LED-Matrix SK6812 RGBW 10x10

 ArtNet PixxControl PX1The ArtNet PixxControl PX1 is a compact ArtNet (DMX over Ethernet) interface,which converts ArtNet directly to a control signals for several digital LEDs.For the ArtNet network connection a standard RJ45 network connector is used.Output with selectable pixel data protocolThe ArtNet PixxControl PX1 has one configurable output. The pixel data protocol (control signal)for different LED pixel types and other parameters can be selected separately.Adjustable color sequenceThe RGB color sequence is adjustable, which allows flexible uses.It is also possible to control RGBW pixels. Furthermore, a SingleColor optioncan be selected, where each pixel needs only one channel.Adjustable pixel groupThe ArtNet PixxControl PX1 supports pixel groups with adjustable length.Each pixel group behaves like a single pixel controlled via 3 DMX channels (RGB)or 4 DMX channels (RGBW). That reduces channels in installations with many pixels.RGB-LED-DisplayThe RGB LED displays the current operation status of the ArtNet PixxControl PX1 clearly.Muteable LED-DisplayThe LED displays on the ArtNet PixxControl PX1 can be switched off via ArtNet command (AcLedMute),RDM (DISPLAY_LEVEL) or time-controlled. This is especially helpful on stages to avoid disturbing "light spots".RDMThe important parameters such as the pixel type, the pixel group size or the color sequencecan be set individually for both data outputs via RDM.Free RDM-SoftwareTo set parameters via RDM our free software RDM-Configurator is available as download on our website www.dmx4all.de .DMX4ALL Communication-InterfaceThe ArtNet PixxControl PX1 has another communication interface which uses the DMX4ALL commands via TCP or UDP.Easy ConfigurationA user-friendly configuration via a web browser allows a quick and uncomplicated setting of all parameters.No special software is needed a normal web browser is enough. This means that the configuration is possibleat any time from a PC, smartphone or tablet.To set the IP address easily, the IP Configurator is offered as free download as PC tool or Android app.This allows the network settings of the PC or Android device to remain unchanged in order to configurethe IP of the ArtNet PixxControl PX1.Combinable with WiFi componentsThe ArtNet PixxControl PX1 can be integrated into WLAN networks in combination with a WLAN bridge.Firmware update functionTo use future functions, the ArtNet PixxControl PX1 offers a firmware update function.The update can be started from a web browser, so no access to the device is necessary!Top hat rail housing availableThe top-hat rail housing 350 or 350flat is available as accessory for the ArtNet PixxControl PX1. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:8-24V DC (100mA@12V; 50mA@24V)  Connection:RJ45 Ethernet  5pin screw terminal  Protocol:Art-Net™ 4 (downward compatible) RDM  LED types:APA-101, APA-104, APA-102,max. 1360 pixel DycoLED PB3, DycoLED PB5,  GS8208,  INK1002, INK1003,  LC8808,  LPD1101, LPD8803, LPD6803, LPD8806,  LPD1886 8Bit, LPD1886 12Bit (8Bit controlled),  SK6812, SK6822, SK9822,  SM16703,  TM1804, TM1812, TM1814, TM1829, TM1934,  UCS1903, UCS1912, UCS2903, UCS2912,  WS2801, WS2811, WS2812, WS2812B,  WS2813, WS2815, WS2818, WS2821     LPD1886 12Bit (12Bit controlled),max. 680 pixel UCS9812 (8Bit controlled), UCS9812 (16Bit controlled)   Color Sequence:RGB selectable / RGBW SingleColor white, red, green, blue  Pixel groups:1 up to 127 pixel / all  Gamma correction:Selectable for LPD1886 12Bit (8Bit controlled), UCS9812 (8Bit controlled)  LED-Display:RGB Status-LED Ethernet-Status-LEDs yellow and green  Dimensions:29,2mm x 82mm Product DownloadsArtNet PixxControl PX1Bedienungsanleitung ArtNet PixxControl PX1User Manual ArtNet PixxControl PX1Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note RDM Configurator (ArtNet Produkte)Windows 32 & 64bit RDM ConfiguratorBedienungsanleitung RDM ConfiguratorUser Manual

