DMX UNIVERSE DR1.1 RDM

 ArtNet-LED-Dimmer 6The ArtNet Dimmer 6 is a compact LED-Dimmer with 6 seperate LED-outputs.These can be used for RGB/ RGB+W / RGB + W WW or for single color stripes.High Power OutputsEach output can drive a current up to 10A.So it is possible to connect a maximum load on ecah output of 120W (12V) or 240W (24V).16 Million ColorsWith the RGB-LED-Stripe up to 16 million colours can be adjusted.By using an additional single color white stripe it is possible to makecolor neutral illuminations or pastel colours.NEW: User Configurable Color ProgrammsThe ArtNet-LED Dimmer 6 has also 10 user configurable color programms whichcan be defined via the webbrowsr or the Android App „DMX4ALL Remote“.User-friendly ConfigurationA user-friendly configuration via a web browser allows a fast and uncomplicated setting of all parameters.Power Supply for WiFi BridgeIn addition the ArtNet-Dimmer 6 has a USB connector providing a power supplywith 5V/500mA for external devices e.x. a WiFi-bridge.As WLAN-bridge we suggest: TP-Link TL-WR702N or TP-Link TL-WR802NControll with AppThe controll of this device is possible by using the free Android-App "DMX Remote".Firmware-Update-FunctionIn order to take advantage of future features, the ArtNet-LED-Dimmer 6 has a firmware update function.This can be launched from the browser so that no access to the device is necessary!DMX4ALL-Command interfaceThe ArtNet-LED-Dimmer 6 has another TCP communication interface.This interface uses the DMX4ALL-commands via TCP packets. Art-Net ™ Designed by and Copyright Artistic Licence Holdings Ltd. Specifications  Power supply:12-24V DC / 100mA  LED voltage:12-24V DC (no AC voltage !)  Connection:RJ45 Ethernet  LED-connection:6 outputs max. 10A per output (in total 60A) common anode (+)  USB-connection:5V / 500mA for power supply external devices (e.g. WLAN-bridge)  PWM-Frequency:250Hz / 500Hz / 1000Hz / 2000 Hz  Dimensions:64,2 x 82 x 20 mm  Protocol:Art-Net 3 ™ DMX4ALL Commands Product DownloadsArtNet-LED Dimmer 6Bedienungsanleitung ArtNet-LED Dimmer 6User Manual ArtNet-LED Dimmer 6Firmware Software & ToolsIP Configurator (ArtNet Produkte)Windows 32 & 64bit IP ConfiguratorAnwendungshinweis IP ConfiguratorApplication Note DMX4ALL CommandsDMX4ALL Commands for Devolopment

