyfor both data outputs via RDM. Also the voltage values of the LED power supply can be called via RDM.Free RDM-SoftwareTo set parameters via RDM our free software RDM-Configurator is available as download on our website www.dmx4all.de .DMX4ALL Communication-InterfaceThe ArtNet PixxControl PX2 has another communication interface which uses the DMX4ALL commands via TCP or UDP.Combinable with WiFi componentsThe ArtNet PixxControl PX2 can be integrated into WLAN networks in combination with a WLAN bridge.Firmware update functionTo use future functions, the ArtNet PixxControl PX2 offers a firmware update function.The update can be started from a web browser, so no access to the device is necessary!Top-hat rail housing availableThe top-hat rail housing 700 is available as accessory for the ArtNet PixxControl PX2. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:8-24V DC (150mA@12V; 100mA@24V)  Connection:RJ45 Ethernet  12pin screw terminal  Ethernet:10 Mbit/s | 100 Mbit/s  Protocol:Art-Net™ 4 (downward compatible) RDM  LED types:APA-101, APA-104, APA-102,max. 1360 pixel per output DycoLED PB3, DycoLED PB5,  GS8208,  INK1002, INK1003,  LC8808,  LPD1101, LPD8803, LPD6803, LPD8806,  LPD1886 8Bit, LPD1886 12Bit (8Bit controlled),  SK6812, SK6822, SK9822,  SM16703,  TM1804, TM1812, TM1814, TM1829, TM1934,  UCS1903, UCS1912, UCS2903, UCS2912,  WS2801, WS2811, WS2812, WS2812B,  WS2813, WS2815, WS2818, WS2821     LPD1886 12Bit (12Bit controlled),max. 680 pixel per output UCS9812 (8Bit controlled), UCS9812 (16Bit controlled)     DMX512max. 512 DMX channels per output  Color Sequence:RGB selectable / RGBW SingleColor white, red, green, blue  Pixel groups:1 up to 127 pixel / all  Gamma correction:Selectable for LPD1886 12Bit (8Bit controlled), UCS9812 (8Bit controlled)  LED-Display:RGB Status-LED Ethernet-Status-LEDs yellow and green  Dimensions:64,2mm x 82mm Product DownloadsArtNet PixxControl PX2Bedienungsanleitung ArtNet PixxControl PX2User Manual ArtNet PixxControl PX2Firmware Software & ToolsDMX4ALL Software PackDMX / RDM / IP ConfiguratorWindows 32 & 64bit DMX4ALL CommandsDMX4ALL Commands for Third-Party Developers