 ArtNet PixxControl PX2The ArtNet PixxControl PX2 is a compact ArtNet (DMX over Ethernet) interface,which converts ArtNet directly to two independent control signals for several digital LEDs.For the ArtNet network connection a standard RJ45 network connector is used.Two independent outputs with selectable pixel data protocolThe ArtNet PixxControl PX2 has two outputs, independently configurable. The pixel data protocol (control signal)for different LED pixel types and other parameters can be selected separately for each output.Selectable color sequenceThe RGB color sequence is adjustable, which allows flexible uses. It is also possible to control RGBW pixels.Furthermore, a SingleColor option can be selected, where each pixel needs only one channel.Adjustable pixel groupThe ArtNet PixxControl PX2 supports pixel groups with adjustable length.Each pixel group behaves like a single pixel controlled via 3 DMX channels (RGB) or 4 DMX channels (RGBW).That reduces channels in installations with many pixels.Voltage monitoringBoth data outputs are equipped with a voltage input, which allows monitoring of the LED voltage supplyvia the network. The voltage values can be called via RDM or with the web interface.CTRL OutputThe CTRL output can be used to switch off the power supply for the LED installation as soon as theArtNet PixxControl PX2 does not receive any data after 5 minutes or the connected digital LEDs don’t light up.RGB-LED-DisplayThe RGB LED displays the current operation status of the ArtNet PixxControl PX2 clearly.Mute able LED-DisplayThe LED displays on the ArtNet PixxControl PX2 can be switched off via ArtNet command (AcLedMute),RDM (DISPLAY_LEVEL) or time-controlled. This is especially helpful on stages to avoid disturbing "light spots".Easy ConfigurationA user-friendly configuration via a web browser allows quick and uncomplicated setting of all parameters.No special software is needed a normal web browser is enough. This means that the configuration ispossible at any time from a PC, smartphone or tablet.To set the IP address easily, the IP Configurator is offered as free download as a PC tool or Android app.This allows the network settings of the PC or Android device to remain unchanged in order to configurethe IP of the ArtNet PixxControl PX2.RDMThe important parameters such as the pixel type, the pixel group size or the color sequence can be set individuallyfor both data outputs via RDM. Also the voltage values of the LED power supply can be called via RDM.Free RDM-SoftwareTo set parameters via RDM our free software RDM-Configurator is available as download on our website www.dmx4all.de .DMX4ALL Communication-InterfaceThe ArtNet PixxControl PX2 has another communication interface which uses the DMX4ALL commands via TCP or UDP.Combinable with WiFi componentsThe ArtNet PixxControl PX2 can be integrated into WLAN networks in combination with a WLAN bridge.Firmware update functionTo use future functions, the ArtNet PixxControl PX2 offers a firmware update function.The update can be started from a web browser, so no access to the device is necessary!Top-hat rail housing availableThe top-hat rail housing 700 is available as accessory for the ArtNet PixxControl PX2. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:8-24V DC (150mA@12V; 100mA@24V)  Connection:RJ45 Ethernet  12pin screw terminal  Ethernet:10 Mbit/s | 100 Mbit/s  Protocol:Art-Net™ 4 (downward compatible) RDM  LED types:APA-101, APA-104, APA-102,max. 1360 pixel per output DycoLED PB3, DycoLED PB5,  GS8208,  INK1002, INK1003,  LC8808,  LPD1101, LPD8803, LPD6803, LPD8806,  LPD1886 8Bit, LPD1886 12Bit (8Bit controlled),  SK6812, SK6822, SK9822,  SM16703,  TM1804, TM1812, TM1814, TM1829, TM1934,  UCS1903, UCS1912, UCS2903, UCS2912,  WS2801, WS2811, WS2812, WS2812B,  WS2813, WS2815, WS2818, WS2821     LPD1886 12Bit (12Bit controlled),max. 680 pixel per output UCS9812 (8Bit controlled), UCS9812 (16Bit controlled)     DMX512max. 512 DMX channels per output  Color Sequence:RGB selectable / RGBW SingleColor white, red, green, blue  Pixel groups:1 up to 127 pixel / all  Gamma correction:Selectable for LPD1886 12Bit (8Bit controlled), UCS9812 (8Bit controlled)  LED-Display:RGB Status-LED Ethernet-Status-LEDs yellow and green  Dimensions:64,2mm x 82mm Product DownloadsArtNet PixxControl PX2Bedienungsanleitung ArtNet PixxControl PX2User Manual ArtNet PixxControl PX2Firmware