<table width="800" cellspacing="1" cellpadding="1">  <tr>    <td><img src="https://www.media.dmx4all.store/images/kategorie-head.png" align="absmiddle"><span style="font-size: large;"><strong>&nbsp;DMX-LED-Dimmer BB4</strong></span></td>  </tr></table><br>The DMX-LED-Dimmer BB4 is designed to control LEDs, which operate with<br>constant current and works with up to 24V of the LED voltage.<br><br><br><strong>Regulable output current</strong><br>The DMX LED Dimmer BB4 has 4 outputs where the LEDs are operated with a<br>current of 0 to 330mA-1500mA. The level of the output current can be adjusted via DMX.<br><br><strong>Voltages up to 24V</strong><br>The DMX-LED-Dimmer BB4 works with supply voltages up to 24V.<br><br><strong>DMX-FAIL Function</strong><br>An adjustable DMX FAIL function offers the option to hold the current state (HOLD)<br>or to take a preset value in case of a failed DMX signal.<br><br><strong>DMX-Master-Dimmer</strong><br>The DMX-LED-Dimmer BB4 has various Master Dimmers.<br><br><strong>Up to 1024 brightness steps</strong><br>Each output driver has a resolution of 1024 steps in which the output<br>current is controlled. The special driver design allows a constant current<br>which is not modulated by a PWM for the dimming process.<br><br><strong>Two adjustable operation modes</strong><br>Control with 2 DMX channels per output, the first DMX channel allows<br>coarse control and the second DMX channel allows fine control.<br><br><strong>Settable dim curve</strong><br>The dimming curves are freely configurable for each output.<br><br><strong>RDM support</strong><br>The DMX LED dimmer X9HR allows configuration via RDM over DMX.<br><br><strong>LED-State-Display</strong><br>The integrated multifunctional display shows the current status of the device.<br><br><strong>Suitable for top hat rail mounting</strong><br>The top-hat rail housing 1050 is available as optional accessory for the DMX-LED-Dimmer BB4.<br><br><br><img class="dmxmadein" src="https://www.media.dmx4all.store/images/made-in-germany.png" border="0"><br><br><br><!-- Specifications --><table width="800" cellspacing="1" cellpadding="1">  <tr>    <td><img src="https://www.media.dmx4all.store/images/kategorie-head.png" border="0" align="absmiddle"><span style="font-size: large;"><strong> ArtNet Player 4</strong></span></td>  </tr></table><table border="0" cellspacing="1" cellpadding="1">  <tr>    <td width="300">&nbsp;</td>    <td width="500">&nbsp;</td>  </tr>  <tr>    <td>Power supply:</td>    <td>8-24V DC (maximum 26V)</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>50mA (without connected load)</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>&nbsp;</td>  </tr>  <tr>    <td>Drop voltage:</td>    <td>max. 2V</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>&nbsp;</td>  </tr>  <tr>    <td>Output current:</td>    <td>4x 0 – settable output current (330mA – 1500mA)</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>Sustained short circuit / 1024 steps at each output</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>&nbsp;</td>  </tr>  <tr>    <td>Protokoll:</td>    <td>DMX512</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>RDM</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>&nbsp;</td>  </tr>  <tr>    <td>DMX channels:</td>    <td>4 channels with 8Bit control and Lookup table</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>8 channels with 10Bit control</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>&nbsp;</td>  </tr>  <tr>    <td>DMX-FAIL:</td>    <td>Hold / 0%-100%</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>&nbsp;</td>  </tr>  <tr>    <td>Masterdimmer:</td>    <td>Kein / Global / System</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>&nbsp;</td>  </tr>  <tr>    <td>PWM-Frequency:</td>    <td>no PWM on output</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>&nbsp;</td>  </tr>  <tr>    <td>StandAlone-Function:</td>    <td>9 internal StandAlone programs</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>Switching on individual outputs</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>&nbsp;</td>  </tr>  <tr>    <td>Operation temperature:</td>    <td>0°C up to +45°C</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>Thermal overload protection per output</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>&nbsp;</td>  </tr>  <tr>    <td>Connection:</td>    <td>Screw terminals</td>  </tr>  <tr>    <td>&nbsp;</td>    <td>&nbsp;</td>  </tr>  <tr>    <td>Dimensions:</td>    <td>99mm x 82mm x 47mm</td>  </tr></table><br><!-- Produkt Downloads --><table width="800" cellspacing="1" cellpadding="1">  <tr>    <td><img src="https://www.media.dmx4all.store/images/kategorie-head.png" align="absmiddle"><span style="font-size: large;"><strong>&nbsp;Product Downloads</strong></span></td>  </tr></table><div id="dmx4all-buttons">  <a class="document-button" onfocus="this.blur()" href="https://www.dmx4all.de/download/manuals_german/dmx_led_dimmer_bb4_mk2_german.pdf" target="_blank">DMX-LED-Dimmer BB4<br>  <span><span class="german-lang">Bedienungsanleitung</span></span></a>  <br>  <a class="document-button" onfocus="this.blur()" href="https://www.dmx4all.de/download/manuals_english/dmx_led_dimmer_bb4_mk2_english.pdf" target="_blank">DMX-LED-Dimmer BB4<br>  <span><span class="english-lang">User Manual</span></span></a></div>

 DMX-LED-Dimmer MaxiRGB (SR)The DMX-LED-Dimmer MaxiRGB is specially designed for driving RGB LED strips with 12V or 24V.The 3 separate LED outputs that are independently controllable via DMX can beused for RGB or separate single color LED stripes.Alternatively, internal color gradients can be called without external control.The operating voltage of the DMX-LED-Dimmer MaxiRGB is also the operating voltage of the LED-Stripes.SR-Version: With screw connectors Specifications  Power supply:12-24V DC / 50mA The supply voltage must correspond to the voltage for the LED stripe!  LED voltage:12-24V DC (no AC voltage !)  DMX Input:DMX512 / 3 channels  LED Output:3x (R/G/B) max. 10A each together max. 10A with common anode (+) common power supply  PWM resolution:256 steps (8-Bit), linear  PWM frequency:~240 Hz  StandAlone function:9 internal StandAlone-programs  Connectors:Screw connectors  Dimensions:70mm x 30 mm Product DownloadsDMX-LED-Dimmer MaxiRGB (SR)Bedienungsanleitung DMX-LED-Dimmer MaxiRGB (SR)User Manual