 ArtNet PixxControl PX2+The ArtNet PixxControl PX2+ is a compact ArtNet (DMX over Ethernet) interface,which converts ArtNet directly to two independent control signals for several digital LEDs.For the ArtNet network connection a standard RJ45 network connector is used.Two independent outputs with selectable pixel data protocolThe ArtNet PixxControl PX2+ has two outputs, independently configurable. The pixel data protocol (control signal)for different LED pixel types and other parameters can be selected separately for each output.Selectable color sequenceThe RGB color sequence is adjustable, which allows flexible uses. It is also possible to control RGBW pixels.Furthermore, a SingleColor option can be selected, where each pixel needs only one channel.Adjustable pixel groupThe ArtNet PixxControl PX2+ supports pixel groups with adjustable length.Each pixel group behaves like a single pixel controlled via 3 DMX channels (RGB) or 4 DMX channels (RGBW).That reduces channels in installations with many pixels.Voltage monitoringBoth data outputs are equipped with a voltage input, which allows monitoring of the LED voltage supplyvia the network. The voltage values can be called via RDM or with the web interface.CTRL OutputThe CTRL output can be used to switch off the power supply for the LED installation as soon as theArtNet PixxControl PX2+ does not receive any data after 5 minutes or the connected digital LEDs don’t light up.5 RGB-LED-DisplayFive RGB LEDs display the current operating status of the ArtNet PixxControl PX2+ and the output ports clearly.Muteable LED-DisplayThe LED displays on the ArtNet PixxControl PX2+ can be switched off via ArtNet command (AcLedMute),RDM (DISPLAY_LEVEL) or time-controlled. This is especially helpful on stages to avoid disturbing "light spots".Easy ConfigurationA user-friendly configuration via a web browser allows quick and uncomplicated setting of all parameters.No special software is needed a normal web browser is enough. This means that the configuration ispossible at any time from a PC, smartphone or tablet.To set the IP address easily, the IP Configurator is offered as free download as a PC tool or Android app.This allows the network settings of the PC or Android device to remain unchanged in order toconfigure the IP of the ArtNet PixxControl PX2+.RDMThe important parameters such as the pixel type, the pixel group size or the color sequence can be set individuallyfor both data outputs via RDM. Also the voltage values of the LED power supply can be called via RDM.Combinable with WiFi componentsThe ArtNet PixxControl PX2+ can be integrated into WLAN networks in combination with a WLAN bridge.Firmware update functionTo use future functions, the ArtNet PixxControl PX2+ offers a firmware update function.The update can be started from a web browser, so no access to the device is necessary! Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:8-24V DC (150mA@12V; 100mA@24V)  Connection:RJ45 Ethernet  12pin screw terminal  Protocol:Art-Net™ 4 (downward compatible) RDM  LED types:APA-101, APA-104, APA-102,max. 1360 pixel per output DycoLED PB3, DycoLED PB5,  GS8208,  INK1002, INK1003,  LC8808,  LPD1101, LPD8803, LPD6803, LPD8806,  LPD1886 8Bit, LPD1886 12Bit (8Bit controlled),  SK6812, SK6822, SK9822,  SM16703,  TM1804, TM1812, TM1814, TM1829, TM1934,  UCS1903, UCS1912, UCS2903, UCS2912,  WS2801, WS2811, WS2812, WS2812B,  WS2813, WS2815, WS2818, WS2821     LPD1886 12Bit (12Bit controlled),max. 680 pixel per output UCS9812 (8Bit controlled), UCS9812 (16Bit controlled)     DMX512max. 512 DMX channels per output  Color Sequence:RGB selectable / RGBW SingleColor white, red, green, blue  Pixel groups:1 up to 127 pixel / all  Gamma correction:Selectable for LPD1886 12Bit (8Bit controlled), UCS9812 (8Bit controlled)  LED-Display:5 RGB Status-LED Ethernet-Status-LEDs yellow and green  Dimensions:70mm x 90mm x 60mm Product DownloadsArtNet PixxControl PX2+Bedienungsanleitung ArtNet PixxControl PX2+User Manual ArtNet PixxControl PX2+Firmware

 ArtNet Multi PixxControlThe ArtNet Multi PixxControl is a very compact LED pixel controller for digital LED stripes. With a standard ArtNet (DMX over Ethernet)the combination to standard ethernet and WiFi components is possible.Selectable LED controllerThe used LED chip inside the connected digital LED Stripe is selected.Thus, the use of various digital LED Stripes is possible, for example:MagiarLED III flex, MagiarLED II flex, DycoLED, TM1804, TM1812, TM1814, WS2801, WS2811, LPD8803, LPD8806, UCS1903,UCS1912, UCS2912, APA-101, APA-102, APA-104, INK1002, INK1003, SK6812, SK9822, LPD1886 8Bit, LPD1886 12BitAdjustable color sequenceThe RGB color sequence is adjustable which allows universal usage.In addition, you can choose a single color option, in which each pixel has only one channel.Adjustable pixel groupArtNet Multi PixxControl supports pixel groups with an adjustable length.Each pixel group behaves as a single pixel on the 3 DMX channels is controlled.Thus, in extended installations save channels.Muteable LED indicatorThe LED indicators on the ArtNet Multi PixxControl are muteable by ArtNet command (AcLedMute) or time-controlled.This is helpful to disturbing "points of light" especially on stages.Easy ConfigurationA user-friendly configuration via a web browser allows a fast and uncomplicated setting of all parameters.No special software is required, a normal web browser is sufficient. Thus, the configuration at any timefrom your PC, smartphone or tablet device.For easy setting of the IP-address, we provide the IP Configurator as a PC tool or Android app available for free.This allows you to leave the network settings unchanged and can easily configure the IP.High quality and compact designThe ArtNet Multi PixxControl is designed with a 4-pin Neutrik metal XLR connector inside a compact aluminum body.Use together with WiFi componentsIn conjunction with a WiFi-bridge the ArtNet Multi PixxControl can be integrated into standard WiFi networks.As WiFi-bridge we suggest: Netgear WNCE2001.Firmware-Update-FunctionIn order to take advantage of future features, the ArtNet Multi PixxControl has a firmware update function.This can be launched from the browser so that no access to the device is necessary!This Interface will be supported from:Madrix - LED Lighting Control SolutionsDMX-Configurator 4PIXX (V2.x)Jinx!or any other software with ArtNet-outputWe suggest the software MADRIX® - LED Lighting Control Solutions for an easy and optimal controlling via ArtNet. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:5V with included power supply  Connection:RJ45 Ethernet Neutrik® XLR4 USB Mini-B only for the power supply  Protocol:Art-Net ™ (downward compatible)  LED types:MagiarLED III flex / MagiarLED II flexmax. 2720 Pixel TM1804 / TM1812 / TM1829max. 1360 Pixel WS2801max. 1360 Pixel LPD8803max. 1360 Pixel DycoLED / LPD6803 / LPD1101 / APA-101max. 1360 Pixel APA102 / SK9822max. 2720 Pixel LPD1886 - 8Bit oder 12Bitmax. 1360 Pixel WS2811 / WS2812(B) / APA-104 / SK6812max. 1360 Pixel INK1002 / INK1003max. 1360 Pixel UCS1903 / / UCS 1912 / UCS2912max. 1360 Pixel UCS9812max. 850 Pixel DMX512max. 170 Pixel DMX1024max. 340 Pixel  Gamma correction:in combination with LPD1886 - 12Bit, UCS9812  Color sequence:RGB adjustable / SingleColor red, green, blue, white RGBW with SK6812 / UCS2912  Pixel groups:adjustable, 1 - 10  Dimensions:75 x 26 x 35 mm  Delivery includes::ArtNet Multi PixxControl 5V power supply 1m RJ45 network cable 1:1 Product DownloadsArtNet Multi PixxControlBedienungsanleitung ArtNet Multi PixxControlUser Manual ArtNet Multi PixxControlFirmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual IP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note Application NotesArtNet Multi PixxControl mit Jinx ansteuernAppNote Controlling ArtNet Multi PixxControl with JinxAppNote

 SD-Player 8The SD-Player 8, in the following only called ArtNet Player X,is the first Stand-Alone Controller from DMX4ALL, offered in different model versions.Depending on the needed application, the ArtNet Player X is available in different designs and functionalities.As usual, the ArtNet Player X is also quickly ready for use in DMX4ALL manner and remains intuitiveand user-friendly despite numerous and new functions in the handling.This is possible by the well-structured user interface of the device's own web interface, available for the settings.An overview of the current status is provided by the integrated RGB LED.Whether as a board version or as compact ready-made device with comfortable touch operation, the ArtNet Player Xcan be used to play lighting