 DMX-LED-Dimmer X9HR+The DMX-LED-Dimmer X9HR+ is especially designed for controlling RGB LED-Stripes.The dimmer has 9 High-Resolution PWM-Outputs (3xRGB) independently controllable via DMX.9 OutputsThe DMX-LED-Dimmer X9HR+ has 9 outputs to which LEDs can be connected.All outputs are designed in the same way so single color, RGB or RGBW LEDs can be connected.High Power OutputsThe outputs can drive a current up to 10A.So it is possible to connect a maximum load of 120W (12V) / 240W (24V).0% to 100% dimmableThe connected LEDs are dimmed by PWM from 0% to 100%.For voltages from 12V up to 24VThe DMX-LED-Dimmer X9HR+ operates with supply voltages from 12V up to 24V.The LED voltage can be different per output so that one DMX-LED-Dimmer X9HR can control different LED systems.DMX-FAIL FunctionAn adjustable DMX FAIL function offers the option to get in case of lost DMX signal thecurrent state (HOLD) or to adopt a predefined value if the DMX signal fails.DMX-Master DimmerOptionally, another DMX channel can be activated as Master Dimmer (all outputs) orone master dimmer per RGB group. The global master dimmer is fixed at DMX address 1 andcan be used as system master dimmer.Adjustable dimming curveThe dimming curves can be configured individually for each output.RDM supportThe DMX-LED-Dimmer X9HR+ allows configuration by RDM via DMX.SubDevice-ModeWithin the SubDevice Mode, each output is assigned its own DMX address and DMX FAIL behavior via RDM.Touch-ControlThe DMX-LED-Dimmer X9HR+ is designed with 3 touch fields for operation and a 7-segment display.RGB-Status displayVia a RGB status display the DMX reception is shown.Firmware-Update-FunctionTo use future functions, the DMX-LED-Dimmer X9HR+ offers a firmware update function. Specifications  Power supply:7-24V DC 100mA@12V / 150mA@24V (without load)  LED voltage:7-24V DC (no AC voltage !)  Protocol:DMX512 RDM  DMX channels:9 channels with 8Bit-controlling and LookUp-Table 18 channels with 16Bit-controlling + optional Master-Dimmer-Channels  Output:9 PWM-signal common supply voltage anode (PLUS)  8bit ModePWM-Frequency 488 Hz with LookUp-Table 2 kHz or 4 kHz without LookUp-Table  16bit ModePWM-Frequency 488 Hz without LookUp-Table  Masterdimmer:None / Global / RGB / System  DMX-FAIL:Hold / 0%-100%  Output current:max. 10A each output In sum 90A with all GND connections  Output power:9x 120W (12V) / 9x 240W (24V)  CTRL output:Control output for switching off the load power supply units (Energy-Save)  StandAlone function:9 internal StandAlone programs  Display:7 segment display RGB LED  TOUCH-Control:3 touch buttons  Connectors:Screw terminals  Dimensions:105mm x 90mm x 60mm Produkt DownloadsDMX-LED-Dimmer X9 HR+Bedienungsanleitung DMX-LED-Dimmer X9 HR+User Manual DMX-LED-Dimmer X9 HR+USB DriverVersion 6.0.0.0 DMX-LED-Dimmer X9 HR+Firmware Software & ToolsDMX-Configurator V2Windows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual

 WAGO 221-2411 DurchgangsverbinderWith the 221 series connection terminal, WAGO enables tool-free wiring for all types of conductors.Clear handling and space-saving design make every application child's play.Simple, quick and safe handling.The connection terminals can be opened particularly easily and quickly.Thanks to the specially designed operating lever, only minimal effort is required to open the 221.The connection is made completely without tools.In addition, the recessed grips on the side prevent slipping and ensure that the terminal is easy to hold while connecting the conductors.With the small connection terminal up to 4 mm², all types of conductors with different cross-sections can be clamped quickly and easily.The 1-way through connectors connect fine-stranded conductors from 0.14 to 4 mm² as well as single and multi-wire conductors from 0.2 to 4 mm².The large connection area allows you to connect different types of conductors and bridge large differences in cross-section. Specifications  Number of poles:1  Rated current:32A  Cross section flexible (max.):4 mm²  Cross section flexible (min.):0.14 mm²  Cross section rigid (max.):4 mm²  Cross section rigid (max.):0.2 mm²  Part number:221-2411  Manufactor:WAGO

 WAGO 221-412 Verbindungsklemme 2With the 221 series connection terminal, WAGO enables tool-free wiring for all types of conductors.Clear handling and space-saving design make every application child's play.Simple, quick and safe handling.The connection terminals can be opened particularly easily and quickly.Thanks to the specially designed operating lever, only minimal effort is required to open the 221.The connection is made completely without tools.In addition, the recessed grips on the side prevent slipping and ensure that the terminal is easy to hold while connecting the conductors.With the small connection terminal up to 4 mm², all types of conductors with different cross-sections can be clamped quickly and easily.The connectors connect fine-stranded conductors from 0.14 to 4 mm² as well as single and multi-wire conductors from 0.2 to 4 mm².The large connection area allows you to connect different types of conductors and bridge large differences in cross-section. Specifications  Type:Connection terminal  Assembly:2 conductors  Rated current:32A  Cross section flexible (max.):4 mm²  Cross section flexible (min.):0.14 mm²  Cross section rigid (max.):4 mm²  Cross section rigid (max.):0.2 mm²  Part number:221-412  Manufactor:WAGO

 WAGO 221-413 Verbindungsklemme 3With the 221 series connection terminal, WAGO enables tool-free wiring for all types of conductors.Clear handling and space-saving design make every application child's play.Simple, quick and safe handling.The connection terminals can be opened particularly easily and quickly.Thanks to the specially designed operating lever, only minimal effort is required to open the 221.The connection is made completely without tools.In addition, the recessed grips on the side prevent slipping and ensure that the terminal is easy to hold while connecting the conductors.With the small connection terminal up to 4 mm², all types of conductors with different cross-sections can be clamped quickly and easily.The connectors connect fine-stranded conductors from 0.14 to 4 mm² as well as single and multi-wire conductors from 0.2 to 4 mm².The large connection area allows you to connect different types of conductors and bridge large differences in cross-section. Specifications  Type:Connection terminal  Assembly:3 conductors  Rated current:32A  Cross section flexible (max.):4 mm²  Cross section flexible (min.):0.14 mm²  Cross section rigid (max.):4 mm²  Cross section rigid (max.):0.2 mm²  Part number:221-413  Manufactor:WAGO

 WAGO 221-415 Verbindungsklemme 5With the 221 series connection terminal, WAGO enables tool-free wiring for all types of conductors.Clear handling and space-saving design make every application child's play.Simple, quick and safe handling.The connection terminals can be opened particularly easily and quickly.Thanks to the specially designed operating lever, only minimal effort is required to open the 221.The connection is made completely without tools.In addition, the recessed grips on the side prevent slipping and ensure that the terminal is easy to hold while connecting the conductors.With the small connection terminal up to 4 mm², all types of conductors with different cross-sections can be clamped quickly and easily.The connectors connect fine-stranded conductors from 0.14 to 4 mm² as well as single and multi-wire conductors from 0.2 to 4 mm².The large connection area allows you to connect different types of conductors and bridge large differences in cross-section. Specifications  Type:Connection terminal  Assembly:5 conductors  Rated current:32A  Cross section flexible (max.):4 mm²  Cross section flexible (min.):0.14 mm²  Cross section rigid (max.):4 mm²  Cross section rigid (max.):0.2 mm²  Part number:221-415  Manufactor:WAGO

 WAGO 221-500 BefestigungsadapterWith the 221 series, WAGO enables tool-free wiring for all types of conductors.Clear handling and space-saving design make every application child's play.Simple, quick and safe handling.The mounting carrier is suitable for 2-, 3- and 5-conductor 221 Series Splicing Connectors (4 mm²). Specifications  Type:Mounting carrier  Suitable:for 2-, 3- and 5-conductor 221 Series Splicing Connectors  Mounting type:DIN-35 rail Screw mount  Color:Orange  Part number:221-500  Manufactor:WAGO

 MEANWELL HDR-15-12 (12V/1,25A/15W)- Small, staircase rail power supply, compact design, fanless design- Suitable for mounting on DIN standard mounting rails TS35/7 or TS35/15- Enclosed case, Touch-guard screw terminals - Universal input - Overload protection, current limiting, auto recovery - Protections: short circuit/over load/over voltage - Power-on LED display - Low no load power consumption - Manufactor: MEANWELL - Manufactor order code: HDR-15-12 Note:These power supplies are considered as a component that has to be installed in a final equipment. Specifications  Input Type:1-Phase / Single PhaseInput Voltage Range:85VAC to 264VAC | 120VDC to 370VDCFrequency Range:47~63HzOutput Voltage:12VDCOutput Current:0...1,25AOutput Power:15WOpen Frame/Enclosed:EnclosedIsolation Voltage:3kVrmsInrush Current max.:45ARated Output Power:110...145%Operating Temperature Range:-30°C to +70°CUnit Weight:78gLength/Width/Height:54.5mm/17.5mm/90mm Product DownloadsHDR-15Datasheet

 MEANWELL HDR-60-12 (12V/4,5A/54W)- Small, staircase rail power supply, compact design, fanless design- Suitable for mounting on DIN standard mounting rails TS35/7 or TS35/15- Complies with the EU standard DIN EN 43880- Enclosed case, Touch-guard screw terminals- Universal input- Overload protection, current limiting, auto recovery- Protections: short circuit/over load/over voltage- Power-on LED display- Low idle power consumption- Insulation class II- Manufactor: MEANWELL- Manufactor order code: HDR-60-12Note:These power supplies are considered as a component that has to be installed in a final equipment. Specifications  Input Type:1-Phase / Single PhaseInput Voltage Range:85VAC to 264VAC | 120VDC to 370VDCFrequency Range:47~63HzOutput Voltage:12VDCOutput Current:0...4.5AOutput Power:54WOpen Frame/Enclosed:EnclosedIsolation Voltage:3kVrmsInrush Current max.:30A/115VAC | 60A/230VACRated Output Power:105...160%Operating Temperature Range:-30°C to +70°CUnit Weight:190gLength/Width/Height:54.5mm/52.5mm/90mm Product DownloadsHDR-60Datasheet

 MEANWELL RS-25-12 (12V/2,1A/25W)- Enclosed case, screw terminals- Universal input- Overload protection, current limiting, auto recovery- Protections: short circuit/over load/over voltage- Long life 105°C electrolytic capacitors- Manufactor: MEANWELL- Manufactor order code: RS-25-12Note:These power supplies are considered as a component that has to be installed in a final equipment. Specifications  Output voltage:12V  Output current, max:2,1A (0...2,1A)  Input voltage:88...264V AC (47...63Hz) 125...373V DC  Input Inrush Current, max.:30A  Over Current Protection:110...180%  Operating Temperature:-20...+70°C  Weight:200g Produkt DownloadsRS-25Datasheet

 RECOM RAC05-12SK/C14 (12V/420mA)- Unique patented design- Isolated power supply with integrated mains filter- Packaged inside of line filter case- Safe, touchable DC outputs- Easy installation- Worldwide standard IEC input- 85-264VAC universal input voltage- Manufactor: RECOM- Manufactor order code: RAC05-12SK/C14 Specifications  Output voltage:12V  Output current, max:420mA (0...420mA)  Input voltage:85...264V AC (47...63Hz) 120...370V DC  Input Inrush Current, max.:30A  Operating Temperature:-25...+60°C  Weight:56g Produkt DownloadsDatasheetUser Manual

 Stecker-Schaltnetzteil 12V 0,63A- Plug-in switching power supply with europlug- Universal input- Protections: short circuit/over load- Insulation Class II- Low no load power consumption- Meets DOE VI- Manufactor: HN-Power- Product name: HNP06-120L6 Specifications  Output voltage:12V  Output current, max:0,63A (0...0,63A)  Input Voltage:90...264V AC (47...63Hz)  Input Inrush Current, Max.:30A  No Load Power Consumption, Max.:0,075W  Operating Temperature:-10...+40°C  Cable Length:1,5m  Output Plug:2,1x5,5mm Produkt DownloadsHNP06-120L6Datasheet

 DMX-Configurator FREE-VersionThe controlling software DMX-Configurator represents a user friendly surface to create light scenes (programs). Up to 8 DMX-universes can be used which can be represented as pixel-matrix.A live operation with a connected DMX4ALL DMX- or Pixel-Interfaces will be possible as well as an export to DMX4ALL DMX-Player and SD-Card-Player. All in all, in many areas an application will be possible.The FREE-Version is available as download for free and has the following functions.Range of function:1 DMX OUT universeArtNet SupportCue-ListRecord FunctionArtNet Sync RecordingLoop Find FunctionDevice Manager to create LED-Pixel screensPreview for LED-Pixel screensRemote Manager (MIDI / TIMER / DMX)Secutity functions: Password protected programming fileExport/Import of scenesExport/Import of stepsExport for SD-Player 8 / ArtNet-Player X / DMX-Player L MK2Limits of FREE-Version:Multi Interface Support with 16 DMX universes can be used with up to 2 scenesTOUCH-Mode (Time limited)No secutity functionsNo hardware secutity functionsSpecifications  Operating system:Windows® 7, Windows® 8  Software-Updates:Available as download Produkt DownloadsDMX-ConfiguratorWindows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual Application NotesAufnahme von Art-NetAppNote Importieren von Jinx! SzenenAppNote Aufnahme eines DMX SignalsAppNote

 DMX-Configurator PRO-VersionThe controlling software DMX-Configurator represents a user friendly surface to create light scenes (programs). Up to 16 DMX-universes can be used which can be represented as pixel-matrix. A live operationwith a connected DMX4ALL DMX- or Pixel-Interfaces will be possible as well as an export toDMX-Player and SD-Card-Player. All in all, in many areas an application will be possible. The BASIC-Version use a USB-Dongle needing a free USB-slot. The Dongle can be used on several computer and is easy usable for service tasks. Range of functions:16 DMX OUT + 16 DMX-IN universesMulti Interface SupportCuelistArtNet SupportRecord FunctionArtNet Sync RecordingLoop Find FunctionDevice Manager to generate LED-Pixel for lines and screensPreview for LED-Pixel for lines and screensTOUCH-ModeRemote Manager (MIDI / TIMER / DMX)Export/Import of scenesExport/Import of stepsExport for AvengerSD / NanoSD Player / ArtNet-Player 4 / ArtNet MultiPixxPlyer 16 / DMX-Player S/L/ONESecurity functions: Optional password for programming fileHardware secutity functions: Program execution can be limited by using the hardware serial number Important InformationPlease note that the software is excluded from change and return ! ArtNet Player 4  Operating system:Windows®  PC-connections:USB 1.1 / USB 2.0  Scope of delivery:USB-Dongle with PRO-Licence DMX4ALL lanyard with dongle holder  Software-Updates:Available as download Produkt DownloadsDMX-ConfiguratorWindows 32 & 64bit DMX-Configurator V2Bedienungsanleitung DMX-Configurator V2User Manual DMX-Configurator PRO-VersionUSB Driver Application NotesAufnahme von Art-NetAppNote Importieren von Jinx! SzenenAppNote Aufnahme eines DMX SignalsAppNote

 RDM-Configurator FREE-VersionThe RDM Configurator software is a PC-based configuration software for RDM devices.The RDM Configurator is a software that allows you to configure RDM-capable devices.RDM stands for Remote Device Management and enables bidirectional communication betweenconnected RDM-enabled devices.Settings for RDM devices (e.g., start address) can be configured remotely via RDM withoutdirect access to the device. An RDM-capable Art-Net™ RDM gateway is required to use RDM.Once the RDM device is in the system, the unique UID allows device-specific settingsto be configured remotely via RDM command. Direct access to the device is not necessary.Depending on the RDM device used, the properties that can be set via RDM vary.Functionality:Clear user interfaceMulti Art-Net™-Gateway supportArt-Net™-Gateway configurationMulti DMX/RDM-Port supportUser-friendly plain text RDM parameter settingRDM DiscoverRDM GET-ParameterRDM SET-ParameterDMX4ALL MSC-Parameter (Manufacturer Specific Command)RDM SubDevice-SupportRDM Sensor-SupportDMX-Fader PanelDMX-MonitorSaving RDM parameters to configuration fileFREE version restrictions:RDM SET parameters for non-DMX4ALL RDM devicesRestoring RDM parameters via configuration fileAutoRefresh of the RDM sensorsFastDMX-AddressingFor the limited functions (setting parameters in non-DMX4ALL-RDM devices)an optionally available license is required.The license requires a DMX4ALL RDM gateway on which the license key is stored.RDM-Configurator  Operating system:Windows®  Software-Updates:Available as download Produkt DownloadsRDM-ConfiguratorBedienungsanleitung RDM-ConfiguratorUser Manual RDM-ConfiguratorSoftware

 RDM-Configurator MonatslizenzThe RDM Configurator software is a PC-based configuration software for RDM devices.The RDM Configurator is a software that allows you to configure RDM-capable devices.RDM stands for Remote Device Management and enables bidirectional communication betweenconnected RDM-enabled devices.Settings for RDM devices (e.g., start address) can be configured remotely via RDM withoutdirect access to the device. An RDM-capable Art-Net™ RDM gateway is required to use RDM.Once the RDM device is in the system, the unique UID allows device-specific settingsto be configured remotely via RDM command. Direct access to the device is not necessary.Depending on the RDM device used, the properties that can be set via RDM vary.Functionality:Clear user interfaceMulti Art-Net™-Gateway supportArt-Net™-Gateway configurationMulti DMX/RDM-Port supportUser-friendly plain text RDM parameter settingRDM DiscoverRDM GET-ParameterRDM SET-ParameterDMX4ALL MSC-Parameter (Manufacturer Specific Command)RDM SubDevice-SupportRDM Sensor-SupportDMX-Fader PanelDMX-MonitorSaving RDM parameters to configuration fileAdditional features with license:RDM SET parameters for non-DMX4ALL RDM devicesRestoring RDM parameters via configuration fileAutoRefresh of the RDM sensorsFastDMX-AddressingFor the limited functions (setting parameters in non-DMX4ALL-RDM devices)an optionally available license is required.The license requires a DMX4ALL RDM gateway on which the license key is stored.RDM-Configurator  Operating system:Windows®  Software-Updates:Available as download Produkt DownloadsRDM-ConfiguratorBedienungsanleitung RDM-ConfiguratorUser Manual RDM-ConfiguratorSoftware

 RDM-Configurator JahreslizenzThe RDM Configurator software is a PC-based configuration software for RDM devices.The RDM Configurator is a software that allows you to configure RDM-capable devices.RDM stands for Remote Device Management and enables bidirectional communication betweenconnected RDM-enabled devices.Settings for RDM devices (e.g., start address) can be configured remotely via RDM withoutdirect access to the device. An RDM-capable Art-Net™ RDM gateway is required to use RDM.Once the RDM device is in the system, the unique UID allows device-specific settingsto be configured remotely via RDM command. Direct access to the device is not necessary.Depending on the RDM device used, the properties that can be set via RDM vary.Functionality:Clear user interfaceMulti Art-Net™-Gateway supportArt-Net™-Gateway configurationMulti DMX/RDM-Port supportUser-friendly plain text RDM parameter settingRDM DiscoverRDM GET-ParameterRDM SET-ParameterDMX4ALL MSC-Parameter (Manufacturer Specific Command)RDM SubDevice-SupportRDM Sensor-SupportDMX-Fader PanelDMX-MonitorSaving RDM parameters to configuration fileAdditional features with license:RDM SET parameters for non-DMX4ALL RDM devicesRestoring RDM parameters via configuration fileAutoRefresh of the RDM sensorsFastDMX-AddressingFor the limited functions (setting parameters in non-DMX4ALL-RDM devices)an optionally available license is required.The license requires a DMX4ALL RDM gateway on which the license key is stored.RDM-Configurator  Operating system:Windows®  Software-Updates:Available as download Produkt DownloadsRDM-ConfiguratorBedienungsanleitung RDM-ConfiguratorUser Manual RDM-ConfiguratorSoftware