programs from SD card. Different file formats can be used, which can be created withthe DMX Configurator or used as TPM2 files from freely available software.With up to 4 universes, a maximum of 2048 channels can be output via the network with just one ArtNet Player X.Even in larger installations, handling across several devices remains easy and clear thanks to Master-Slave operation.The ArtNet Player X offers the possibility to execute programs comfortably time-controlled. Up to 4 configurable timerscan be defined individually. For each timer one or several days can be assigned as well as the start time.Furthermore, the playback duration can be set optionally.The current time is needed for the correct processing the timers. This setting is done either via the device's ownweb interface, the optionally available DCF77 Key with DCF77 sensor or according to the ArtNet specificationvia network-based ArtTimeSync packages. DCF77 allows an automatic adjustment to summer / winter time.The configurable digital inputs integrated in the ArtNet Player X allow operation by remote pushbuttons,making additional devices obsolete. Designed as a LongDistance inputs, even larger distances do not cause anyproblems when mounting the switching elements.The ArtNet Player X is convincing and combines a multitude of useful and innovative functions undera top-hat rail housing in its space-saving, compact design.Replay up to 4 DMX UniversesThe ArtNet Player X can output up to 4 DMX universes via Art-Net.Output via Art-NetThe DMX universes to be output can be output via Art-Net.Synchronization of sveral devicesIf more DMX universes are needed, several ArtNet Player X can be synchronized.Two galvanically separate DMX connectionsOn the ArtNet Player X there are 2 galvanically isolated DMX connections,one DMX-OUT and one DMX-IN.Remote-FunctionThe ArtNet Player X has a configurable remote function. Remote control ispossible via DMX, Art-Net, HTTP request or DMX4ALL Commands.8 LongDistance inputs8 configurable digital inputs are available for connecting buttons or switches.The inputs are designed as LongDistance Inputs, so the switching elements can also be installed in greater distance.Switchable LED DisplayThe LED displays on the ArtNet Player X can be switched off by ArtNet command or time-controlled,to avoid disturbing "light spots " especially on stage.RGB-FilterA quick and uncomplicated change of the defined color in the program is allowed by the RGB filter.The selected colors can be filtered as needed without editing the previously created program.Firmware-Update-FunctionThe firmware update function enables to use always the free, current device software.Different data files for lighting programsThe ArtNet Player X plays the lighting programs from the SD card.The DMX4ALL program files as well as TPM2 or TPM2NET can be used as data formats.Easy ConfigurationFast and uncomplicated configuration is possible at any time from a PC, smartphone or tablet,due to the user-friendly configuration via any web browser.DIN rail housing availableThe DIN rail housing 700 is available as accessory for the ArtNet Player X.Free SoftwareFor creating the programs our free software DMX-Configurator can be used, which is availablein the current FREE version as download on our website www.dmx4all.de. Specifications  Power supply:8-24V DC (150mA@12V; 100mA@24V)  Connections:RJ45 Ethernet Screw terminals  Ethernet:10 Mbit/s | 100 Mbit/s  Art-Net™ / sACN:4 universes up to 2048 channels  DMX2x galvanically isolated 1x DMX OUTPUT: DMX512 1x DMX INPUT: DMX512  Device-Sync:Synchronisation of several devices  Remote-Options:DMX Art-Net™ HTTP-Request DMX4ALL Commands  Digital Input:8 configurable Long Distance-Inputs  Timer:Up to 4 configurable timer for executing programs  SD Card:microSD up to 16GB  Playback format:DMX4ALL program files TPM2 files TPM2NET files  Status display:RGB-LED, network status LEDs all disengageable  Features:RGB-Filter Firmware-Update-Function Silent without a fan  Optional Equipment:DCF77 receiver  Dimension:62mm x 88mm x 29mm Product DownloadsSD-Player 8Bedienungsanleitung SD-Player 8User Manual SD-Player 8Firmware SD-Player 8Sample Configuration Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual
